LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
Introduction
1.5.2 Environmental
Operating
Temperature
Humidity
Altitude
Shock
1.5.3 Physical
PS .5
Weight
PS 1
PS1.5
PS .5
Dimensions
excluding connectors
PS 1
(See Section 1.6)
PS 1.5
IF/RF Input
RF Output
Connectors
M&C
(Ethernet)
Standard
-40° to 131°F (-40° to 55°C)°
-58° to 131°F (-50° to 55°C) or -40° to 140°F (-40° to
Optional
60°C)
Storage -67° to 167°F (-55° to 75°C)
100% condensing rain 2" per hour
10,000 AMSL
Normal commercial shipping and handling
5 lbs. (2.3 kg) Nominal
17 lbs. (9.1 kg) Nominal
7.21 x 4.65 x 3.34 in. (183.1 x 118.1 x 84.8 mm)
12.60 x 6.31 x 6.05 in. (320.0 x 160.3 x 153.7 mm)
12.78 x 6.14 x 6.47 in. (324.6 x 155.9 x 164.3 mm)
Type 'N' Female
C-Band: CPR137G
PS .5
Ku-Band: WR75G (8W unit), WR75 (16W unit)
C-Band: Type 'N' Female (optional CPR137G)
PS 1
X-Band: CPR112G
Ku-Band: WR75
C-Band: CPR137G
PS 1.5
X-Band: CPR112G
Ku-Band: WR75
PS .5
Weatherized RJ-45
PS 1
Optional 19-pin MS style (single integrated cable
PS 1.5
assembly available, dependent upon configuration)
1–9
MN-LPODR
Revision 3
