LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
Optional Serial Interface Operation (PS 1, PS 1.5 ONLY)
Controller-to-Target
Instruction Code and
Parameter Type
Qualifier
(* indicates
End-of-Life)
Command
Query
Concise
N/A
CMS?
Maintenance
Status
Clear Trending
CTD=
N/A
Data
Set RTC Date (by
DAT=
DAT?
Month)*
Set RTC Date (by
DAY=
DAY?
Day)
Arguments for
Command or
Response to
Query
95 bytes
Query only.
Returns the Maintenance status of the unit in a concise format, response is semicolon delimited, in the form
aaa.a;bbb.b;ccc.c;ddd.d;eee.e;fff.f;ggg.g;hh.h;iii.i;jjj.j;kkk.k;lll.l;mmm.m;nnn.n;ooo.o;ppp.p;qqq.q; rrr.r;
sss.s;ttt.t{CR}{LF} where:
aaa.a = P24V1
bbb.b = P24V2 (NOT USED)
ccc.c = LNBVT (NOT USED)
ddd.d = P13VT
eee.e = P10V1
fff.f = A10V1
ggg.g = A10V2 (NOT USED)
hhh.h = P7V8T
iii.i = P5V8T
jjj.j = P2V5T
kkk.k = P1V2T
lll.l = N5V8T
mmm.m = FANR1
nnn.n = FANR2 (PS 1.5 ONLY)
ooo.o = BUCVT (ONLY WHEN BUC OPTION INSTALLED)
ppp.p = FWPWR
qqq.q = REFVT (NOT USED)
rrr.r = LNBCS (NOT USED)
sss.s = ATEMP
ttt.t = OTEMP (PS 1.5 ONLY)
NOTE: This is the condensed version of the RMS query.
Command only.
1 byte
Clears the trending data in the form x, where:
x = 1
EXAMPLE: <0001/CTD=1{cr}
6 bytes
Command or Query.
Sets or returns the date in the form mmddyy, where:
mm = month of the year (01 to 12)
dd = day of the month (01 to 31)
yy = year (00 to 96) (2000 to 2096)
COMMAND EXAMPLE (date = April 25, 2016): <0001/DAT=042516{CR}
6 bytes
Command or Query.
Sets or returns the date in the form ddmmyy, where:
dd = day of the month (01 to 31)
mm = month of the year (01 to 12)
yy = year (00 to 99) (2000 to 2099)
COMMAND EXAMPLE (date = April 25, 2016): <0001/DAY=250416{CR}
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
5–12
MN-LPODR
Revision 3
Target-to-Controller
(see Description of Arguments)
Response to
Response to
Command
Query
CMS=
CMS=x....x
CTD=
CTD=
CTD?
CTD*
DAT=
DAT=mmddyy
DAT?
DAT*
DAY=
DAY=ddmmyy
DAY?
DAY*
