4-5-15 Brake Confirmation

4-5-16 LAD Cancellation

4-5-17 Pulse Counter Clear

This function is for brake performance. Please refer to chapter 3 for the
detailed description of the function.
Option Terminal
Code Symbol
44
BOK Brake
confirmation
C001~C007
Valid for inputs:
b120~b127, C021~C022
Required settings:
This function is for canceling the set ramp time and changes the output speed
immediately according to the set speed. (Please refer to chapter 3 for the
detailed description of the function.)
Option Terminal
Code Symbol
46
LAC LAD cancel-
lation
C001~C007
Valid for inputs:
Required settings:
This function is for clearing the accumulated pulse numbers in case of posi-
tioning. (Please refer to chapter 3 for the detailed description of the function.)
Option Terminal
Code Symbol
47
PCLR Pulse
counter
clear
C001~C007
Valid for inputs:
Required settings:
Function State
Name
ON Brake confirmation signal is being
given
OFF Brake confirmation signal is not
given
Function State
Name
ON Disabling the set ramp time and
inverter output immediately follows
the speed command.
OFF Accelerates and decelerates
according to the set ramp time
Function State
Name
ON Clears the accumulated pulse
numbers.
OFF Does not clear the pulse numbers.
