LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
Optional Serial Interface Operation (PS 1, PS 1.5 ONLY)
Controller-to-Target
Instruction Code and
Parameter Type
Qualifier
(* indicates
End-of-Life)
Command
Query
Auto Fault
AFR=
AFR?
Recovery
RF Power
AMP=
AMP?
Amplifier State
Attenuation
ATT=
ATT?
Clear All Stored
CAA=
N/A
Alarms
Clear All Stored
CAE=
N/A
Events
Arguments for
Command or
Response to
Query
1 byte
Command or Query.
Sets or returns automatic fault recovery in the form x, where:
x = 1 (DEFAULT)
NOTE: The LPOD output automatically mute if the BUC Lock Detect fault condition occurs. If auto fault recovery is
enabled, it will cause the output return to its pre-fault mute condition if all faults are cleared. If disabled, the
output will remain muted even if all faults are cleared
COMMAND EXAMPLE: <0001/AFR=1{CR}
1 byte
Command or Query.
Sets (turns ON or OFF) or returns the RF power amplifiers status in the form x, where:
0 = Off (DEFAULT)
1 = On
NOTE: Turning the amplifier off disables the +10V supply, and masks it during fault checking.
COMMAND EXAMPLE: <0001/AMP=1{CR}
5 bytes
Command or Query.
Sets or returns the valid attenuation level, in dB, in 0.25 dB steps as factory default in the form xx.xx where:
xx.xx = 00.00 to 20.00 (Default Value = 10.00)
COMMAND EXAMPLE: <0001/ATT=12.25{CR}
None
Command only.
Instructs the unit to Clear All stored Alarms. This command takes no arguments.
EXAMPLE: <0001/CAA={CR}
None
Command only.
Instructs the SSPA to Clear All stored Events. This command takes no arguments.
EXAMPLE: <0001/CAE={CR}
Description of Arguments
(Note that all arguments are ASCII numeric codes from 48 to 57)
5–9
MN-LPODR
Revision 3
Target-to-Controller
(see Description of Arguments)
Response to
Response to
Command
Query
AFR=
AFR=x
AFR?
AFR*
AMP=
AMP=x
AMP?
AMP*
ATT=
ATT=xx.xx
ATT?
ATT*
CAA=
N/A
CAA*
CAE=
N/A
CAE*
