E&M Signal
E&M Signal
Use this procedure to specify the type of tie trunk signal, as follows:
E&M Mode
— 1S. Type 1 Standard. Tie trunks that are connected through the
local telephone company.
— 1C. Type 1 Compatible. Tie trunks that are connected directly to a
system that uses 1S signaling.
Simplex Mode
— 5. Type 5 Simplex. Tie trunks that are connected to a system using
type 5 signaling.
Summary: E&M Signal
Programmable by
Mode
Idle Condition
Planning Form
Factory Setting
Valid Entries
Inspect
Copy Option
Console Procedure
PC Procedure
System manager
All
Tie trunk idle
Form 3c, Incoming Trunks: Tie
1S
1S, 1C, 5
No
Yes
LinesTrunks TIE Lines
Specify signaling type
Enter
Exit
[F4] [F2] [F4]
signaling type [F10]
E&M Signal
Enter
Type trunk no. [F10]
[F5] [F5]
Dial trunk no.
Exit
Specify
Tie Trunks 7-5
