Call Parameters
Table 20 shows the call parameters displayed by the command.
Table 20 Call Parameters
Name
Call number
Call Type
Call State
Number of Out
Connections
Priority
CLL (Cell Loss Level)
In Connection VPI
In Connection VCI
In Connection Port
In Connection ATM
Address Member
Out Connection VPI
Out Connection VCI
Out Connection Port
Out Connection ATM
Address Member
Description
This is the unique number that identifies the call.
Whether the call is SVC or PVC, and if it is a point-to-point
or point-to-multipoint call.
When showing a connection of LAN Emulation,
point-to-point indicates use of the control direct VCC (for
LES), or the multicast sent VCC (for BUS).
When showing a connection of point-to-multipoint, it
indicates use of the control distribute VCC (for LES) or
Multicast forward VCC (for BUS).
Whether the call is active or not.
The number of output destinations that the call is routed
to. In a point-to-point call, this is always one; whereas in a
point-to-multipoint call, this number may be greater than
one.
Whether the call cells are transferred through the Switch
using the high priority queue or low priority queue.
The queue saturation level at which cells with their CLP bit
set are discarded. The possible values can be: "no discard
at all"," 20%", "50%", "80%".
The Virtual Path Identifier (VPI) number of the input port.
The Virtual Channel Identifier (VCI) number of the input
port.
The port number of the input port.
The ATM address member of the source. (If the source is
not SVC, this field does not appear.)
The Virtual Path Identifier (VPI) number of the output port.
The Virtual Channel Identifier (VCI) number of the output
port.
The port number of the output port.
The ATM address member of the destination. (If the
source is not SVC, this field does not appear).
