106 C 5: C
HAPTER ONFIGURING THE

Set Port Frame Mode

P
LATFORM
Set the interface mode of the selected port as SDH or SONET and save to
flash memory. You are prompted to specify a port and a mode.
Command Actions
Enter the menu sequence: (1) SYS: Platform Configuration
Enter a parameter at the prompt
Parameter
Port ID
Frame Mode
Direct access sequence:
Command Result
System action taken:
System message display:
When setting the port frame mode on one of the ports of the OC-3 card,
all four ports are automatically updated, even if only one port was
selected.
Example
Enter:
1 5 3
5.1.1
The following messages are displayed:
The following settings will take place:
Changing port <5.1.1> setting from SONET mode to SDH mode.
Changing port <5.1.2> setting from SONET mode to SDH mode.
Changing port <5.1.3> setting from SONET mode to SDH mode.
Changing port <5.1.4> setting from SONET mode to SDH mode.
Do you really want to do these changes? (Y/N)?
Enter to confirm. The following message is displayed:
y
Setting port frame mode has completed successfully.
(5) IFC: Interface Cards

(3) SFM: Set Port Frame Mode

Format or Range
<slot.group.port> (0.0 - For all)
0 - SDH
1 - SONET
1 5 3 [parameters]
The frame mode of the selected port on the interface
module is set and saved.
Setting port frame mode has completed
successfully.
