LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
Optional Serial Interface Operation (PS 1, PS 1.5 ONLY)
Controller-to-Target
Instruction Code and
Parameter Type
Qualifier
(* indicates
End-of-Life)
Command Query
Management IP IPA= IPA?
Address
Gateway IP IPG= IPG?
Address
Initialize Statistics ISP= N/A
Pointer
Retrieve next 5 N/A LNA?
unread Stored
Alarms*
Arguments for
Command or
Response to
Query
18 bytes Command or Query.
Sets or returns the Management IP Address and network prefix for the 'J6 | COM1' 10/100 BaseT Ethernet
management port, in the form xxx.xxx.xxx.xxx.yy, where:
xxx.xxx.xxx.xxx = the IP Address
yy = the network prefix (8 to 30)
NOTE: Default Value = 192.168.001.004.24
COMMAND EXAMPLE: <0001/IPA=192.168.001.004.24{CR}
CAUTION: Changing the Management IP Address through the Telnet interface requires you to power cycle the
unit, and then restart a new Telnet session with the new IP Address. The IP Address that you type into the Telnet
client software does not include the range parameter so it would be: 192.168.1.4
15 bytes Command or Query.
Sets or returns the Gateway IP Address for the 'J6 | COM1' 10/100 Base Tx Ethernet management port, in the
form xxx.xxx.xxx.xxx, where:
xxx.xxx.xxx.xxx = the IP Address
NOTE: Default Value = 192.168.001.005
COMMAND EXAMPLE: <0001/IPG=192.168.001.005{CR}
None Command only.
Resets the internal pointer to allow RNS? queries to start at the beginning of the stored statistics log. This
command takes no arguments.
EXAMPLE: <0001/ISP={CR}
145 bytes Query only.
Returns the five oldest stored events in the alarm log, in the reply format:
YYYYYYYYYY ZZ mmddyy hhmmss{CR}
YYYYYYYYYY ZZ mmddyy hhmmss{CR}
YYYYYYYYYY ZZ mmddyy hhmmss{CR}
YYYYYYYYYY ZZ mmddyy hhmmss{CR}
YYYYYYYYYY ZZ mmddyy hhmmss{CR}{LF}
Where:
YYYYYYYYYY is the fault description.
ZZ is the event type FT = Fault; OK = Clear; or IF = Information
mmddyy hhmmss = date / time stamp.
NOTE: If there are no events in the log the unit will reply with LNA*. All events that are read from the log are also
automatically removed from the log.
EXAMPLE: <0001/LNA?{CR}
>0001/LNA={CR}
LOG CLR IF 175503 052307{CR}
FAN #1 FT 175504 052307{CR}
OVR TMP FT 175504 052307{CR}
FAN #1 OK 175504 052307{CR}
IIC BUS FT 175504 052307{CR}{LF}
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
5–15
MN-LPODR
Revision 3
Target-to-Controller
(see Description of Arguments)
Response to Response to
Command Query
IPA= IPA=xx.xxx.xxx.
IPA? xxx.yy
IPA*
IPA#
IPG= IPG=xxx.xxx.xxx
IPG? .xxx
IPG*
ISP= N/A
ISP?
ISP*
LNA= LNA=YY..ss
