xConfiguration Standby StandbyAction

Define the camera position when going into standby mode.
Requires user role: ADMIN
Value space: <None/PrivacyPosition>
None: No action.
PrivacyPosition: Turns the camera to a sideways position for privacy.
Example: xConfiguration Standby StandbyAction: PrivacyPosition

xConfiguration Standby WakeupAction

Define the camera position when leaving standby mode.
Requires user role: ADMIN
Value space: <None/Preset1/Preset2/Preset3/Preset4/Preset5/Preset6/Preset7/
Preset8/Preset9/Preset10/Preset11/Preset12/Preset13/Preset14/Preset15/
RestoreCameraPosition/DefaultCameraPosition>
None: No action.
Preset1 to Preset15: When leaving standby the camera position will be set to the position defined
by the selected preset.
RestoreCameraPosition: When leaving standby the camera position will be set to the position it
had before entering standby.
DefaultCameraPosition: When leaving standby the camera position will be set to the factory
default position.
Example: xConfiguration Standby WakeupAction: RestoreCameraPosition
D14641.06 Codec C90 API Reference Guide TC5.0 November 2011.
© 2010-2011 Cisco Systems, Inc. All rights reserved.
About the API xConfiguration xConfiguration

The SystemUnit configuration

xConfiguration SystemUnit Name

xConfiguration SystemUnit MenuLanguage

xConfiguration SystemUnit ContactInfo Type

55
xCommand
Enter a System Name to define a name of the system unit. If the H.323 Alias ID is configured on the
system then this ID will be used instead of the system name. The system name will be displayed:
1) When the codec is acting as an SNMP Agent.
2) Towards a DHCP server.
Requires user role: ADMIN
Value space: <S: 0, 50>
Format: String with a maximum of 50 characters.
xConfiguration SystemUnit Name: "Meeting Room"
Example:
Select the language to be used in the menus on screen.
Requires user role: USER
Value space: <English/ChineseSimplified/ChineseTraditional/Czech/Danish/Dutch/
Finnish/French/German/Hungarian/Italian/Japanese/Korean/Norwegian/Polish/
PortugueseBrazilian/Russian/Spanish/SpanishLatin/Swedish/Turkish>
Example: xConfiguration SystemUnit MenuLanguage: English
Describes which parameter to put in the status field in the upper left corner on the screen display.
The information can also be read with the command xStatus SystemUnit ContactInfo.
Requires user role: ADMIN
Value space: <Auto/None/IPv4/IPv6/H323Id/E164Alias/SipUri/SystemName>
Auto: Shows the address which another system can dial to reach this system, depending on the
default call protocol and system registration.
None: Do not show any contact information.
IPv4: Shows the IPv4 address as the contact information.
IPv6: Shows the IPv6 address as the contact information.
H323Id: Shows the H323 ID as the contact information.
E164Alias: Shows the H323 E164 Alias as the contact information.
SipUri: Shows the SIP URI as the contact information.
SystemName: Shows the system name as the contact information.
Example: xConfiguration SystemUnit ContactInfo Type: Auto
