LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
Optional Serial Interface Operation (PS 1, PS 1.5 ONLY)
Controller-to-Target
Instruction Code and
Parameter Type
Qualifier
(* indicates
End-of-Life)
Command Query
SNMP Trap STB= STB?
Destination IP
Address 2
SNMP Trap STV= STV?
Version
SNMP Write SWC= SWC?
Community
Software Revision N/A SWR?
Set RTC Time TIM= TIM?
Heatsink N/A TMP?
Temperature
Retrieve Number N/A TNA?
of unread stored
Alarms*
Arguments for
Command or
Response to
Query
15 bytes, Command or Query.
Numerical Sets or returns the IP Address of the SNMP Trap Destination IP Address 2 in the form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx = IP Address
COMMAND EXAMPLE: <0001/STB=010.006.030.002{CR}
NOTE: When not configured, the Target returns >0001/STB=0.0.0.0{CR}{LF}
1 byte Command or Query.
Sets or returns the SNMP Trap Version that will be used to send traps in the form x, where:
1 = SNMP Trap Version 1
2=SNMP Trap Version 2
COMMAND EXAMPLE: <0001/STV=0{CR}
16bytes, Command or Query.
characters, no Sets or returns the SNMP Write Community string.
spaces COMMAND EXAMPLE: <0001/SWC=private{CR}
NOTE: An empty string is not allowed.
34-37 bytes Query only.
Returns the value of the internal software revision installed in the unit, in the form:
Boot:x.y.z Bulk1:x.y.z Bulk2:x.y.z
-or-
Boot:x.y.zz Bulk1:x.y.zz Bulk2:x.y.zz
6 bytes Command or Query.
Sets or returns the Real-Time-Clock time in the form hhmmss, where:
hh = hours, from 00 to 23;
mm = minutes, from 00 to 59,
ss = seconds, from 00 to 59
COMMAND EXAMPLE (time = 23 hours, 12 minutes and 59 seconds since midnight – i.e., 11:12:59 PM):
<0001/TIM=231259{CR}
5 bytes Query only.
Returns the temperature of the Heatsink in the form sxxxx, where:
s = sign byte, positive or negative (+ or –)
xxxx = temperature (including decimal point)
EXAMPLE: <0001/TMP?{CR}
<0001/TMP=+26.0{CR}{LF}
2 bytes Query only.
Returns the number of stored events that remain unread in the alarm log in the form xx, where:
xx = number from 00 to 99.
NOTE: Although a maximum of 255 events may be stored in the alarm log, event tallies greater than 99 are
reported as 99.
EXAMPLE: <0001/TNA?{CR}
>0001/TNA=14{CR}{LF}
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
5–24
MN-LPODR
Revision 3
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
STB = STB=xxx.xxx.xxx
STB! .xxx
STV = STV=x
STV!
SWC = SWC=x
SWC!
SWR= SWR=Boot:x.y.z
z Bulk1:x.y.zz
Bulk2:x.y.z
TIM = TIM=xxxxxx
TIM?
TIM *
TMP= TMP=sxxxx
TNA= TNA=xx
