xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
Ethernet Type
Click Create to create the new ACL Profile.
To view the setting details for a created profile, click the Show Details button for the corresponding entry on the Access Profile
List window, revealing the following window:
The window shown below is the Add ACL Profile window for IPv4:
The following parameters can be set for the IPv4 ACL type:
Parameter
Select Profile ID
Select ACL Type
Selecting this option instructs the Switch to examine the Ethernet type value in each frame's
header.
Figure 7 - 4. Access Profile Detail Information window for Ethernet
Figure 7 - 5. Add ACL Profile window for IPv4 ACL
Description
Use the drop-down menu to select a unique identifier number for this profile set. This value
can be set from 1 to 200.
Select profile based on Ethernet (MAC Address), IPv4 address, IPv6 address, or packet
