xCommand Video Layout SetPresentationView

Set the presentation view mode.
View: Select Default when you want the presentation to be viewed with the default settings for the
codec. Select Maximized when you want the presentation to be displayed in full screen. Select
Minimized when you want the presentation to be displayed in a small picture on screen.
Requires user role: ADMIN
Parameters:
View(r): <Default/Maximized/Minimized>
Example:
xCommand Video Layout SetPresentationView View:Default
OK
*r VideoLayoutSetPresentationViewResult (status=OK):
** end

xCommand Video Layout LoadDb

Loads and starts using the specified video layout database. The default video layout database is
initially provided by the system. The custom database is generated by the Cisco TC Console tool and
is made available to the codec from within the TC Console tool. The TC Console software is found
at the Developer Zone web page. Go to: http://developer.tandberg.com/web/guest/tools/integrators/
audio-console.
Custom: The system will use the custom video layout database which generated by the Cisco TC
Console tool.
CustomAutoModes: The system will use the auto mode part of the custom video layout database.
Default: The system use the default video layout database which is provided by the system.
Requires user role: USER
Parameters:
Type(r): <Custom/CustomAutoModes/Default>
Example:
xCommand Video Layout LoadDb Type: Default
*r VideoLayoutLoadDbResult (status=OK):
** end
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration

The Experimental commands

The Experimental commands can be used 'as is' and will not be further documented.
NOTE: The Experimental commands are likely to change.

xCommand Experimental Audio LocalInput Mute

xCommand Experimental Audio LocalInput Unmute

xCommand Experimental Audio RemoteInput Mute

108
xCommand xCommand
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Mute the local audio input.
Requires user role: ADMIN
Parameters:
ConferenceId(r): <0..65534>
Example:
xCommand Experimental Audio LocalInput Mute ConferenceID:1
*r AudioLocalInputMuteResult (status=OK):
** end
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Unmute the local audio input.
Requires user role: ADMIN
Parameters:
ConferenceId(r): <0..65534>
Example:
xCommand Experimental Audio LocalInput Unmute ConferenceID:1
*r AudioLocalInputUnmuteResult (status=OK):
** end
NOTE: This Experimental command can be used 'as is' and will not be further documented. The
Experimental settings WILL change.
Mute the remote audio input.
ADMIN
Requires user role:
Parameters:
CallId(r): <0..65534>
Example:
xCommand Experimental Audio RemoteInput Mute CallID:1
*r AudioRemoteInputMuteResult (status=OK):
** end
