Line Compensation

Line Compensation
Use this procedure to specify the amount of cable loss in decibels. Cable loss
is based on the length of cable between the 100D module and the Channel
Service Unit, as shown below:
1 = 0.6 dB loss
2 = 1.2 dB loss
3 = 1.8 dB loss
4 = 2.4 dB loss
5 = 3.0 dB loss
Summary: Line Compensation
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
6-8 DS1 Facilities
System manager
All
100D module idle
Form 3b, Incoming Trunks: DS1 Connectivity
(100D module)
1 (0.6 dB loss)
1 to 5
No
No
LinesTrunks LS/GS/DS1
Drop Dial line compensation value
Comp
Exit Exit
[F4] [F1] Type slot no.
line compensation value
Dial slot no.
Enter
[F10] [F6] [Alt] + [P]
[F10] [F5] [F5]
Line
Enter
Type
