xConfiguration Conference [1..1] PacketLossResilience Mode
Set the packetloss resilience mode. This configuration will only take effect for calls initiated after the
configuration is set.
Requires user role:
ADMIN
Value space:
<On/Off>
On: Enable the packetloss resilience.
Off: Disable the packetloss resilience.
Example:
xConfiguration Conference 1 PacketLossResilience Mode: On
xConfiguration Conference [1..1] Presentation Policy
Control how the presentation service is to be performed.
ADMIN
Requires user role:
Value space:
<LocalRemote/LocalOnly>
LocalRemote: The presentation will be shown locally and sent to remote side.
LocalOnly: The presentation will only be shown locally.
Example:
xConfiguration Conference 1 Presentation Policy: LocalRemote
xConfiguration Conference [1..1] IncomingMultisiteCall Mode
Set the incoming Multisite call mode. The MultiSite feature allows participants from more than two
locations to join a meeting — by video and/or telephone.
ADMIN
Requires user role:
<Allow/Deny>
Value space:
Allow: Accept incoming calls to an already active call/conference. The incoming call will be added
to the MCU conference.
Deny: The system will not accept incoming calls when you are in a call. The calling side will
receive a busy signal.
xConfiguration Conference 1 IncomingMultisiteCall Mode: Allow
Example:
D14641.06
Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API
xConfiguration
xConfiguration

The GPIO configuration

xConfiguration GPIO Pin [1..4] Mode

38
xCommand
The four GPIO pins are configured individually. The state can be retrieved by "xStatus GPIO Pin [1..4]
State". The default pin state is High (+12 V). When activated as output, they are set to 0 V. To activate
them as input, they must be pulled down to 0 V.
Requires user role:
ADMIN
Value space:
<InputNoAction/OutputManualState/OutputInCall/
OutputMicrophonesMuted/OutputPresentationOn/OutputAllCallsEncrypted/
OutputStandbyActive/InputMuteMicrophones>
InputNoAction: The pin state can be set, but no operation is performed.
OutputManualState: The pin state can be set by "xCommand GPIO ManualState Set PinX: <High/
Low>" (to +12 V or 0 V, respectively).
OutputInCall: The pin is activated when in call, deactivated when not in call.
OutputMicrophonesMuted: The pin is activated when microphones are muted, deactivated when
not muted.
OutputPresentationOn: The pin is activated when presentation is active, deactivated when
presentation is not active.
OutputAllCallsEncrypted: The pin is activated when all calls are encrypted, deactivated when one
or more calls are not encrypted.
OutputStandbyActive: The pin is activated when the system is in standby mode, deactivated
when no longer in standby.
InputMuteMicrophones: When the pin is activated (0 V), the microphones will be muted. When
deactivated (+ 12 V), the microphones are unmuted.
Example:
xConfiguration GPIO Pin 1 Mode: InputNoAction
API Reference Guide
