Audio breakaway — An embedded audio signal can be separated from its
•
corresponding video signal within the switcher, allowing the audio and video signals
from one source to be switched to different destinations
• 32 global presets — Frequently used I/O configurations can be saved and recalled
as global presets either from the front panel, IP Link, or serial control. This allows I/O
configurations to be set up and stored in memory for future use.
• I/O mode viewing — Users can easily view which inputs and outputs are actively
connected.
QuickSwitch Front Panel Controller (QS-FPC) — The DXP front panels provide a
•
discrete button for each input and output.
Tri-color back-lit buttons — The front panel buttons light red, green, or amber,
•
depending on function, for ease of use in low-light environments, and can be custom
labeled for easy identification.
IP Link Ethernet control — The DXP matrix switchers can be monitored and
•
managed over a computer network, using standard TCP/IP protocols. IP Link provides
for remote selection of I/O ties, EDID configuration, and monitoring system status.
RS-232 and RS-422 control — Using serial commands issued from the rear panel
•
Remote RS232/RS422 port or the front panel 2.5 mm TRS Config port, you can control
and configure the DXP switchers via the included Matrix Switchers Control Program, or
integrate the switchers into a control system. Firmware updates can also be installed via
this port.
Simple Instruction Set (SIS
•
basic ASCII code commands that easy programming through a control system via an
RS-232 or RS-422 connection.
Control software — For RS-232, RS-422, and Ethernet remote control via a
•
computer, the Matrix Switchers Control Program is provided with the DXP switcher.
This icon-driven software uses a graphical, drag-and-drop interface to provide easy I/O
configuration and other customization. The control software also offers an emulation
mode for configuration of an offsite switcher; the configuration can then be saved for
future downloading to the switcher.
• Optional remote control — Available as an option is the MKP 2000 or MKP 3000 X-Y
Remote Control Panel, which can be connected via Ethernet or to the Remote RS232/
RS422 port, providing the flexibility to control a DXP matrix switcher from a remote
location.
Front panel security lockout — Front panel lockout (executive mode) prevents
•
unauthorized use in non-secure environments. In lockout mode, a special button
combination is required to unlock operation of the switcher from the front panel.
Rack-mountable 2U, full rack width metal enclosure
•
• Internal universal power supply — The 100-240 VAC, 50-60 Hz, international power
supply provides worldwide power compatibility.
• High-bandwidth Digital Content Protection (HDCP) compliance — The DXP
switchers provide continuous authentication with HDCP-compliant input and output
devices to ensure quick and reliable switching in professional AV environments. This
enables simultaneous distribution of a single source signal to one or more displays.
The DXP switchers support full matrix switching of digital signals with HDCP for copy
protection of digital television broadcasts and high resolution digital video output from
DTV tuners, DVRs, and Blu-ray Disc players.
) commands — The Extron SIS consists of a set of
™
DXP DVI Pro and DXP HDMI Series • Introduction 3
