LPOD-R Outdoor Amplifier / Block Up Converter
Ethernet Interface Operation
4.4.3.2 Page Navigation
The HTTP Interface has four navigation tabs at the top of
each page. Click a navigation tab to see its page
hyperlinks. Click a page hyperlink to open a page.
This manual uses a convention for all web pages to show you how to navigate to
the featured page: Navigation Tab | Page Hyperlink.
For example, "Home | Home" instructs you to click the 'Home' navigation tab,
and then click the 'Home' page hyperlink.
4.4.3.3 Page Sections
Each page has one or more sections. The title at the
upper-left corner of each page or section describes its
operational features. Each section can have editable
fields, action buttons and read-only displays for a
specific function.
This manual explains the purpose and operation for each Web page and its
sections.
4.4.3.4 Action Buttons
Action buttons are important in the LPOD-R HTTP Interface.
Click an action button to do one of these tasks:
• Refresh the page to see the latest data.
• Reset changed parameters to remove unsaved changes.
• Submit (save) changes.
If you change any parameters, make sure to click the related action
button before you leave the page. If you go to another page without
first clicking the action button, your changes are not saved.
4.4.3.5 Drop-down Lists
A drop-down list lets you choose from a list of selections.
Left-click the drop-down button to open the list. Then, left-
click on an item to select that choice.
4–9
MN-LPODR
Revision 3
