LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
System Connectors, Installation, and Startup
2.4.5

KT-0020987 OMT-Mount Installation (PS .5)

Use this kit to install your LPOD-R PS .5 standalone configuration on the antenna
orthomode transducer (OMT).
ITEM QTY CEFD PART NO.
1 1 FP-0021719
2 1 FP-0021720
3 3 HW/8-SPLIT
4 3 HW/832X5/8SHCS
5 2 HW/5/16-18X1.25
6 2 HW/5/16-18HEXNT
7 2 HW/5/16-FLT
8 2 HW/5/16-SPLIT
9 2 HW/8-32HEXNUT
10 2 HW/8-FLT

Figure 2-12. KT-0020987 LPOD-R PS .5 OMT-Mount Installation Kit

DESCRIPTION
BRACKET, LOWER
BRACKET, UPPER
LOCK WASHER, SPLIT, #8
SOCKET HEAD CAP SCREW, 8-32 X 5/8 LG
BOLT, HEX HEAD, 5/16-18 X 1.25 LG
HEX NUT, 5/16-18
FLAT WASHER, 5/16
LOCK WASHER, SPLIT, 5/16
HEX NUT, #8-32
FLAT WASHER, #8
2–22
MN-LPODR
Revision 3
