XML API service

TXAS is a service provided by Cisco units for transmitting and
receiving (transceiving) information encoded in XML format.
The API uses HTTP(S) as the transport mechanism and
connects to the normal web port (80). TXAS can be accessed
by bare-bone HTTP requests where URL's uniquely identifies
the request.
Bare-bone HTTP/HTTPS Access
The bare-bone HTTP mode uses a unique URL to identify the
specific request. The contents of the HTTP body will be a XML
document (or part of it).
Bare-bone HTTP(S) access is accomplished by passing
arguments in the query string (after '?' in URL) in a GET
request, or using the "application/x-www-form-urlencoded"
content-type method of POSTing form data (Each argument
starts with a name '=' and a value, and every parameter
separated with '&' (and opt NL).)
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API About the API xConfiguration
getxml
/getxml request returns an XML document based on the location parameter passed to the request. The elements (or complete
document) matching the expression will be returned.
On Incorrect XPath expression, a <Fault> element with a <XPathError> element will be returned.
getxml
REQUEST:
/getxml
PARAM:
location = XPath expression
formputxml
This is most useful in a POST (to extend character limit of 255 of GET urls). It posts a Configuration or Command document to
set the configurations or issue a command.
Like getxml, it has the data URL form-data encoded with one single parameter. The Content-Type of the document must be of
type "application/x-www-form-urlencoded" and the body must be encoded accordingly (e.g. first line will be xmldoc=<then the
document>).
formputxml
REQUEST:
/formputxml
PARAM:
xmldoc = "an XML document of Configuration, Directory or Command"
putxml
Putxml is like formputxml+, put uses the complete BODY as argument (i.e. the content of the xmldoc parameter). The Content-
type should be "text/xml" or "application/xml" ( or "text/plain"), though no check at the moment. (Except for application/x-www-
form-url encoded which will cause a failure).
putxml
REQUEST:
/putxml
PARAM:
HTTP BODY as argument
27
