LPOD-R Outdoor Amplifier / Block Up Converter
Ethernet Interface Operation
• The LPOD-R is operating with the latest version firmware files.
• The User PC is running a terminal emulation program for operation of the
LPOD-R Telnet Interface.
• The User PC is running a compatible web browser for operation of the
LPOD-R HTTP Interface.
• The user-supplied Windows PC is connected to the LPOD-R as applicable:
o The 'J6 | COM1' port on the unit connects to the User PC Ethernet
port with a user-provided Ethernet cable that has the available
weatherproof connector kit (CEFD P/N KT-0020707 or KT-
0020708).
o Older versions of the LPOD-R PS 1 and PS 1.5 feature a 19-pin 'J6 |
COM1' port. The unit connects to the User PC Ethernet port with
the available CA-0000352 Ethernet Interface Cable (part of CEFD
Kit KT-0000203).
• You have recorded the LPOD-R's Management IP Address.
4.2 SNMP Interface
SNMP is an Internet-standard protocol for managing devices over IP networks. An
SNMP-managed network has three key components:
• The managed device. This includes the LPOD-R.
• The SNMP Agent. This software runs on the LPOD-R. The LPOD-R SNMP
Agent supports both SNMPv1 and SNMPv2c.
• The user-supplied Network Management System (NMS). This software
runs on the User PC.
4.2.1 Management Information Base (MIB) Files
An MIB file is used for SNMP remote management of a unique device, and
consist of a tree of nodes called Object Identifiers (OIDs). Each OID provides
remote management of a particular function. These MIB files should be compiled
in a user-supplied MIB Browser or SNMP Network Monitoring System server.
In these LPOD-R MIB file names, the letter x represents the revision of the file.
4–2
MN-LPODR
Revision 3
