xStack DGS-3200 Series Layer 2 Managed Gigabit Ethernet Switch Web UI Reference Guide
802.1Q VLAN
IPv4 DSCP
IPv4 Source IP Mask
IPv4 Destination IP
Mask
Protocol
Click Create to implement changes made.
To view the setting details for a created profile, click the Show Details button for the corresponding entry on the Access Profile
List window, revealing the following window:
content. This will change the window according to the requirements for the type of profile.
Select Ethernet ACL to instruct the Switch to examine the layer 2 part of each packet header.
Select IPv4 ACL to instruct the Switch to examine the IPv4 address in each frame's header.
Select IPv6 ACL to instruct the Switch to examine the IPv6 address in each frame's header.
Select Packet Content to instruct the Switch to examine the packet content in each frame's
header.
Selecting this option instructs the Switch to examine the 802.1Q VLAN identifier of each
packet header and use this as the full or partial criterion for forwarding.
Selecting this option instructs the Switch to examine the DiffServ Code part of each packet
header and use this as the, or part of the criterion for forwarding.
Enter an IP address mask for the source IP address.
Enter an IP address mask for the destination IP address.
Selecting this option instructs the Switch to examine the protocol type value in each frame's
header. Then the user must specify what protocol(s) to include according to the following
guidelines:
Select ICMP to instruct the Switch to examine the Internet Control Message Protocol (ICMP)
field in each frame's header.
•
Select Type to further specify that the access profile will apply an ICMP type value,
or specify Code to further specify that the access profile will apply an ICMP code
value.
Select IGMP to instruct the Switch to examine the Internet Group Management Protocol
(IGMP) field in each frame's header.
•
Select Type to further specify that the access profile will apply an IGMP type value.
Select TCP to use the TCP port number contained in an incoming packet as the forwarding
criterion. Selecting TCP requires that you specify a source port mask and/or a destination
port mask.
•
src port mask - Specify a TCP port mask for the source port in hex form (hex 0x0-
0xffff), which you wish to match.
•
dst port mask - Specify a TCP port mask for the destination port in hex form (hex
0x0-0xffff) which you wish to match.
•
flag bit - The user may also identify which flag bits to match. Flag bits are parts of a
packet that determine what to do with the packet. The user may filter packets by
filtering certain flag bits within the packets, by checking the boxes corresponding to
the flag bits of the TCP field. The user may choose among the urg (urgent), ack
(acknowledgement), psh (push), rst (reset), syn (synchronize), and fin (finish)
options.
•
Select UDP to use the UDP port number contained in an incoming packet as the
forwarding criterion. Selecting UDP requires that you specify a source port mask
and/or a destination port mask.
•
src port mask - Specify a UDP port mask for the source port in hex form (hex 0x0-
0xffff).
•
dst port mask - Specify a UDP port mask for the destination port in hex form (hex
0x0-0xffff).
Protocol ID - Enter a value defining the protocol ID in the packet header to mask. Specify the
protocol ID mask in hex form (hex 0x0-0xff).
