Pole Mount Installations (Ps 1, Ps 1.5) - Comtech EF Data LPOD-R PS .5 Installation And Operation Manual

LPOD-R Outdoor Amplifier / Block Up Converter (BUC)
System Connectors, Installation, and Startup
2.4.3

Pole Mount Installations (PS 1, PS 1.5)

The Universal Pole Mount Kit PL/12319-1 is used in combination with pole-
mounted standalone installation kits. For purpose of brevity, all subsequent
mention of this kit's usage refers you back to this chapter section.
CHAPTER CEFD PART
SECT. NO.
2.4.3.1 PL/12319-1
2.4.3.2 KT-0000095
DESCRIPTION
Universal Pole Mounting Kit
LPOD-R PS 1, PS 1.5 Single Unit
Mounting Kit
2–15
MN-LPODR
Revision 3
See...
Figure 2-7
Figure 2-8
Figure 2-9
