Page 1: User Guide
CoreBuilder 9000 ® ATM Enterprise Switch ® User Guide Software Version 2.00 http://www.3com.com/ Part No. DUA-C9000-1FAA03 1999 Published February...
Page 2: Set External Clock Source
3Com Corporation reserves the right to revise this documentation and to make changes in content from time 95052-8145 to time without obligation on the part of 3Com Corporation to provide notification of such revision or change. 3Com Corporation provides this documentation without warranty, term, or condition of any kind, either implied or expressed, including, but not limited to, the implied warranties, terms, or conditions of merchantability, satisfactory quality, and fitness for a particular purpose.
Page 3: Table Of Contents
BOUT UIDE Conventions Command Description Related Documents CoreBuilder 9000 Documents World Wide Web Site Documents 3Com Facts Automated Fax Service Documents Year 2000 Compliance VERVIEW CoreBuilder 9000 ATM Enterprise Switch ATM Switch Fabric Module Interfaces to ATM Processors Device Management...
Page 4 Vorkehrungen beim Umgang mit dem Modul Installation Installation Prerequisites Installing the Daughter Cards Installing the ATM Interface Module into the Chassis NTEGRATED ETUP CoreBuilder 9000 ATM Enterprise Switch Integrated Fast Setup Setup Procedure Sections Entering Data Navigation Aids Integrated Fast Setup Operation SING THE OCAL...
Page 5 Setting Up for Management Display Current IP Configuration Update IP Address Display Current NMS IP Address Update NMS Address Display Current Default Gateway IP Address Update Default Gateway IP Address Display Current IP Subnet Mask Update IP Subnet Mask Display Current Read Community String Update Read Community String Display Current Write Community String Update Write Community String...
Page 6 Configuring Interface Modules Display Interface Module Slot Occupancy Display Interface Module Card Parameters Enable Interface Set Port Frame Mode Set Port Clock Mode Set Loop Mode Reset Interface Card Logging Out and Rebooting Logout Reboot Configuration Flash Status ATM Features and Software Versions Display ATM Features Display Software Versions LECS ATM Address...
Page 7 ATM Addresses Port Table Display User Management Entities (UME) ATM Addresses at Port Display Static ATM Addresses at Port Display De-registered ATM Addresses at Port Delete All ATM Addresses at Port Add ATM Address to Port Delete ATM Address by Member ID Get ATM Addresses at Port Delete All Inactive Addresses Port Interface Type...
Page 8 Delete All Inactive PVCs Delete All PVC Connections of port NNI Hops Setup Display Maximum NNI Hops Update Maximum NNI Hops Signaling Setup Display VPI/VCI Range Update VPI/VCI Range Display Signaling Protocol Profile Update Signaling Protocol Profile Display Signaling Protocol Version Update Signaling Protocol Version Display Call-Proceeding Enable Value Update Call-Proceeding Enable Value...
Page 9 Signaling Protocol Statistics Display Signaling Protocol Statistics Reset Signaling Counters LAN E ANAGING MULATION LAN Emulation Services Setup Display LAN Emulation Services Status Enable LAN Emulation Services Disable LAN Emulation Services Display LECS Status Enable LECS Disable LECS LAN Emulation Redundancy Setup Display LECS Redundancy Add LECS to LECS-Order Database Delete LECS from LECS-Order Database...
Page 10 Restore Network Topology LECS Database Statistics Reset LECS LAN Emulation Redundancy Assign Redundant LES to ELAN Deassign Redundant LES from ELAN Make Primary LES Active Display Redundant ELANs General Information Display Redundant ELANs Specific Information Display Redundant LES General Information Display Redundant LES Specific Information LES Address Display LES-BUS Addresses...
Page 11 User Plane Control Plane Management Plane Designing ATM Networks ATM Network Examples Classical IP ATM Networks The CoreBuilder 9000 ATM Enterprise Switch with a Workgroup Multiple Switch IP Routed Network LAN Emulation ATM Networks Enterprise Network Headquarters Network ETWORK NTERFACE...
Page 12 Gateway Interface (GWY) Interim InterSwitch Protocol (IISP) E-IISP P ROTOCOL Introducing Enhanced Interim InterSwitch Protocol (E-IISP) IISP vs. E-IISP Features of E-IISP Hierarchy in an E-IISP Network Hierarchic ATM Addressing Configuring Network ATM Addresses Auto-Discovery Auto-Configuration Static Address Registration in E-IISP Planning a Network with E-IISP Hierarchical Topology E-IISP Hierarchic Routing Algorithm...
Page 13 Point-to-Point Calls Point-to-Multipoint Calls Displaying Connections Signaling Sequences Signaling Timers Timer Resolution Signaling AAL SSCOP SSCOP Timers SSCOP Configuration Parameters Call Control Managing Signaling Protocol Parameters Routing — Internal Links E-IISP Hierarchic Routing Algorithm Hop Limit — Avoiding loops Crankback ATM S WITCHING ATM Switching...
Page 14 Unknown Multicast and Broadcast Frames LAN Emulation Statistics Display LAN Emulation Redundancy LANE Services in the CoreBuilder 9000 ATM Switch Fabric Module Redundant LANE Services LECS Redundancy Facility — Configuring the LECS-Order Database LES Redundancy Facility — Configuring the ELAN Topology...
Page 15 Management Information Base (MIB) SNMP Traps Managing by SNMP Access Methods Security Ethernet Encapsulation Type CoreBuilder 9000 ATM Enterprise Switch Service Console WITCH EDUNDANCY Need for a Redundant Switch Fabric Module Identifying the Active Switch Fabric Module Conditions for Switch-over to Redundant Module...
Page 16 DS-3 Physical Layer Interface ATM Layer ATM Cell Structure The ATM Layer Operation and Maintenance (OAM) Physical Layer OAM ATM Layer OAM ATM Adaptation Layer (AAL) AAL1 AAL2 AAL3/4 AAL5 ECHNICAL UPPORT Online Technical Services World Wide Web Site 3Com FTP Site...
Page 17 3Com Bulletin Board Service 3Com Facts Automated Fax Service Support from Your Network Supplier Support from 3Com Returning Products for Repair LOSSARY NDEX ORPORATION IMITED ARRANTY...
Page 19: About This Guide
UIDE The CoreBuilder 9000 ATM Enterprise Switch User Guide provides all the information that you need to configure and set up the CoreBuilder 9000 ATM Enterprise Switch in ATM networking environments. It also provides information about how the CoreBuilder 9000 ATM Enterprise Switch operates in an ATM network.
Page 20: Conventions
BOUT UIDE Table 1 and Table 2 list conventions that are used throughout this guide. Conventions Table 1 Notice Icons Icon Notice Type Description Information note Information that describes important features or instructions Caution Information that alerts you to potential loss of data or potential damage to an application, system, or device Warning Information that alerts you to potential personal injury...
Page 21 Conventions Table 2 Text Conventions (continued) Convention Description Words in italics Italics are used to: Emphasize a point. Denote a new term at the place where it is defined in the text. Identify menu names, menu commands, and software button names. Examples: From the Help menu, select Contents .
Page 22: Command Description
BOUT UIDE Command In Chapters 4 through 9 of this guide, all of the Local Management Description Application (LMA) commands are explained. For each command, a standard format describes the command. Following is a sample of command descriptions: Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup (1) PAS: Password setup...
Page 23 Conventions Table 3 explains the command descriptions presented above:. Table 3 Command Description Sections Section Description Menu sequence The menu options that you select to execute the command, including all the levels and sublevels. Parameters The parameters to enter after the menu sequence and the format to use.
Page 24: Related Documents
3Com Web site and fax services. To order a paper copy of a document that you see on the CD-ROM, or to order additional CDs, contact your sales representative. For a complete list of all CoreBuilder 9000 documents, see the CoreBuilder 9000 Documentation Overview.
Page 25 Related Documents Paper Documents These documents are shipped with the CoreBuilder 9000 chassis: 16-Slot Chassis Quick Installation Guide for the CoreBuilder 9000 Enterprise Switch Instructions for installing the 16-slot chassis in a rack, on a table, or on a shelf, including prerequisites.
Page 26 CoreBuilder 9000 Enterprise Switch Instructions for removing a faulty fan tray and installing a new one in the 7-slot chassis. Chassis ID Printed Circuit Board for the CoreBuilder 9000 Enterprise Switch Information about a chassis ID printed circuit board (PCB).
Page 27: World Wide Web Site Documents
Related Documents Documents on CD-ROM The Documentation CD-ROM contains online versions of the paper guides that are shipped with your chassis and other CoreBuilder 9000 documents in online format only, such as: CoreBuilder 9000 Enterprise Management Engine User Guide How to use the CoreBuilder 9000 Enterprise Management Engine (EME) to manage the chassis and the network modules in the chassis.
Page 28: Year 2000 Compliance
BOUT UIDE Year 2000 For information on the Year 2000 compliance and 3Com products, visit Compliance the 3Com Year 2000 Web page: http://www.3com.com/products/yr2000.html...
Page 29: Overview
Traffic Management ATM Networks Features Standards and Protocols CoreBuilder 9000 The CoreBuilder 9000 ATM Enterprise Switch has two components: ATM Enterprise The ATM Switch Fabric Module Switch The ATM Interface Module For information about the ATM Interface Module, see the ATM Interface Module User Guide and the ATM Interface Module Getting Started Guide.
Page 30: Interfaces To Atm
2 SM = Single Mode Intermediate These cell-based daughter cards are designed to be installed into ATM Interface Modules that are inserted into CoreBuilder 9000 chassis slots. Each ATM Interface Module can accommodate two of the following daughter cards in any combination: OC-3c/STM-1, OC-12c/STM-4, and 155 Mbps-over-UTP5.
Page 31: Processors
CoreBuilder 9000 ATM Enterprise Switch You can install up to 11 ATM Interface Modules in the 16-slot chassis and up to 5 ATM Interface Modules in the 7-slot chassis. You can order the ATM Interface Modules as a kit with daughter cards included or, you can order individual daughter cards separately.
Page 32: Device Management
1: O HAPTER VERVIEW Device Management You can use the CoreBuilder 9000 ATM Enterprise Switch Local Management Application (LMA) or Transcend ® Enterprise Manager (or other SNMP-based network management application) to manage your CoreBuilder 9000 ATM Enterprise Switch. The CoreBuilder 9000 ATM Enterprise Switch LMA is a character-oriented, menu-driven user interface for performing system-level administration.
Page 33: Atm Networks
ATM networks: Classical IP (CLIP) ATM The CoreBuilder 9000 ATM Enterprise Switch is transparent to CLIP and allows you to use CLIP over the ATM network. For a view of the CoreBuilder 9000 ATM Enterprise Switch when CLIP is used over ATM within a network, see Chapter 10.
Page 34: Software Version 2.00 Key Features
1: O HAPTER VERVIEW Software Version The CoreBuilder 9000 ATM Enterprise Switch has the following key 2.00 Key Features features: Distributed output buffering An ATM switching engine that provides full-rate, non-blocking switching for up to 22 OC-12c/STM-4 ATM ports and up to 88...
Page 35: Standards And Protocols Supported
For more information about ATM, see Chapter 10. Protocols The CoreBuilder 9000 ATM Enterprise Switch uses numerous protocols to connect to and communicate with other devices in the network. Among the protocols used is the Integrated Local Management Interface (ILMI), which is used to connect over the user-to-network interface (UNI) and network-to-network interface (NNI), as well as for address registration.
Page 36 1: O HAPTER VERVIEW...
Page 37: Startingu
CoreBuilder 9000 ATM Switch Fabric Module Getting Started Guide. Safety Precautions When you handle components in a CoreBuilder 9000 system, be sure that you follow all safety precautions. To avoid electric shocks, burns, fire or equipment damage, read and follow these warnings: WARNING: Hazardous energy exists within the CoreBuilder 9000 system.
Page 38: Laser And Led Safety Information
Although the data communications LEDs and lasers that are used in this product meet the regulatory requirements for casual exposure to the eye, as with any bright source of bright light, 3Com recommends that you do not look into the light source (Class One Laser/LED Product).
Page 39: Précautions De Sécurité
Précautions de Sécurité Précautions de Lorsque on manipule les éléments du système CoreBuilder 9000, il faut Sécurité bien respecter les précautions de sécurité. Pour éviter des décharges électriques, des brûlures, des incendies ainsi que pour ne pas endommager l’équipement, veuillez bien lire et respecter les précautions suivantes: AVERTISSEMENT: Le système CoreBuilder 9000 contient énergie qui...
Page 40: Précautions De Manipulation
WARNUNG: Halten Sie sich beim Installieren des ATM-Schnittstellen-Moduls zur Gewährleistung des optischen Sicherheit an folgende Vorkehrung: Obwohl die für die Datenkommunikation verwendeten LEDs und Laser-Dioden die Sicherheitsvorkehrungen für zufälligen Augenkontakt erfüllen, entsprechend wie bei anderen hellen Lichtquellen, empfiehlt 3Com nicht direkt in die Lichtquellen zu blicken.
Page 41: Sicherheitsinformationen Für Elektrostatische Entladungen
Vorkehrungen beim Umgang mit dem Modul Sicherheitsinfor- Elektrostatische Entladungen (ESD) können einzelne Baugruppen oder mationen für das gesamte Modul beschädigen. ESD können vorkommen, wenn das Elektrostatische Modul nicht richtig gehandhabt wird und können eine dauerhafte oder Entladungen zeitweilige Fehlfunktion bewirken. VORSICHT: Zur Verhütung von Schäden durch ESD: Vergewissern Sie sich, daß...
Page 42: Installation Prerequisites
16-Slot Chassis Quick Installation Guide for the CoreBuilder 9000 Enterprise Switch or the 7-Slot Chassis Quick Installation Guide for the CoreBuilder 9000 Enterprise Switch. You can install the chassis in a rack, on a shelf, or on a tabletop.
Page 43: Integrated Fast Setup
ANAGEMENT ASKS Chapter 3 Integrated Fast Setup Chapter 4 Using the Local Management Application Chapter 5 Configuring the Platform Chapter 6 Managing Network Interfaces Chapter 7 Configuring Virtual Channels Chapter 8 Viewing Statistics Chapter 9 Managing LAN Emulation...
Page 45: Corebuilder 9000 Atm Enterprise Switch Integrated Fast Setup
ATM Enterprise Enterprise Switch to your site network devices and power has been Switch Integrated applied, you must set some parameters to enable the CoreBuilder 9000 Fast Setup ATM Enterprise Switch with its attached ATM Interface Modules to function in the network.
Page 46: Setup Procedure Sections
2 LE Parameters Set LE parameters for the CoreBuilder 9000 ATM Enterprise Switch 3 LECS Address Set active LECS address for the CoreBuilder 9000 ATM Enterprise Switch 4 UNI/NNI parameters Set UNI/NNI port parameters for ports in the ATM Interface Module...
Page 47: Using The Local Management Application
9000 ATM Enterprise Switch Local Management Application (LMA) to configure and administer the CoreBuilder 9000 ATM Enterprise Switch. A Menu Index shows the command structure of the LMA and refers to the command description for each menu command. You run the LMA from a terminal via a direct RS-232 connection or via Telnet.
Page 48: Lma Access Level
Access level (read, write, admin): Password: When you log in for the first time, simply press Enter at the Password prompt. CAUTION: 3Com strongly recommends that you change passwords for security reasons. For more information, see “Password Setup” on page...
Page 49 Starting Up To log in to the LMA: 1 Enter your access level (default is admin). 2 Enter your password. After a successful login, the Main Menu is displayed as shown in Figure 2. Figure 2 LMA Main Menu CB7000 switch module - Main Menu: ========== (1) SYS: Platform config ->...
Page 50: The Lma Menu System
4: U HAPTER SING THE OCAL ANAGEMENT PPLICATION The LMA Menu The LMA menu system is a set of command menus that are organized in System a hierarchical, top-down fashion. Figure 3 shows the menu structure. Each command menu contains a numbered list of menu items. Each menu item has a three-letter mnemonic identifier and a short description of the item.
Page 51: Selecting Menu Options
The LMA Menu System Selecting Menu To select a menu option, you enter its number or its mnemonic identifier Options at the prompt symbol ( ) that is displayed below the menu item list. You > need to enter the first unique characters of the mnemonic identifier. The hierarchical path from the Main Menu down to the currently displayed submenu option is displayed in front of the angle bracket prompt.
Page 52: Direct Access To Submenus
4: U HAPTER SING THE OCAL ANAGEMENT PPLICATION The Password Setup Menu is displayed as follows, followed by the path and the ( ) prompt. These menu items are all (1)SYS\(1)SET\(1)PAS > configuration commands; none of them have arrows to the right. CB9000 switch module - Password Setup Menu: REA: Set Read-access Password WRI: Set Write-access Password...
Page 53: Entering Multiple Parameters
The LMA Menu System Entering Multiple When a command has more than one parameter, you can enter them all Parameters on the same command line with blanks in between or you can enter some or all of them on separate command lines. If you do not enter them all on one line, you are repeatedly prompted for the remaining parameters.
Page 54: Logging Out
To log out of the LMA, enter at the Main Menu prompt. Automatic Logout The CoreBuilder 9000 ATM Enterprise Switch CoreBuilder 7000 family Switchhas an automatic logout feature. If you do not use the keyboard for 15 minutes, the ATM Switch Fabric Module automatically logs you out.
Page 55 Menu Index (4) SIG: Signaling Setup (1) RES: Timer Resolution setup (1) GET: Get Timer Resolution ......197 (2) SET: Set Timer Resolution.
Page 56: Lan Emulation Menu
4: U HAPTER SING THE OCAL ANAGEMENT PPLICATION (2) FLS: FLASH setup (1) RES: Reset Config to Defaults ......86 (2) RES: Reset All Except IP Addresses to Defaults .
Page 57: Connections Menu
Menu Index (4) REG: Display Redundant ELANs general info ..268 (5) RLG: Display Redundant ELANs specific info ..270 (6) RLG: Display Redundant LESs general info ... . 272 (7) RLS: Display Redundant LES specific info .
Page 58: Statistics Menu
4: U HAPTER SING THE OCAL ANAGEMENT PPLICATION (2) STP: Static ATM Addresses Setup (1) DAD: Delete all ATM Addresses of Port ....140 (2) ADD: Add ATM Address .
Page 59: Configuring The Platform
ONFIGURING THE LATFORM This chapter describes how you configure common management tasks for the CoreBuilder ® 9000 ATM Enterprise Switch platform. For a description of the login procedure, see “Starting Up” on page 47. Password Setup Setting Up for Management Setting the Port Network Connection Type Resetting All Parameters Except IP Addresses Downloading System Software...
Page 60: Password Setup
You can set up the three levels of access passwords to the LMA, or reset all passwords to their factory defaults. CAUTION: 3Com strongly recommends that you change passwords for security reasons. Three access passwords are provided: read-access, write-access and admin-access.
Page 61: Update Read-Access Password
Password Setup Update Read-access Update the read-access password. Enter the new password a second time. Password To accept the default password, press Enter. Command Actions Enter menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (1) PAS: Password Setup (1) REA: Set Read-access Password Enter a parameter at the prompt Parameter...
Page 62: Update Write-Access Password
5: C HAPTER ONFIGURING THE LATFORM Update Write-access Update the write-access password. Enter the new password a second time to confirm your entry. Password To accept the default password, press Enter. Command Actions Enter menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (1) PAS: Password Setup (2) WRI: Set Write-access Password...
Page 63: Update Admin-Access Password
Password Setup Update Admin-access Update the admin-access password. Enter the new password a second time to confirm your entry. You are prompted for the existing password Password before you enter the new password. To accept the default password, press Enter. Command Actions Enter menu sequence: (1) SYS: Platform Configuration...
Page 64: Set Password To Factory Default
LATFORM Set Password to Reset the passwords to their factory default settings for the CoreBuilder 9000 ATM Enterprise Switch. These are, for each type of Factory Default user: read access, write access, and administer access. For more information on access levels, see the CoreBuilder 9000 ATM Switch Fabric Module Getting Started Guide.
Page 65: Setting Up For Management
Setting Up for Management Setting Up for You can set up and display parameters for remotely managing the Management CoreBuilder 9000 ATM Enterprise Switch. The CoreBuilder 9000 ATM Enterprise Switch needs these parameters to communicate via the network. Display Current IP Configuration...
Page 66: Display Current Ip Configuration
5: C HAPTER ONFIGURING THE LATFORM Display Current IP Display the current IP address of the CoreBuilder 9000 ATM Enterprise Configuration Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (2) MNG: Management Setup...
Page 67: Update Ip Address
Setting Up for Management Update IP Address Update the IP address of the CoreBuilder 9000 ATM Enterprise Switch. The default factory IP address is 0.0.0.0. The IP address is changed after the next reboot. Command Actions Enter the menu sequence: (1) SYS: Platform configuration...
Page 68: Display Current Nms Ip Address
5: C HAPTER ONFIGURING THE LATFORM Display Current NMS Display the current NMS IP address where the CoreBuilder 9000 ATM IP Address Enterprise Switch sends event traps. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 69: Update Nms Address
Setting Up for Management Update NMS Address Update the NMS IP address where the CoreBuilder 9000 ATM Enterprise Switch sends the event traps. The factory default NMS address is 255.255.255.255 The NMS IP address is changed after the next reboot...
Page 70: Display Current Default Gateway Ip Address
5: C HAPTER ONFIGURING THE LATFORM Display Current Display the current Default Gateway IP address. The Default Gateway is Default Gateway IP used to locate the network management station (NMS) if the NMS is not Address found in the local IP subnetwork. Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup...
Page 71: Update Default Gateway Ip Address
Setting Up for Management Update Default Update the Default Gateway address. The default factory Default Gateway IP Address Gateway IP address is 151.104.78.20 The default gateway IP address is changed after the next reboot. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (2) MNG: Management Setup (3) GWY: Default Gateway Setup...
Page 72: Display Current Ip Subnet Mask
5: C HAPTER ONFIGURING THE LATFORM Display Current IP Display the current IP subnet mask of the CoreBuilder 9000 ATM Subnet Mask Enterprise Switch. The IP subnet mask is used in conjunction with the IP address. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 73: Update Ip Subnet Mask
Setting Up for Management Update IP Subnet Update the IP subnet mask of the CoreBuilder 9000 ATM Enterprise Mask Switch. The default factory IP subnet mask address is 255.255.255.0 Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 74: Display Current Read Community String
5: C HAPTER ONFIGURING THE LATFORM Display Current Read Display the current Read Community String of the CoreBuilder 9000 ATM Community String Enterprise Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (2) MNG: Management Setup...
Page 75: Update Read Community String
Setting Up for Management Update Read Update the Read Community String of the CoreBuilder 9000 ATM Community String Enterprise Switch. The read community string is updated after the next reboot. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 76: Display Current Write Community String
5: C HAPTER ONFIGURING THE LATFORM Display Current Write Display the current Write Community String of the CoreBuilder 9000 Community String ATM Enterprise Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (2) MNG: Management Setup...
Page 77: Update Write Community String
Setting Up for Management Update Write Update the Write Community String of the CoreBuilder 9000 ATM Community String Enterprise Switch. The write community string is updated after the next reboot. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 78: Display Ethernet Encapsulation Type
HAPTER ONFIGURING THE LATFORM Display Ethernet Display the current Ethernet encapsulation type of the CoreBuilder 9000 Encapsulation Type ATM Enterprise Switch. The Ethernet encapsulation type parameter determines how the CoreBuilder 9000 ATM Enterprise Switch interprets Ethernet frames that enter through the Ethernet management port. For more information, see “Ethernet Encapsulation Type”...
Page 79: Update Ethernet Encapsulation Type
Setting Up for Management Update Ethernet Update the Ethernet encapsulation type of the CoreBuilder 9000 ATM Encapsulation Type Enterprise Switch. The options are: 1-ETH: Standard encapsulation — according to 802.3 0-LLC: Enhanced encapsulation The default Ethernet encapsulation type is 1-ETH.
Page 80: Set Management Configuration To Factory Defaults
5: C HAPTER ONFIGURING THE LATFORM Set Management Reset the management configuration to the factory defaults for the next Configuration to reboot. Factory Defaults Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (2) MNG: Management Setup (8) MNG: Set management configuration to factory defaults Direct access sequence:...
Page 81: Setting The Port Network Connection Type
To do this, you can use either the LMA or the integrated fast Connection Type setup. If you want to use the fast setup, see the CoreBuilder 9000 ATM Interface Module Getting Started Guide. You can set the interface type to NNI, UNI, or GWY.
Page 82 5: C HAPTER ONFIGURING THE LATFORM Example Enter: 1 1 3 3 The following information is displayed for a 16-slot chassis: Port: < 1.1.1> < 1.1.2> < 1.1.3> < 1.1.4> < 1.2.1> < 1.2.2> < 1.2.3> < 1.2.4> Value: Port: <...
Page 83 Setting the Port Network Connection Type Example Enter: 1 1 3 3 The following information is displayed for a 7-slot chassis: Port: < 1.1.1> < 1.1.2> < 1.1.3> < 1.1.4> < 1.2.1> < 1.2.2> < 1.2.3> < 1.2.4> Value: Port: <...
Page 84: Update Port Network Connection Type
ONFIGURING THE LATFORM Update Port Network Update the network connection type (NNI, UNI, or GWY) for a specified port of the CoreBuilder 9000 ATM Enterprise Switch. Connection Type Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 85: Reset Nni Configuration
Setting the Port Network Connection Type Reset NNI Reset the NNI configuration parameters for the CoreBuilder 9000 ATM Enterprise Switch to their factory default settings. The default setting is Configuration UNI for all ports, and 7 for maximum number of hops.
Page 86: Resetting All Parameters
5: C HAPTER ONFIGURING THE LATFORM Resetting All You can reset all parameters for the CoreBuilder 9000 ATM Enterprise Parameters Switch. Reset all configuration parameters for the CoreBuilder 9000 ATM Reset All Enterprise Switch to their factory default settings. Some parameters are reset only after the next reboot. These parameters include ATM addresses, PVC, IP parameters, and NMS parameters.
Page 87: Resetting All Parameters Except Ip Addresses
You can reset the parameters, while leaving the current IP parameters, for Parameters Except the CoreBuilder 9000 ATM Enterprise Switch. IP Addresses Reset configuration parameters for the CoreBuilder 9000 ATM Enterprise Reset All Except IP Addresses Switch to their factory default settings with the exception of the IP parameters.
Page 88: Downloading System Software
5: C HAPTER ONFIGURING THE LATFORM Downloading You can download the system software for the CoreBuilder 9000 ATM System Software Enterprise Switch. Display Software Download Status Download System Software by TFTP Download System Software by Serial Port Upload Switch/LANE Configuration...
Page 89 Download has completed Completed successfully No activity; nothing downloaded Unknown CRC error, download again. If the error Error while downloading persists, contact 3Com technical support. Bad connection No response from server Check cable connection Check if TFTP server is up...
Page 90: Download System Software By Tftp
<file name> Direct access sequence: 1 3 2 [parameters] Command Result System action taken: Software is downloaded by TFTP to the CoreBuilder 9000 ATM Enterprise Switch. System message display: No message is displayed because the process runs in the background.
Page 91: Download System Software By Serial Port
Switch for the software download via the RS-232 port. After the reboot, the Switch changes to the waiting state for the download utilities via RS-232. Operational Returns the CoreBuilder 9000 ATM Enterprise Switch to run after any reboot. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 92: Upload Switch/Lane Configuration
Upload Switch/LANE Upload the Switch configuration or LANE database configuration from Configuration the CoreBuilder 9000 ATM Enterprise Switch to an external host. Specify the server IP address and the target configuration file name. Command Actions. Enter the menu sequence: (1) SYS: Platform Configuration...
Page 93: Download Switch/Lane Configuration
Download Download the Switch and LANE database configuration from an external Switch/LANE host to the CoreBuilder 9000 ATM Enterprise Switch. Specify the server IP Configuration address and the configuration file name. After the configuration has been downloaded, the following operations...
Page 94 Do you really want to continue? y The following prompts are displayed: Server IP address: 151.104.21.147 Enter file name: cfgtest.cfg Start download from 151.104.21.147, cfgtest.cfg (Y/N)? y The following message is displayed: Download process started... The configuration is downloaded to the CoreBuilder 9000 ATM Enterprise Switch.
Page 95: Managing Switch Fabric Modules
Display information about each of the switch fabric modules present. If Module Status there are two switch fabric modules, one is used for standby. See the CoreBuilder 9000 Switch Fabric Module Getting Started Guide for more information about standby Switch Fabric Modules. Command Actions...
Page 96 5: C HAPTER ONFIGURING THE LATFORM Switch Fabric Module Parameters Table 13 describes the switch fabric module parameters displayed by the command. Table 13 Switch Fabric Module Parameters Name Description Slot ID Specifies the slot number in the chassis (slots 8 or 9). The asterisks (***) that appear before the Slot ID indicate to which Switch Fabric Module you are connected.
Page 97: Reset Switch
Do you really want to reboot the switch? [y/n]y The switch is rebooted and the following messages are displayed: Bootstrap V1.10 7 1998 CB9000 3Com NCD ============================ Moving the file from FLASH to DRAM ..Going to operational code ..
Page 98: Reset Standby Switch Fabric Module
Do you really want to reboot the switch? [y/n] y The switch is rebooted and following messages are displayed: Bootstrap V1.10 7 1998 CB9000 3Com NCD ============================ Moving the file from FLASH to DRAM ..Going to operational code ..
Page 99: Set Standby Switch Fabric Module To Suspended/ In-Service Mode
Managing Switch Fabric Modules Set Standby Switch Set the standby switch fabric module to suspended/in-service mode. Fabric Module to When the standby switch fabric module is suspended, it cannot be used Suspended/ In-service to replace the active switch fabric module. Mode Command Actions Enter the menu sequence: (1) SYS: Platform configuration...
Page 100: Upgrade Software Files
5: C HAPTER ONFIGURING THE LATFORM Upgrade Software Upgrade the software on the standby switch fabric module from the Files active switch fabric module. After upgrading, the standby switch fabric module must be reset. See “Reset Standby Switch Fabric Module” on page 98 for details on how to reset the standby switch fabric module.
Page 101: Configuring Interface Modules
Configuring Interface Modules Configuring You can configure parameters for the interface modules of the Interface Modules CoreBuilder 9000 ATM Enterprise Switch. Display Interface Module Slot Occupancy Display Interface Module Card Parameters Enable Interface Set Port Frame Mode Set Port Clock Mode...
Page 102 5: C HAPTER ONFIGURING THE LATFORM Example (for the 16-slot chassis and 7-slot chassis) Enter: 1 5 1 0 Interface Module slot occupancy information for the 16-slot chassis is displayed as follows: Slot id Slot status Interface card type Interface card status ------- ------------ -------------------------...
Page 103: Display Interface Module Card Parameters
Configuring Interface Modules Display Interface Display parameters of an installed interface module. You are prompted to Module Card specify an interface module for display. Parameters Command Actions Enter the menu sequence: (1) SYS: Platform configuration (5) IFC: Interface cards (1) GIF: Get interface card info Enter a parameter at the prompt Parameter Format or Range...
Page 104 5: C HAPTER ONFIGURING THE LATFORM Interface Card Slot Occupancy Parameters Table 15 describes the interface card slot occupancy parameters displayed by the command. Table 15 Interface Parameters Parameter Description Port ID The port ID number for each of the module’s ports in the format slot.group.port.
Page 105: Enable Interface
Configuring Interface Modules Enable Interface Enable interface module port. You are prompted to specify a port. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (5) IFC: Interface Cards (2) EIF: Enable Interface Enter a parameter at the prompt Parameter Format or Range Port ID...
Page 106: Set Port Frame Mode
5: C HAPTER ONFIGURING THE LATFORM Set Port Frame Mode Set the interface mode of the selected port as SDH or SONET and save to flash memory. You are prompted to specify a port and a mode. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (5) IFC: Interface Cards (3) SFM: Set Port Frame Mode Enter a parameter at the prompt...
Page 107: Set Port Clock Mode
Configuring Interface Modules Set Port Clock Mode Set the port clock operational mode of selected port as Internal or External and save to flash memory. You are prompted to specify a port and a mode. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (5) IFC: Interface Cards (4) PCK: Set Port Clock Mode Enter a parameter at the prompt...
Page 108: Set Loop Mode
5: C HAPTER ONFIGURING THE LATFORM Set Loop Mode Set the loop mode of selected port as None, Loop Forward, or Loop Back. You are prompted to specify a port and a mode. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (5) IFC: Interface Cards (5) SLM: Set Loop Mode Enter a parameter at the prompt...
Page 109: Reset Interface Card
Configuring Interface Modules Reset Interface Card Reset the interface module in a specific slot, or all the interface modules. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (5) IFC: Interface Cards (8) RST: Reset Interface Card Enter a parameter at the prompt Parameter Format or Range Slot Number...
Page 110: Logging Out And Rebooting
5: C HAPTER ONFIGURING THE LATFORM Logging Out and You can log out and reboot the CoreBuilder 9000 ATM Enterprise Switch. Rebooting Logout Reboot Logout Log out of the current session. Command Actions Enter the menu sequence: (7) LOG: Logout...
Page 111: Reboot
Logging Out and Rebooting Reboot Reboot the system. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (7) RBO: Reboot Enter a parameter at the prompt Parameter Format or Range Confirm reboot y or n Direct access sequence: Command Result System action taken: Reboots the ATM Enterprise Switch.
Page 112: Configuration Flash Status
Configuration Flash Show status of the configuration flash. When you change the Status configuration of the CoreBuilder 9000 ATM Enterprise Switch, the new configuration is stored in the configuration flash. This command indicates when the new configuration has been successfully stored.
Page 113: Atm Features And Software Versions
You can display the following ATM features and the software version Software Versions number: Display ATM Features Display Software Versions Display ATM Features Display the ATM features available on this CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter the menu sequence: (6) FTR: ATM Features Direct access sequence: Command Result System action taken: Displays ATM features.
Page 114: Display Software Versions
LATFORM Display Software Display the software versions currently installed in the LMA and in the Versions CoreBuilder 9000 ATM Interface Modules. Consult your release notes for latest software version numbers. Command Actions Enter the menu sequence: (8) VER: Version Direct access sequence:...
Page 115: Lecs Atm Address
You can display and update the LAN Emulation Configuration Server (LECS) ATM address. Display LECS ATM Address Update LECS ATM Address Display LECS ATM Display the ATM address of the LECS in the CoreBuilder 9000 ATM Address Enterprise Switch unit. Command Actions Enter menu sequence:...
Page 116: Update Lecs Atm Address
5: C HAPTER ONFIGURING THE LATFORM Update LECS ATM Update the LECS ATM address in the CoreBuilder 9000 ATM Enterprise Address Switch. Command Actions Enter menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (5) SLE: LE Setup (2) LCS: LECS Setup...
Page 117: Setting Up The Switch Clock Source
Setting Up the Switch Clock Source Setting Up the Using this option, you can set up all the parameters to configure and Switch Clock Source synchronize the data speed clocks on different ports of the CoreBuilder 9000 ATM Enterprise Switch to an external clock source. Get Clock Source Status Set External Clock Source 1 Set External Clock Source 2...
Page 118: Set External Clock Source
5: C HAPTER ONFIGURING THE LATFORM Example Enter: 1 8 1 The clock source information is displayed: Active Clock source is EXTERNAL External Clock source port 1 is <1.2.4> active External Clock source port 2 is <5.1.2> standby Set External Clock Set a port to be the first external clock source port.
Page 119: Sp2: Set External Clock Source 2
Setting Up the Switch Clock Source Example Enter: 1 8 2 5.1.2 The following message is displayed: External clock source port 1 was successfully configured to port 5.1.2. Set a port to be the second external clock source port. If the port does Set External Clock not exist, is disabled, is in loop timing mode, loopback or loop forward, it Source 2...
Page 120: Set Clock Source To Internal
5: C HAPTER ONFIGURING THE LATFORM Example Enter: 1 8 3 5.1.2 The following prompt is displayed: This operation will change the active clock source. Do you really want to change it (Y/N)? Y The following message is displayed: External clock source port 2 was successfully configured to port <5.1.2>.
Page 121: Managing Network Interfaces
ANAGING ETWORK NTERFACES This chapter describes how you view and define network interfaces with the CoreBuilder ® 9000 ATM Enterprise Switch. ILMI Setup ATM Addresses Port Table Port Interface Type Network Prefix ILMI Setup You can configure the Interim Local Management Interface (ILMI) with the following options: Display ILMI Version Update ILMI Version...
Page 122: Display Ilmi Version
ANAGING ETWORK NTERFACES Display ILMI Version Display the ILMI version for the specified port of the CoreBuilder 9000 ATM Enterprise Switch. For more information, see “Basic ILMI Functions” on page 324. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 123: Update Ilmi Version
ILMI Setup Update ILMI Version Update the ILMI Version for the specified port in the CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup (8) IME: ILMI Setup (1) VER: ILMI Version Setup (2) SET: Set &...
Page 124: Display Auto-Configuration Status
ANAGING ETWORK NTERFACES Display Display the auto-configuration status for the specified port of the CoreBuilder 9000 ATM Enterprise Switch. Auto-configuration determines, Auto-configuration Status by negotiation, the User-Network Interface (UNI) parameters for the specified port. The configuration options are enabled (auto-configured) or disabled (not auto-configured).
Page 125: Update Auto-Configuration Status
ILMI Setup Update Update the Auto-configuration Status for the specified port in the Auto-configuration CoreBuilder 9000 ATM Enterprise Switch. Enable the Auto-configuration Status Status only if both ATM Switch Fabric Modules have an auto-configuration capability. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 126: Display Lecs Access Options
Display the current communication channel between LEC and LECS for Options the specified port of the CoreBuilder 9000 ATM Enterprise Switch. The LECS-via-ILMI parameter determines whether the LEC that is attached to the port connects to the LECS by ILMI or by the well-known address.
Page 127: Update Lec/Lecs Communication Channel
Update LEC/LECS Update the LECS-via-ILMI parameter for the specified port in the Communication CoreBuilder 9000 ATM Enterprise Switch. If this parameter is enabled, the Channel LEC communicates on the channel VPI/VCI = (0/16) with the ILMI MIB. It submits an inquiry to obtain the LECS address. If this parameter is disabled, the LEC connects to the LECS using the well-known address or via the preconfigured LECS address in the LEC.
Page 128: Display Ilmi Channel Polling Status
Display the ILMI channel polling facility status for the specified port of the Polling Status CoreBuilder 9000 ATM Enterprise Switch. If enabled, the ILMI channel VPI/VCI = (0/16) is periodically polled for connectivity. For more information, see “Status Information” on page 324.
Page 129: Update Ilmi Channel Polling Status
ILMI Setup Update ILMI Channel Update and save the channel polling facility status for the specified port Polling Status in the CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 130: Display Ilmi Channel Polling Interval
Display ILMI Channel Display the ILMI channel polling interval for the specified port of the Polling Interval CoreBuilder 9000 ATM Enterprise Switch. If enabled, the ILMI channel VPI/VCI = (0/16) is periodically polled for connectivity. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 131: Update Ilmi Channel Polling Interval
Update ILMI Channel Update and save the ILMI channel polling interval for the specified port in Polling Interval the CoreBuilder 9000 ATM Enterprise Switch. The minimum value of the polling interval is 30 seconds. The default ILMI polling value is 30 seconds.
Page 132: Atm Addresses Port Table
Delete All Active Addresses Display User Display User Management Entities (UME) registered ATM addresses for Management Entities specified ports of the CoreBuilder 9000 ATM Enterprise Switch. These (UME) ATM ATM addresses were received from end stations or edge devices attached Addresses at Port to the port and registered using ILMI in the MIB address table.
Page 133 ATM Addresses Port Table Command Actions Enter the menu sequence: (3) CON: Connections (1) ADD: Get ATM Addresses (1) UME: Get UME Addresses at Port Enter a parameter at the prompt Parameter Format or Range Port ID <slot.group.port> (0.0 for all ports) Direct access sequence: 3 1 1 [parameters] Command Result...
Page 134 6: M HAPTER ANAGING ETWORK NTERFACES Example Enter: 3 1 1 0.0 The following information is displayed. Note that port 1 of slots 1 and 2 have multiple ATM addresses registered. Port ATM address: Network prefix ATM address:user_part member man ------- --------------------------------------- --------------------- ------ --- <1.1.1>...
Page 135 ATM Addresses Port Table UME Parameters Table 16 describes the UME parameters displayed by the command. Table 16 UME Parameters Name Description Port ID ATM port id. ATM address - Network prefix of ATM address. Network prefix ATM address - User part of ATM address.
Page 136: Display Static Atm Addresses At Port
6: M HAPTER ANAGING ETWORK NTERFACES Display Static ATM Display static ATM addresses registered for the specified port. This command includes ATM addresses that have been entered manually via Addresses at Port LMA or learned addresses over Network-to-Network Interface (NNI) connection (E-IISP).
Page 137 ATM Addresses Port Table Example Enter: 3 1 2 0.0 The following information is displayed: Port ATM address: Network prefix ATM address:user_part member man number number -------- -------------------------------------- -------------------- ------ --- < 2.1.1> 47. *. *. *. *. *. *. *. *. *. *. *. * *.
Page 138: Display De-Registered Atm Addresses At Port
6: M HAPTER ANAGING ETWORK NTERFACES Display De-registered Display UME, static ATM or NNI addresses at the specified port that were de-registered via LMA or UME but whose connections are still active. ATM Addresses at Port Command Actions Enter the menu sequence: (3) CON: Connections (1) ADD: Get ATM Addresses (3) ACT: Get Not Active Registered ATM Addresses at Port...
Page 139 ATM Addresses Port Table Parameters Table 18 describes the parameters displayed by the command. Table 18 Parameters Name Description Port ID ATM port id. ATM address - Network prefix of ATM address. Network prefix ATM address - User part of ATM address. User part Member number The member number is made up of the port ID concatenated with or followed by a sequential number.
Page 140: Delete All Atm Addresses At Port
6: M HAPTER ANAGING ETWORK NTERFACES Delete All ATM Delete the ATM addresses registered at the specified port including those registered by ILMI and those that were created manually through the Addresses at Port LMA. The addresses are deleted from the MIB at the port (they are de-registered).
Page 141: Add Atm Address To Port
ATM Addresses Port Table Add ATM Address to Add an ATM address to the list of registered ATM addresses at a port. Enter the port number and ATM address. Use this command, for Port example, with devices that do not support ILMI; you must add ATM addresses manually to interface with such devices.
Page 142: Delete Atm Address By Member Id
6: M HAPTER ANAGING ETWORK NTERFACES Delete ATM Address Delete the ATM address from the list of registered ATM addresses at a port. The address is deleted from the MIB at the port; in other words, it is by Member ID de-registered.
Page 143: Get Atm Addresses At Port
ATM Addresses Port Table Get ATM Addresses at Get the manual ATM addresses at a specific port. Port Command Actions Enter the menu sequence: (3) CON: Connections (4) S&C: Setup and Config Connections (2) STP: Static ATM Addresses Setup (4) STC: Get ATM Addresses at Port Enter a parameter at the prompt Parameter Format or Range...
Page 144: Delete All Inactive Addresses
6: M HAPTER ANAGING ETWORK NTERFACES Table 19 Parameters (continued) Name Description Member number The member number provides a sequential numbering of ATM addresses registered at a port. It is used to specify the connection. Always set to YES. Delete All Inactive Delete all ATM addresses that do not exist for the port but are currently Addresses present in flash memory.
Page 145: Port Interface Type
Reset NNI Configuration See Chapter 11 for more information about port interface types. Display Port Interface Display the interface type for each port of the CoreBuilder 9000 ATM Type Enterprise Switch. The interface type is Gateway (GWY), User to Network Interface (UNI) or Network to Network Interface (NNI).
Page 146 6: M HAPTER ANAGING ETWORK NTERFACES Example Enter: 1 1 3 3 The following information is displayed: Port: < 1.1.1> < 1.1.2> < 1.1.3> < 1.1.4> < 1.2.1> < 1.2.2> < 1.2.3> < 1.2.4> Value: Port: < 2.1.1> < 2.1.2> < 2.1.3> < 2.1.4> < 2.2.1> < 2.2.2> < 2.2.3> < 2.2.4> Value: Port: <...
Page 147: Update Port Interface Type
Port Interface Type Update Port Interface Update the Interface Type (NNI, UNI, or GWY) for a specified port of the Type CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 148: Reset Nni Configuration
ANAGING ETWORK NTERFACES Reset NNI Reset the NNI configuration parameters for the CoreBuilder 9000 ATM Configuration Enterprise Switch to their factory default settings. The default setting is UNI for all ports, and 7 for maximum number of hops. The reset takes place after the next reboot.
Page 149: Network Prefix
Reset Network Prefix Configuration For more information about the use of Network Prefix, see “Hierarchic ATM Addressing” on page 336. Display Network Display the Network Prefix of the CoreBuilder 9000 ATM Enterprise Prefix Switch. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 150: Update Network Prefix
6: M HAPTER ANAGING ETWORK NTERFACES Update Network Update the Network Prefix in the CoreBuilder 9000 ATM Enterprise Prefix Switch. The prefix update takes place after the next reboot. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 151: Reset Network Prefix Configuration
Network Prefix Reset Network Prefix Reset the network prefix configuration parameters for the Configuration CoreBuilder 9000 ATM Enterprise Switch to their factory default settings. The default setting is 47.00.00.00.00.00.3c.00.60.9*. The reset takes place after the next reboot. Command Actions Enter the menu sequence: (1) SYS: Platform Configuration...
Page 152 6: M HAPTER ANAGING ETWORK NTERFACES...
Page 153: Configuring Virtual Channels
ONFIGURING IRTUAL HANNELS This chapter describes how to configure ATM virtual channels. Display ATM Addresses Display Call Routing Display Port Connections Create Permanent Virtual Channel (PVC) NNI Hops Setup Signaling Setup Signaling Timers...
Page 154: Display Atm Addresses
7: C HAPTER ONFIGURING IRTUAL HANNELS Display ATM You can display information about ATM addresses at different ports. Addresses Display UME Display the UME address at a specific port or at all ports. Addresses at Port Command Actions Enter the menu sequence: (3) CON: Connections (1) ADD: Get ATM addresses (1) UME: Get UME addresses at port Enter a parameter at the prompt...
Page 155: Display Static And Nni Addresses At Port
Display ATM Addresses Display Static and Display the static addresses (which are the manually entered ATM NNI Addresses at Port addresses) and NNI addresses at a specific port or at all ports. Command Actions Enter the menu sequence: (3) CON: Connections (1) ADD: Get ATM addresses (2) STC: Get static and NNI addresses at port...
Page 156: Display Non-Active Atm Addresses At Port
7: C HAPTER ONFIGURING IRTUAL HANNELS Display Non-Active Display the non-active registered ATM addresses at a specific port or at all ATM Addresses at ports. Port Command Actions Enter the menu sequence: (3) CON: Connections (1) ADD: Get ATM addresses (3) ACT: Get Not active registered ATM addresses at port Enter a parameter at the prompt...
Page 157: Display Call Routing
PVC, specify the port number (slot.group.port). Calls routed to an ATM address are differentiated by their Call number. The Call number is allocated by the CoreBuilder 9000 ATM Enterprise Switch during the time the call is initiated and uniquely identifies the call in the CoreBuilder 9000 ATM Enterprise Switch.
Page 158: Rtg: Routing (1) Cll: Calls
7: C HAPTER ONFIGURING IRTUAL HANNELS Command Actions Enter the menu sequence: (3) CON: Connections (2) RTG: Routing (1) CLL: Calls Enter a parameter at the prompt Parameter Format or Range For SVC: ATM address <slot group port> sequential number member For example: 11102 For PVC: Port number...
Page 159 Display Call Routing Example — Display all SVC Calls for an ATM address member Enter: 3 2 1 11102 0 Information for all calls with ATM address member 11102 (the second ATM address registered at port 1.1.1) are displayed. Note that both calls with the ATM address member as input connection and output connection are displayed.
Page 160 7: C HAPTER ONFIGURING IRTUAL HANNELS Example — Display all PVC Calls for a Port Enter: 3 2 1 1.1.1 The list of all calls at port 1.1.1 is displayed. There is one P2M call with two additional destinations. Call Call Call Pri Cll In conn In...
Page 161 Display Call Routing Call Parameters Table 20 shows the call parameters displayed by the command. Table 20 Call Parameters Name Description Call number This is the unique number that identifies the call. Call Type Whether the call is SVC or PVC, and if it is a point-to-point or point-to-multipoint call.
Page 162: Display Port Connections
7: C HAPTER ONFIGURING IRTUAL HANNELS Display Port You can display the port ATM connections. Connections Display UME Address Port Connection Display Static Address Port Connection Display Inactive Address Port Connections For information about establishing port connections, see “External Links —...
Page 163 Display Port Connections Example — Display all Connections at a Port Enter: 3 3 1 1.1.1 Multiple ATM addresses at the port 1.1.1 are displayed where each ATM address has multiple SVCs defined by their VPI/VCI values. Conn Call Port Member Conn Conn Oper...
Page 164 7: C HAPTER ONFIGURING IRTUAL HANNELS Example — Display Info for a Connection at a Port Enter: 3 3 1 1.1.1 3 200 The information for the connection 0/46 at port 1.1.1 is displayed. Connection number: Call number: Port: Connection type: PVC,P2P Connection VPI: Connection VCI:...
Page 165: Display Static Address Port Connection
Display Port Connections Table 21 Port SVC Connection Parameters (continued) Name Description Originator Specifies if the connection is originated at the calling UNI or the called UNI. Specifies the action which is to be performed on the CLP bit. The possible values are: clear bit (0), set bit (1), or no change (N).
Page 166 7: C HAPTER ONFIGURING IRTUAL HANNELS Example Enter: 3 3 2 3.1.2 The following information is displayed: Conn Call Port Member Conn Conn Oper Admin Originator number number number number type VPI/VCI status status ----- ----- -------- ------ ------- ------- -------- -------- ---------- <1.1.1>...
Page 167: Display Inactive Address Port Connections
Display Port Connections Display Inactive Display a connection relating to a specific VPI/VCI of the port or all Address Port connections related to de-registered addresses. Connections Command Actions Enter the menu sequence: (3) CON: Connections (3) PRT: ATM ports (3) ACT: Not active addresses Enter a parameter at the prompt Parameter Format or Range...
Page 168: Create Permanent Virtual Channel (Pvc)
7: C HAPTER ONFIGURING IRTUAL HANNELS Create Permanent The following commands allow you to create a PVC: Virtual Channel Display PVC VPI/VCI Limits (PVC) Create PVC — Full Setup Create PVC — Quick Setup Add PVC Destination Release PVC Release PVC Destination Display PVCs Delete All Inactive PVCs Delete All PVC Connections of Ports...
Page 169: Create Pvc - Full Setup
Create Permanent Virtual Channel (PVC) Create PVC — Full Set up a PVC (permanent virtual connection). Requires all parameters for Setup a PVC to be defined. You must create a PVC for each port-to-port connection in your ATM network. (For more information, see “Permanent Virtual Channels”...
Page 170 7: C HAPTER ONFIGURING IRTUAL HANNELS Command Actions Enter the menu sequence: (3) CON: Connections (4) S&C: Setup of Connections and ATM Addresses (1) PVC: PVCs Setup (1) GET: Display VPI/VCI Limits (2) CRF: Create full PVC call Enter a parameter at the prompt Parameter Format or Range Call type...
Page 171 Create Permanent Virtual Channel (PVC) Command Result System action taken: A full PVC with the required parameters is created. System message display: A new PVC was created with call number: <n> Example Enter: 3 4 1 1 2 p2p 0 0 0 5.1.2 1 55 1 5.1.4 0 60 The following message is displayed: A new PVC was created with call number: Port Static Connection Parameters...
Page 172: Create Pvc - Quick Setup
7: C HAPTER ONFIGURING IRTUAL HANNELS Create PVC — Quick Set up PVC using the default for parameters not explicitly set. Default values for Cell Loss Level, Priority, and Cell Loss Priority are used. (See Setup Table 23.) The same limits as full PVC call setup apply. For more information, see “Permanent Virtual Channels”...
Page 173: Add Pvc Destination
Create Permanent Virtual Channel (PVC) Add PVC Destination Create an additional destination connection (branch) for an existing point-to-multipoint PVC. You can only create an additional destination if the existing PVC was predefined as a PLM PVC. Enter the call number of the original PVC setup and the parameters: output port number, VPI/VCI and CLP, with the same permissible values.
Page 174 7: C HAPTER ONFIGURING IRTUAL HANNELS Command Result System action taken: An additional PVC destination with parameters specified is created. System message display: A new output VC was created with call number: <n> out connection number: <n> Example Enter: 3 4 1 1 4 9 5.1.4 The following message is displayed: A new output VC was created with call number:...
Page 175: Release Pvc
Create Permanent Virtual Channel (PVC) Release PVC Release a specified PVC. PVCs must be manually released. When a P2M PVC is released, all additional destination connections are also released. You cannot release SVCs with this menu. In a P2M (point-to-multi-point call), this option releases all of its branches that belong to the call number that you enter.
Page 176: Release Pvc Destination
7: C HAPTER ONFIGURING IRTUAL HANNELS Release PVC Release a single destination connection (branch) from a Destination point-to-multipoint call. Specify the P2M call number and the output port number and VPI/VCI of the destination connection. Command Actions Enter the menu sequence: (3) CON: Connections (4) S&C: Setup of Connections and ATM Addresses (1) PVC: PVCs Setup...
Page 177 Create Permanent Virtual Channel (PVC) Example Enter: 3 4 1 1 6 1 1.1.4 1 60 The following message is displayed: An Outgoing VC with call number: VPI: VCI: was released. The additional connection with output port 1.1.4 and VPI/VCI values of 1/60, which was added to the P2M connection with call number 1, is released.
Page 178: Display Pvcs
7: C HAPTER ONFIGURING IRTUAL HANNELS Display PVCs Display the PVCs for a specific port and call number. Command Actions Enter the menu sequence: (3) CON: Connections (4) S&C: Setup of Connections and ATM Addresses (1) PVC: PVCs Setup (1) GET: Display VPI/VCI Limits (7) GEP: Display PVCs Enter a parameter at the prompt Parameter...
Page 179: Delete All Inactive Pvcs
Create Permanent Virtual Channel (PVC) Delete All Inactive Delete all PVCs that are inactive. A PVC that does not contain a card is PVCs inactive. Command Actions Enter the menu sequence: (3) CON: Connections (4) S&C: Setup of Connections and ATM Addresses (1) PVC: PVCs Setup (1) GET: Display VPI/VCI Limits...
Page 180: Delete All Pvc Connections Of Port
7: C HAPTER ONFIGURING IRTUAL HANNELS Delete All PVC Delete all the PVC connections for a specific port. Connections of port Command Actions Enter the menu sequence: (3) CON: Connections (4) S&C: Setup of Connections and ATM Addresses (1) PVC: PVCs Setup (1) GET: Display VPI/VCI Limits (9) RES: Delete all PVCs of port Enter a parameter at the prompt...
Page 181: Nni Hops Setup
NNI Hops Setup NNI Hops Setup The following commands allow you to configure the NNI hops parameter: Display Maximum NNI Hops Update Maximum NNI Hops For more information about hops, see “Hop Limit — Avoiding loops” on page 370. Display Maximum Display the maximum number of hops permissible for NNI routing.
Page 182: Update Maximum Nni Hops
Enter the new Maximum NNI Hops parameter to update the Maximum NNI Hops NNI Hops parameter of the CoreBuilder 9000 ATM Enterprise Switch. The choice of parameter value depends on the size and topology of the network. For a hierarchically designed network, it is normally chosen to be 7.
Page 183: Signaling Setup
Signaling Setup Signaling Setup The following commands allow you to configure the ILMI signaling parameters: Display VPI/VCI Range Update VPI/VCI Range Display Signaling Protocol Profile Update Signaling Protocol Profile Display Signaling Protocol Version Update Signaling Protocol Version Display Call-Proceeding Enable Value Update Call-Proceeding Enable Value Reset Signaling Configuration For information about signaling setup, see “Signaling —...
Page 184: Display Vpi/Vci Range
If an end station or edge device is attached to the port, it frequently has limits on the VPI/VCI channels it can handle; you must set the CoreBuilder 9000 ATM Enterprise Switch port to match these limits.
Page 185 Signaling Setup Example Enter: 1 1 4 3 1 3.1.2 The following information is displayed for an OC-3c port: VPI/VCI ranges Param number Param name Param value -------- ------------------------------ ----------- Min vpi Max vpi Min vci Max vci The following information is displayed for an OC-12c port: VPI/VCI ranges Param number Param name Param value...
Page 186: Update Vpi/Vci Range
7: C HAPTER ONFIGURING IRTUAL HANNELS Update VPI/VCI Update the VPI/VCI configuration parameters of the specified port. You Range set maximum and minimum VPI/VCI values for each port. For more information, see “Display VPI/VCI Range” on page 184. Note that when the ILMI auto-configuration procedure is enabled, the VPI/VCI limits are determined automatically and override any settings made by this command.
Page 187: Display Signaling Protocol Profile
It can be Network, User, or Gateway. The CoreBuilder 9000 ATM Enterprise Switch Gateway = IISP. When the port is connected to an end station or edge device, the port is normally defined as Network; when it is connected to another switch, it is defined automatically as User or Network depending on their network prefixes.
Page 188 7: C HAPTER ONFIGURING IRTUAL HANNELS Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup (4) SIG: Signaling setup (5) SPS: Signaling protocol configuration setup (1) GPR: Get profiles of ports Direct access sequence: 1 1 4 5 1 Command Result System action taken: The current signaling protocol profile is displayed for...
Page 189 Signaling Setup Example Enter: 1 1 4 5 1 The following message is displayed. Note that Net refers to a Network side; Usr refers to a User side. Slots 1-5 are displayed. Profile: Port number: <1.1.1> <1.1.2> <1.1.3> <1.1.4> <1.2.1> <1.2.2> <1.2.3> <1.2.4> Current val: Val for save: Next reb val:...
Page 190: Update Signaling Protocol Profile
7: C HAPTER ONFIGURING IRTUAL HANNELS Update Signaling Update the signaling protocol profile for the selected port. See the Protocol Profile previous section for details. This command causes the new Signaling Protocol Parameters to be activated in the current session, and the new value is stored in flash.
Page 191: Display Signaling Protocol Version
Signaling Setup Display Signaling Display the current signaling protocol version for the specified port. It can Protocol Version be either version 3.0 or version 3.1. Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup (4) SIG: Signaling setup (5) SPS: Signaling protocol configuration setup (3) GVP: Get protocol version...
Page 192 7: C HAPTER ONFIGURING IRTUAL HANNELS Protocol Version Parameters Table 24 shows the protocol version parameters displayed by the command. Table 24 Protocol Version Parameters Name Description Port number Number of port on which the protocol version is being set. Value The active protocol version: 3.0 or 3.1.
Page 193: Update Signaling Protocol Version
Signaling Setup Update Signaling Update the signaling protocol version of the ports of the Protocol Version CoreBuilder 9000 ATM Enterprise Switch and save it to flash. Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup...
Page 194: Display Call-Proceeding Enable Value
7: C HAPTER ONFIGURING IRTUAL HANNELS Display Display the value of the call-proceeding enable value. Call-Proceeding With the call-proceeding enable value, the user can suppress the Enable Value message that is returned to the edge device or end call-proceeding user that has sent a signaling SETUP message. For more information, see “CALL PROCEEDING Message”...
Page 195: Update Call-Proceeding Enable Value
Signaling Setup Update Update the signaling call-proceeding enable flag and save it to flash Call-Proceeding memory. See the previous section for more details. Enable Value Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup (4) SIG: Signaling setup (6) CCL: Signaling call control setup (2) SET: Set call proceeding value...
Page 196: Reset Signaling Configuration
IRTUAL HANNELS Reset Signaling Reset the signaling configuration parameters for the CoreBuilder 9000 Configuration ATM Enterprise Switch to their factory default settings. All signaling timers are set to default as UNI and the UNI version is set to 3.0. The reset takes effect immediately.
Page 197: Signaling Timers
When the timer resolution is changed, all of the signaling timers are affected. The CoreBuilder 9000 ATM Enterprise Switch is shipped with a default timer resolution of 500 msec (0.5 secs). To change the value of an individual timer, change the timer resolution proportionally.
Page 198 7: C HAPTER ONFIGURING IRTUAL HANNELS Command Actions Enter the menu sequence: (1) SYS: Platform configuration (1) SET: Switch setup (4) SIG: Signaling setup (1) RES: Timer Resolution setup (1) GET: Get Timer Resolution 1 1 4 1 1 Direct access sequence: Command Result System action taken: The current timer resolution for the signaling protocol...
Page 199: Update Protocol Timer Resolution
Signaling Timers Update Protocol Update the timer resolution of the CoreBuilder 9000 ATM Enterprise Timer Resolution Switch. The default timer resolution is 500 msec (0.5 secs); the minimum timer resolution is 100 msec and there is no upper limit. For more information, see the previous section and see “Timer Resolution”...
Page 200: Display Uni Signaling Timers
7: C HAPTER ONFIGURING IRTUAL HANNELS Display UNI Signaling Display the current Q93B signaling timer values in seconds. These values Timers are the same for all ports because they all work on a common timer. Enter any port identifier. To alter these values, update the timer resolution. For more information, see “Update Protocol Timer Resolution”...
Page 201 Signaling Timers Example Enter: 1 1 4 2 3.1.2 The following information is displayed, showing each message/timer name and its value in seconds: Timers(sec): Param number Param name Current value -------- ------------------------------ ------- q93b_t303 q93b_t308 q93b_t310 q93b_t313 q93b_t316 q93b_t316c q93b_t317 q93b_t322 q93b_t398 q93b_t399...
Page 202: Display Qsaal Signaling Timers And Protocol Configuration
7: C HAPTER ONFIGURING IRTUAL HANNELS Display QSAAL Display the current QSAAL signaling protocol timer values and Service Signaling Timers and Specific Connection-Oriented Protocol (SSCOP) configuration parameters Protocol for the specified port. The timer values are displayed in tenths of a Configuration second.
Page 203 Signaling Timers Table 25 SSCOP Timers (continued) SSCOP Timer Description No-Response Maximum time between receipt of a STAT PDU in an active connection. The connection control timer determines the time between transmission of BGN, END, or RS PDUs, as long as an acknowledgment PDU has not been received.
Page 204 7: C HAPTER ONFIGURING IRTUAL HANNELS Example Enter: 1 1 4 4 3.1.2 The following information is displayed (1-9 are timers, 10-13 are configuration parameters): Signaling QSAAL Timers(Tenths of second): for port <3.1.2> Param number Param name Current value -------- ------------------------------ ------- Poll UNI 3.0 Keep alive UNI 3.0 No response UNI 3.0...
Page 205: Viewing Statistics
IEWING TATISTICS This chapter contains detailed descriptions of common management tasks for viewing statistics of traffic flow in the CoreBuilder ® 9000 ATM Enterprise Switch platform. Physical Layer Statistics ATM-Layer Statistics AAL5-Layer Statistics AAL5 Control Frame Port Statistics Signaling Protocol Statistics Physical Layer You can: Statistics...
Page 206 8: V HAPTER IEWING TATISTICS Example Enter: 4 1 1 1.1.1 The following information is displayed: SONET section level BIP errors (B1): SONET line level BIP errors (B2): SONET path level BIP errors (B3): SONET loss of signal state (LOS): SONET loss of frame state (LOF): SONET loss of pointer state (LOP): SONET out of cell delineation state (OCD):...
Page 207 Physical Layer Statistics Table 27 Physical Layer Statistics (continued) Statistic Description SONET path alarm indication signal state (Path AIS) The AIS is an all-ONES characteristic or adapted information SONET line alarm indication signal state (Line AIS) signal. It is generated to replace the normal traffic signal when it contains a defect condition in order to prevent consequential downstream failures being declared or alarms being raised.
Page 208: Reset Physical Layer Statistics
8: V HAPTER IEWING TATISTICS Reset Physical Layer Reset physical layer statistics for a specified port. Statistics Command Actions Enter the menu sequence: (4) STS: Statistics (1) PHY: Physical Layer (2) RST: Reset phys layer counters Enter a parameter at the prompt Parameter Format or Range Port ID...
Page 209: Atm-Layer Statistics
For more information on ATM statistics, see “Traffic Statistics” on page 373. Display Total Calls in Display the total number of calls existing in the CoreBuilder 9000 ATM Switch Enterprise Switch presented according to type of channel, SVC or PVC, and type of call, P2P or P2M.
Page 210 8: V HAPTER IEWING TATISTICS Example Enter: 4 2 1 The following information is displayed: Calls summary: -------------- Total number of PVC P2P calls: Total number of PVC P2M calls: Total number of SVC P2P calls: Total number of SVC P2M calls:...
Page 211: Display Counters Per Port
ATM-Layer Statistics Display Counters Per Display counters for a specified port or for all ports. Port Command Actions Enter the menu sequence: (4) STS: Statistics (2) ATM: ATM Layer (2) GPR: Get Counters Per Port Direct access sequence: 4 2 2 Command Result System action taken: Calls summary information is displayed.
Page 212: Display Counters Per Vpi/Vci
8: V HAPTER IEWING TATISTICS Display Counters Per Display total cells through a connection specified by its VPI/VCI, presented VPI/VCI according to the setting of the CLP bit. If the call is P2M (Point to Multipoint), the transmit or receive information is not always applicable. Command Actions Enter the menu sequence: (4) STS: Statistics (2) ATM: ATM layer...
Page 213: Reset Counters Per Port
ATM-Layer Statistics Reset Counters Per Reset the statistics counter for total cells through a port. For more Port information, see “Display Total Calls in Switch” on page 209. Command Actions Enter the menu sequence: (4) STS: Statistics (2) ATM: ATM layer (4) RPR: Reset counters per port Enter a parameter at the prompt Parameter...
Page 214: Reset Counters Per Vpi/Vci
8: V HAPTER IEWING TATISTICS Reset Counters Per Resets the statistics counter for total cells through a connection. For more VPI/VCI information, see “ATM-Layer Statistics” on page 209. Command Actions Enter the menu sequence: (4) STS: Statistics (2) ATM: ATM layer (5) RVP: Reset counters per vpi/vci Enter a parameter at the prompt Parameter...
Page 215: Aal5-Layer Statistics
Reset AAL-Layer Statistics For more information on AAL5 statistics, see “Traffic Statistics” on page 373. Display AAL-Layer Display AAL-Layer statistics for the CoreBuilder 9000 ATM Enterprise Statistics Switch. AAL connections and SAR frame statistics are presented. Command Actions Enter the menu sequence: (4) STS: Statistics (3) AAL: AAL5 layer (1) GET: Get AAL &...
Page 216 8: V HAPTER IEWING TATISTICS Example Enter: 4 3 1 The following information is displayed: AAL COUNTERS: ============= Max connections: 5316 Active connections: SAR MEMORY SIZE: ================ SSRAM size: 512Kb SDRAM size: SAR COUNTERS: ============= RX correct frames: TX correct frames: RX CRC-32 ERR frames: RX Length ERR frames: RX Zero Length ERR frames:...
Page 217: Reset Aal-Layer Statistics
AAL5-Layer Statistics Reset AAL-Layer Reset the AAL-Layer statistics for the CoreBuilder 9000 ATM Enterprise Statistics Switch. Command Actions Enter the menu sequence: (4) STS: Statistics (3) AAL: AAL5 layer (2) RST: Reset AAL & SAR counters Direct access sequence: 4 3 2...
Page 218: Aal5 Control Frame Port Statistics
8: V HAPTER IEWING TATISTICS AAL5 Control Frame You can display the following AAL5 control statistics: Port Statistics Display Control Frame Port Statistics Reset Control Frame Port Statistics For information about AAL5-layer control, see “Signaling AAL” on page 364. Display Control Display control frame statistics for a specified port.
Page 219 AAL5 Control Frame Port Statistics Example Enter: 4 4 1 1.1.1 The following information is displayed: Port number: <1.1.1> SIGNALING ILMI ----------- ------ Max transmit SDU size in bytes: Number of transmitted SDUs: Max received SDU size in bytes: Number of SDUs received without errors: Number of PDUs received with CRC-32 errors: Number of oversized PDUs: Number of buffers shortage errors:...
Page 220: Reset Control Frame Port Statistics
8: V HAPTER IEWING TATISTICS Reset Control Frame Resets control frame statistics for a specified port. Port Statistics Command Actions Enter the menu sequence: (4) STS: Statistics (4) CTL: Control Frames (2) RST: Reset Control Frames Counters Enter a parameter at the prompt Parameter Format or Range Port ID...
Page 221: Signaling Protocol Statistics
Signaling Protocol Statistics Signaling Protocol You can display the following signaling statistics: Statistics Display Signaling Protocol Statistics Reset Signaling Counters For information about signaling protocol, see “Signaling Protocol” on page 355. Display Signaling Display the signaling protocol statistics for a specified port. The number Protocol Statistics of signaling messages is presented according to transmitted and received messages.
Page 222 8: V HAPTER IEWING TATISTICS Example Enter: 4 5 1 1.1.1 The following information is displayed: Number of Number of messages transmitted messages received -------------------- ----------------- Call proceeding Connect Connect acknowledge Setup Release Release complete Restart Restart acknowledge Status Status inquiry Add party Add party acknowledge Add party reject...
Page 223: Reset Signaling Counters
Signaling Protocol Statistics Reset Signaling Resets the signaling counters for a specified port. Counters Command Actions Enter the menu sequence: (4) STS: Statistics (5) SIG: Signaling (2) RST: Reset signaling counters Enter a parameter at the prompt Parameter Format or Range Port ID <slot.group.port>...
Page 224 8: V HAPTER IEWING TATISTICS...
Page 225: Managing Lan Emulation
LAN E ANAGING MULATION This chapter describes how to configure LAN Emulation (LANE) in the CoreBuilder ® 9000 ATM Enterprise Switch. LAN Emulation Setups LAN Emulation Services Setup LAN Emulation Redundancy Setup LAN Emulation Configuration Service (LECS) Operations LECS Address LECS Search Policy LECS ELAN Database Operations LAN Emulation Redundancy...
Page 226: Lan Emulation Services Setup
9: M LAN E HAPTER ANAGING MULATION LAN E MULATION ETUPS LAN Emulation You can set up the LAN Emulation services, as follows: Services Setup Display LAN Emulation Services Status Enable LAN Emulation Services Disable LAN Emulation Services Display LECS Status Enable LECS Disable LECS CAUTION: Before you reboot the Switch, wait for one minute after each...
Page 227: Display Lan Emulation Services Status
LAN Emulation Services Setup Display LAN Display the status of the LAN Emulation services in the CoreBuilder 9000 ATM Enterprise Switch. The status is either enabled or disabled. Emulation Services Status Command Actions Enter menu sequence: (1) SYS: Platform config...
Page 228: Enable Lan Emulation Services
9: M LAN E HAPTER ANAGING MULATION Enable LAN Enable the LAN Emulation services in the CoreBuilder 9000 ATM Enterprise Switch. The enable takes place after the next reboot. Emulation Services Command Actions Enter menu sequence: (1) SYS: Platform config...
Page 229: Disable Lan Emulation Services
LAN Emulation Services Setup Disable LAN Disable the LAN Emulation services in the CoreBuilder 9000 ATM Enterprise Switch. The disable takes place after the next reboot. Emulation Services Command Actions Enter menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 230: Display Lecs Status
LAN E HAPTER ANAGING MULATION Display LECS Status Display the status of the LECS in the CoreBuilder 9000 ATM Enterprise Switch. The status is either enabled or disabled. Command Actions Enter menu sequence: (1) SYS: Platform Configuration (1) SET: Switch Setup...
Page 231: Enable Lecs
LAN Emulation Services Setup Enable LECS Enable the LECS in the CoreBuilder 9000 ATM Enterprise Switch after the next reboot. This command also enables the resident LESs. Command Actions Enter menu sequence: (1) SYS: Platform Setup (1) SET: Switch Setup...
Page 232: Disable Lecs
9: M LAN E HAPTER ANAGING MULATION Disable LECS Disable the LECS in the CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter menu sequence: (1) SYS: PLatform Setup (1) SET: Switch Setup (5) SLE: LE Services Setup (2) LCS: LECS setup...
Page 233: Lan Emulation Redundancy Setup
LAN Emulation Redundancy Setup LAN Emulation You can set up the LAN Emulation redundancy services as follows: Redundancy Setup Display LECS Redundancy Add LECS to LECS-Order Database Delete LECS from LECS-Order Database Display LE Service Redundancy Enable or Disable LE Servers Redundancy Update Startup Delay...
Page 234: Display Lecs Redundancy
ANAGING MULATION Display LECS Display the LECS-order database in the CoreBuilder 9000 ATM Enterprise Switch. The LECS-order database has up to five entries. The first entry is Redundancy the active LECS and the others are redundant backup LECS, which are activated according to order.
Page 235: Add Lecs To Lecs-Order Database
LAN Emulation Redundancy Setup Add LECS to Add a LECS to the LECS-order database in the CoreBuilder 9000 ATM Enterprise Switch as the last element. If you want to change the order of LECS-Order Database the LECS in the LECS-order database, delete the entries and reenter them.
Page 236: Delete Lecs From Lecs-Order Database
ANAGING MULATION Delete LECS from Delete a LECS from the LECS-order database in the CoreBuilder 9000 ATM Enterprise Switch. Enter the index of the LECS address as it appears LECS-Order Database in the LECS-order database. To display the database, see “Display LECS Redundancy”...
Page 237: Display Le Service Redundancy
LAN Emulation Redundancy Setup Display LE Service Display parameters of the LES redundancy facility in the CoreBuilder 9000 ATM Enterprise Switch. For more information, see “Redundant LANE Redundancy Services” on page 392. Command Actions Enter menu sequence: (1) SYS: Platform config...
Page 238: Enable Or Disable Le Servers Redundancy
CoreBuilder 9000 ATM Enterprise Switch is enabled or disabled. System message display: Redundancy mode changed. Example Enter: 1 1 5 4 2 0 The following message is displayed: Redundancy mode changed. The LECS-based LANE redundancy facility in the CoreBuilder 9000 ATM Enterprise Switch is disabled...
Page 239: Update Startup Delay
LAN Emulation Redundancy Setup Update Startup Delay Update the startup delay parameter for LANE redundancy facility in the CoreBuilder 9000 ATM Enterprise Switch. The startup delay is the time elapsed between the switch startup and the startup of the LANE redundancy facility.
Page 240: Lecs Address
Information is displayed as shown in the example. Example Enter: 2 1 1 The following information is displayed. The first 13 bytes represent the network prefix of the CoreBuilder 9000 ATM Enterprise Switch and the last 7 bytes represent the user part. LECS ADDR is: 47.0.0.0.0.0.3c.0.0.a0.0.0.0.0.a0.3e.0.0.1.0...
Page 241: Update Resident Lecs Address
LECS Address Update Resident LECS Update the address of the resident LECS. Enter the user part of the Address address (last 7 hex bytes). The switch network prefix is used for the first 13 bytes. The update takes place immediately. Command Actions Enter menu sequence: (2) LEM: LAN Emulation...
Page 242: Lecs Search Policy
9: M LAN E HAPTER ANAGING MULATION LECS Search Policy You can configure the LECS search policy. Display LECS Search Display the search policy of the resident LECS, according to which a LES Policy address is assigned to a LEC that requests to join an ELAN. When a LEC applies to the LECS to join an ELAN, it can supply the following information to assist the LECS: The ATM address of the LES with which it wants to communicate over...
Page 243 LECS Search Policy Example Enter: 2 1 3 The search policy of the resident LECS is displayed: First lecs search policy is by ATM address Second lecs search policy is by Mac Address Third lecs search policy is by Elan name...
Page 244: Lecs Elan Database Operations
9: M LAN E HAPTER ANAGING MULATION LECS ELAN You can configure the ELAN database as follows: Database Display ELANs Operations Display ELAN Parameters in LECS Database Update ELAN Parameters in LECS Database Display ELAN MAC Addresses Delete ELAN MAC Address Add ELAN MAC Address Display ELAN ATM Addresses Delete ELAN ATM Address...
Page 245: Display Elans
LECS ELAN Database Operations Display ELANs Display all the ELANs that are defined in the LECS database along with their LES addresses. The active LESs are indicated. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS network topology (1) DAL: Display all ELANs Direct access sequence:...
Page 246 9: M LAN E HAPTER ANAGING MULATION ELAN LES Parameters Table 29 ELAN LES Parameters Name Description ELAN Name Name of ELAN. LES Address ATM address of ELAN LES. Status Active status of LES: Active or Backup.
Page 247: Display Elan Parameters In Lecs Database
LECS ELAN Database Operations Display ELAN Display the ELAN type and maximum frame size for a specified ELAN. The Parameters in LECS information is taken from the LECS database. For information about Database parameters in the LES database, see “Display ELAN Parameters in LES Database”...
Page 248 9: M LAN E HAPTER ANAGING MULATION ELAN Parameters in LECS Database Table 30 ELAN Parameters in LECS Database Name Description ELAN Type The type of frames that the ELAN recognizes: 802.3 Ethernet type 802.3 Token Ring type Max Frame Size LAN Type Frame Length (Bytes) Ethernet/Fast Ethernet:...
Page 249: Update Elan Parameters In Lecs Database
LECS ELAN Database Operations Update ELAN Update the parameters for the specified ELAN in the LECS database. (For Parameters in LECS more information, see Table 30 for a description of the ELAN parameters Database that you can update.) CAUTION: After you update the parameters of an ELAN in the LECS database, you must use the LMA to update the parameters of the ELAN in the LES database in exactly the same way.
Page 250: Display Elan Mac Addresses
9: M LAN E HAPTER ANAGING MULATION Display ELAN MAC Display the MAC address inserted by a specified ELAN. Addresses Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (4) MAC: MAC Addresses Info (1) MAD: Display all MAC addresses Enter a parameter at the prompt Parameter...
Page 251: Delete Elan Mac Address
LECS ELAN Database Operations Delete ELAN MAC Delete a MAC address inserted from an ELAN. Address Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (4) MAC: MAC Address Info (2) DEL: Delete MAC Address Enter a parameter at the prompt Parameter...
Page 252: Add Elan Mac Address
9: M LAN E HAPTER ANAGING MULATION Add ELAN MAC Add a MAC address to an ELAN MAC address database. This database is Address selected from the real database. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (4) MAC: MAC Address Info (3) ADD: Add new MAC address...
Page 253: Display Elan Atm Addresses
LECS ELAN Database Operations Display ELAN ATM Display ATM addresses inserted for a specified ELAN. Addresses Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (5) ATM: ATM Address Info (1) AAD: Display all ATM addresses Enter a parameter at the prompt Parameter...
Page 254: Delete Elan Atm Address
9: M LAN E HAPTER ANAGING MULATION Delete ELAN ATM Delete an ATM address inserted by a specified ELAN. Address Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (5) ATM: ATM Addresses Info (2) DEL: Delete ATM address Enter a parameter at the prompt Parameter...
Page 255: Add Elan Atm Address
LECS ELAN Database Operations Add ELAN ATM Add an ELAN ATM address for a specified ELAN ATM address database. Address This database is disconnected from the real database. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (5) ATM: ATM Address Info (3) ADD: Add new MAC address...
Page 256: Add Elan
(Ethernet, 1516). You can define up to 380 ELANs in the LECS database of a CoreBuilder 9000 ATM Enterprise Switch. Each CoreBuilder 9000 ATM Enterprise Switch LECS database has 16 default ELAN names and default ATM addresses corresponding to the LESs in the same switch.
Page 257 LECS ELAN Database Operations Example Enter: 2 1 5 6 elan_73_9 47.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0 The console responds with the confirmation: New elan was added.
Page 258: Delete Elan
9: M LAN E HAPTER ANAGING MULATION Delete ELAN Delete an ELAN from the LECS database. Specify the ELAN name. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (7) DEL: Delete ELAN record Enter a parameter at the prompt Parameter Format or Range...
Page 259: Configure Segment Id
LECS ELAN Database Operations Configure Segment Configure a local segment ID for a token ring ELAN in the LECS database. Specify the ELAN name. Each token ring segment in a token ring network that uses source routing must be assigned a unique segment ID by the network administrator. You assign the segment ID to the ATM ELAN, which simulates the token ring, by this command.
Page 260: Restore Network Topology
9: M LAN E HAPTER ANAGING MULATION Restore Network Load the network topology from the database. Topology Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Config Services (5) LNT: LECS network topology Direct access sequence: 2 1 5 Command Result System action taken: The network topology parameters from the LECS...
Page 261: Lecs Database Statistics
LECS ELAN Database Operations LECS Database Show how many entries in LECS database are occupied by LECs that are Statistics in the process of configuration request. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Config Services (6) LST: LECS Statistics Direct access sequence: 2 1 6...
Page 262: Reset Lecs
9: M LAN E HAPTER ANAGING MULATION Reset LECS Release configuration of direct VCCs that were used in the configuration phase of a LEC and are no longer needed. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (7) RST: Reset LECS Direct access sequence: 2 1 7...
Page 263: Lan Emulation Redundancy
LAN Emulation Redundancy LAN Emulation You can configure the LAN emulation redundancy facility as follows: Redundancy Assign Redundant LES to ELAN Deassign Redundant LES from ELAN Make Primary LES Active Display Redundant ELANs General Information Display Redundant ELANs Specific Information Display Redundant LES General Information Display Redundant LES Specific Information...
Page 264: Assign Redundant Les To Elan
9: M LAN E HAPTER ANAGING MULATION Assign Redundant Assign a LES to be the redundant (secondary) LES of a specified ELAN in the LECS database. Specify the ELAN name and the ATM address of the LES to ELAN LES. The secondary LES should reside on a different switch than the primary LES.
Page 265: Deassign Redundant Les From Elan
LAN Emulation Redundancy Deassign Redundant Deassign a redundant (secondary) LES from a specified ELAN in the LECS database. Specify the ELAN name associated with the LES. LES from ELAN Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (9) RDN: LE Service redundancy (2) DLS: Delete Redundant LES...
Page 266: Make Primary Les Active
Redundant LES” on page 396. To perform this command, the ELAN must be in secondary state and it must be redundant. You need to perform this command on all CoreBuilder 9000 ATM Enterprise Switches with active LECS and verify the result. Command Actions...
Page 267 LAN Emulation Redundancy Example Enter: 2 1 5 9 3 elan_73_9 The following message is displayed: Force to Primary message sent to LECS The active LES of the specified ELAN is forced to become the primary LES...
Page 268: Display Redundant Elans General Information
9: M LAN E HAPTER ANAGING MULATION Display Redundant Display general information about redundant ELANs. ELANs General Command Actions Information Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (9) RDN: LE Service redundancy (4) REG: Display Redundant ELANs general info Direct access sequence:...
Page 269 LAN Emulation Redundancy Redundant ELANs General Parameters Table 31 describes the ELANs general parameters. Table 31 Redundant ELANs General Parameters Parameter Description The ELAN Id number. Name The ELAN name. State The state of the ELAN. This can be Primary, Secondary, In Check (when the ELAN is in transient state) or No LES.
Page 270: Display Redundant Elans Specific Information
9: M LAN E HAPTER ANAGING MULATION Display Redundant Display specific information about Redundant ELANs. ELANs Specific Command Actions Information Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (9) RDN: LE Service redundancy (5) RLG: Display Redundant ELANs specific info Direct access sequence:...
Page 271 LAN Emulation Redundancy Redundant ELANs Specific Parameters Table 32 describes the ELANs specific parameters. Table 32 Redundant ELANs Specific Parameters Parameter Description ELAN name The ELAN name. ELAN status The status of the ELAN. This can be: Operational The ELAN is operating normally. A newly created ELAN that has not yet been processed by the LECS.
Page 272: Display Redundant Les General Information
9: M LAN E HAPTER ANAGING MULATION Display Redundant Display general information on Redundant LES. LES General Command Actions Information Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (9) RDN: LE Service redundancy (6) RLG: Display Redundant LESs general info Direct access sequence:...
Page 273: Display Redundant Les Specific Information
LAN Emulation Redundancy Display Redundant Display specific information on Redundant LES. LES Specific Information Command Actions Enter menu sequence: (2) LEM: LAN Emulation (1) LCS: LE Configuration Services (5) LNT: LECS Network topology (9) RDN: LE Service redundancy (7) RLS: Display Redundant LES specific info.
Page 274 9: M LAN E HAPTER ANAGING MULATION Redundant LES General Parameters Table 34 describes the redundant LES general parameters. Table 34 Redundant LES General Parameters Parameter Description LES ATM Address The LES ATM address. Connection State The LES connection state. This can be: Establish There is a connection between the LECS and the LES.
Page 275: Les Address
Display LES-BUS Addresses Update ELAN LES-BUS Address Display LES-BUS Display LES ATM addresses for all 16 LESs that are defined in the Addresses CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Service...
Page 276 9: M LAN E HAPTER ANAGING MULATION Example Enter: 2 2 1 The following information is displayed: ELAN LES-BUS ATM address: LES-BUS ATM address: Network prefix User part ----- --------------------------------------- --------------------- 47. 0. 0. 0. 0. 0.3c. 0. 0.a0. 0. 0. 0 0.c0.da.60.
Page 277: Update Elan Les-Bus Address
Address part, which consists of 6 bytes separated by dots. The last byte is a selector byte (0-F) that signifies the sequential identifier of the LES in the CoreBuilder 9000 ATM Enterprise Switch. Command Actions Enter menu sequence: (2) LEM: LAN Emulation...
Page 278: Elan Parameters
Display ELAN Parameters in LES Database Update ELAN Parameters in LES Database Display ELAN Display general information about the 16 ELANs in the CoreBuilder 9000 Parameters in LES ATM Enterprise Switch. The information is taken from the LES database. Database (For more information about parameters in the LECS database, see “Display ELAN Parameters in LECS Database”...
Page 279 ELAN Parameters Example Enter: 2 2 2 The following information is displayed: ELAN ELAN ELAN Control Mcast name type frame distrib forward size mem_id/ mem_id/ Call_id Call_id ---- -------------- ------ ------ ------- ------- elan_69_0 802.3 1516 1701/ 11 1701/ 13 elan_69_1 802.3 1516...
Page 280 9: M LAN E HAPTER ANAGING MULATION ELAN Parameters for Resident LESs Table 35 ELAN Parameters for Resident LESs Name Description ELAN ID ELAN ID number. ELAN Names ELAN name. ELAN Type The type of frames that the ELAN recognizes: 802.3 Ethernet type 802.5 Token Ring type Max Frame Size...
Page 281: Update Elan Parameters In Les Database
ELAN Parameters Update ELAN Update the parameters for the specified ELAN in the LES database. Parameters in LES Table 36 describes the ELAN parameters you can update. Database CAUTION: After you use this command to update the parameters of an ELAN in the LES database, you must use the LMA to update the parameters of the ELAN in the LECS database in exactly the same way.
Page 282 9: M LAN E HAPTER ANAGING MULATION Example Enter: 2 2 4 14 1 1 The following message appears: ELAN is reset. The parameters of the ELAN with ID 14 are updated. ELAN Parameters for a LES Table 36 describes the ELAN parameters that can be updated. Table 36 ELAN Parameters for a LES Name Description...
Page 283: Le_Arp Policy Configuration
LE_ARP Policy Configuration LE_ARP Policy You can configure the LE_ARP policy as follows: Configuration Display ELAN Response Policy Update ELAN Response Policy Display LE_ARP Response Policy Update LE_ARP Response Policy Display LE_ARP Response Policy for Route Descriptor Update LE_ARP Response Policy for Route Descriptor Reset LES Configurations Display LANE Multicast Forward Delay Update LANE Multicast Forward Delay...
Page 284 9: M LAN E HAPTER ANAGING MULATION Example Enter: 2 2 3 1 2 2 The response policy of the ELAN with ELAN ID #2 is displayed as follows: Response policy is DIRECT VCC. ELAN Response Policies Table 37 ELAN Response Policies Name Description DIRECT VCC...
Page 285: Update Elan Response Policy
LE_ARP Policy Configuration Update ELAN Update the response policy for an ELAN: direct VCC or distributed Response Policy connection. The new response policy takes effect immediately. This is a global setting for all the clients in that ELAN. The factory default value is direct connection.
Page 286: Display Le_Arp Response Policy
9: M LAN E HAPTER ANAGING MULATION Display LE_ARP Display the policy for handling LAN Emulation Address Resolution Response Policy Protocol (LE_ARP) requests for a specified ELAN. See Table 38 for the possible LE_ARP policies. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Services (3) ELN: ELANs Information...
Page 287: Update Le_Arp Response Policy
“Display ELAN Response Policy” on page 283.) Forward Request Does not check the address table of the LES in the CoreBuilder 9000 ATM Enterprise Switch but instead immediately sends the LE_ARP request to all LECs in the ELAN.
Page 288 9: M LAN E HAPTER ANAGING MULATION Command Actions Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Services (3) ELN: ELANs Information (1) LSU: LES Setup (5) SAR: Set & Save LE arp policy Enter a parameter at the prompt Parameter Format or Range 1–16...
Page 289: Display Le_Arp Response Policy For Route Descriptor
(See Table 38.) When the Respond policy is selected, the address table of the LES in the CoreBuilder 9000 ATM Enterprise Switch is searched for the LAN destination. If the LAN destination is not found and is a Route Descriptor, this policy gives the you the option of rejecting the LE_ARP request.
Page 290 9: M LAN E HAPTER ANAGING MULATION Command Actions Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Services (3) ELN: ELANs Information (1) LSU: LES Setup (6) GRD: Get ARP pol. for nonreg RD Enter a parameter at the prompt Parameter Format or Range ELAN ID...
Page 291: Update Le_Arp Response Policy For Route Descriptor
LE_ARP Policy Configuration Update LE_ARP Update the additional policy for handling LE_ARP requests for a Token Response Policy for Ring ELAN: Reject Request or Forward Request. The new response policy Route Descriptor goes into effect immediately. This is a global setting for all the clients in that ELAN.
Page 292: Reset Les Configurations
9: M LAN E HAPTER ANAGING MULATION Reset LES Reset all LES configurations in the CoreBuilder 9000 ATM Enterprise Configurations Switch to factory-default values including LES-BUS address, ELAN response policy, and LE_ARP response policies. Command Actions Enter menu sequence: (2) LEM: LAN Emulation...
Page 293: Display Lane Multicast Forward Delay
LE_ARP Policy Configuration Display LANE Display the LANE multicast forward delay. For certain switches and Multicast Forward bridges that connect to the CoreBuilder 9000 ATM Enterprise Switch, you Delay must configure a delay between a multicast send and a multicast forward.
Page 294: Update Lane Multicast Forward Delay
9: M LAN E HAPTER ANAGING MULATION Update LANE Update the LANE multicast forward delay parameter. Multicast Forward Command Actions Delay Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Services (3) ELN: ELANs Information (1) LSU: LES Setup (10) SDL Set LANE Multicast Fwd Delay Enter a parameter at the prompt...
Page 295: Lec Operations
LEC Operations LEC Operations You can configure the LEC operations as follows: Display LEC Connection Info Display LEC Address Info Display LEC Display LAN emulation clients (LEC) connection information for a Connection Info specified ELAN and specified LEC. A LEC is specified by its ID. To determine the ID of a specific LEC, first perform this command with a value of 0 for LEC ID (as in the example).
Page 296 9: M LAN E HAPTER ANAGING MULATION Example Enter: 2 2 3 2 1 0 The LEC information for all LECs of the specified ELAN is displayed as follows: State Ctrl Mcast ATM addresses: Direct send User part proxy mem_id/ mem_id/ Call_id Call_id...
Page 297: Display Lec Address Info
LEC Operations Display LEC Address Display all MAC addresses, ATM addresses, and Route Descriptors of a Info specified LEC that are registered in the LES ARP-cache of a specified ELAN. A LEC is specified by its ID. If you do not know a LEC’s ID, specify a value of 0 to display information for all LECs.
Page 298 9: M LAN E HAPTER ANAGING MULATION Example Enter: 2 2 3 2 1 0 The MAC and ATM addresses for all LECs of the ELAN with ELAN ID 1 are displayed as follows: LECID: Primary ATM Addr: 47.0.0.0.0.0.0.0.0.0.0.0.0 0.c0.da.18.1.c.0 MAC address ATM address --------------...
Page 299: Lan Emulation Statistics
LAN Emulation Statistics LAN Emulation You can view the LAN Emulation statistics, as follows: Statistics Display LAN Emulation Statistics Display LEC Statistics Reset LAN Emulation Statistics Reset ELAN Display LAN Displays statistics for the LES and BUS in a specified ELAN. Emulation Statistics Command Actions Enter menu sequence:...
Page 300 9: M LAN E HAPTER ANAGING MULATION Example Enter: 2 2 3 4 1 2 LES and BUS statistics for the ELAN with ELAN ID 2 are displayed as follows: LES global counters ------------------- Total number of active clients: Total number of active MAC addresses for all clients: Total number of active ATM addresses for all clients: Total number of messages accepted by LES: Total number of messages rejected by LES:...
Page 301: Display Lec Statistics
LAN Emulation Statistics Display LEC Statistics Display statistics for a LEC in a specified ELAN. Command Actions Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Services (3) ELN: ELANs Information (4) STS: Statistics (2) LEC: LEC statistics Enter a parameter at the prompt Parameter Format or Range 1–16...
Page 302 9: M LAN E HAPTER ANAGING MULATION LEC Statistics Table 41 LEC Statistics Name Description LEC ID LEC ID number. Num Reg MAC addr Number of MAC addresses registered by that LEC. Num Reg ATM addr Number of ATM addresses registered by that client. Num msg Sent by Client Number of messages sent by that client.
Page 303: Reset Lan Emulation Statistics
LAN Emulation Statistics Reset LAN Emulation Reset general LAN Emulation statistics for a specified ELAN to zero. Statistics Command Actions Enter menu sequence: (2) LEM: LAN Emulation (2) LES: LE Services (3) ELN: ELANs Information (4) STS: Statistics (3) RES: Reset General LE Statistics Enter a parameter at the prompt Parameter...
Page 304: Reset Elan
ELAN. This feature enables the user to reset the LANE Services without rebooting the CoreBuilder 9000 for the following purposes: Shutdown of the redundant LANE Services to force all LECs to return to the primary LANE Services after a failure has occurred.
Page 305 APABILITIES Chapter 10 ATM Network Basics Chapter 11 Network Interface Management Chapter 12 E-IISP Protocol Chapter 13 Establishing ATM Channels Chapter 14 ATM Switching Chapter 15 Managing LAN Emulation Chapter 16 Traffic Management Chapter 17 Device Management Chapter 18 Switch Redundancy Chapter 19 Viewing Network Statistics...
Page 307: Atm Network Basics
ATM N ETWORK ASICS This chapter provides basic concepts and information about: ATM Overview ATM Cell Structure ATM Layers Functional Planes Designing ATM Networks ATM Network Examples LAN Emulation ATM Networks ATM Overview In 1986, the Comité Consulatif International Télégraphique et Téléphonique (CCITT), now known as the International Telecommunications Union (ITU), formed a study group to explore the concept of a high-speed, integrated network to uniformly handle voice,...
Page 308: Atm Cell Structure
10: ATM N HAPTER ETWORK ASICS Using this connection-oriented networking technology, centered by a switch, you can set up a great number of virtual connections to support multiple applications through the same physical connection. The switching technology enables dedicated bandwidth for each application, overcoming the problems that exist in a shared-media networking technology, like Ethernet, Token Ring, and Fiber Distributed Data Interface (FDDI).
Page 309: Advantages Of Using Fixed-Length Cells
Advantages of Using Fixed-Length Cells Advantages of Fixed-length cells offer the following advantages: Using Fixed-Length Network and switching queueing delays are more predictable than for Cells variable-length packets. Cell switching is less complex and more reliable. ATM hardware can be implemented more efficiently because control structures, buffers, and buffer management schemes can be designed to known size criteria.
Page 310: Atm Layers
10: ATM N HAPTER ETWORK ASICS ATM Layers As in the OSI (Open Systems Interconnection) model, ATM has levels that divide the functions of ATM. Figure 5 shows the OSI and ATM models, side by side. Note that the ATM layers do not exactly match the OSI layers.
Page 311: Atm Adaptation Layer (Aal)
ATM Layers ATM Adaptation The ATM Adaptation Layer is the standards layer that allows multiple applications to have data converted to and from the ATM cell. There are Layer (AAL) five AAL types. The AAL performs Segmentation and Reassembly (SAR) on cells.
Page 312: Functional Planes
ATM format while ensuring the required quality of service. LAN Emulation is the primary UNI service operating on the User Plane in the CoreBuilder 9000 ATM Enterprise ATM Switch; it transfers Ethernet frames across ATM devices. See Chapter 15 for details about LAN Emulation.
Page 313: Management Plane
LANs and an ATM switch. For example, the SuperStack Switch 2700 unit for Ethernet and Switch 2000 for Token Ring. An ATM switch — The ATM switch such as the CoreBuilder 9000 ATM Enterprise Switch provides the central switching service between end users.
Page 314: Atm Network Examples
ATM Network In this section, several examples of ATM networks and details of how they Examples are built are presented. You can use the CoreBuilder 9000 ATM Enterprise Switch in Classical IP Classical IP ATM Networks configurations to connect a workgroup.
Page 315: Multiple Switch Ip Routed Network
ATM Network Examples Figure 7 shows the CoreBuilder 9000 ATM Enterprise Switch deployed with two servers and numerous workstations. Figure 7 The CoreBuilder 9000 ATM Enterprise Switch in a Simple Workgroup CoreBuilder 9000 C ore Bui lde r 900 0...
Page 316: Lan Emulation Atm Networks
ATM and maintain the legacy LANs’ well-established environment. The following network devices support LAN Emulation: CoreBuilder 2500 CoreBuilder 9000 Enterprise ATM Switch provides the LAN Emulation services LES and LECS. An ATM edge device — SuperStack II Switch 2700 unit for Ethernet,...
Page 317: Enterprise Network
CoreBuilder 9000 ATM Enterprise Switch systems handle the LANE services based in the CoreBuilder 9000 units. The CoreBuilder 9000 units on the upper floors serve as edge devices; CoreBuilder 7200 and 7400 series of Ethernet interface cards provides high-density switched Ethernet 10 Mbps connections to workgroup hubs or direct to the desktop.
Page 318 MAN applications use the OC-12 SMF SR interface. High-density Server Farm Applications Figure 9 illustrates how you can connect servers to the CoreBuilder 9000 ATM Enterprise Switch via OC-12 (3). The CoreBuilder 9000 ATM Enterprise Switch high-density OC-3 and...
Page 319 LAN Emulation ATM Networks Figure 9 The CoreBuilder 9000 ATM Enterprise Switch in a Headquarters Network ® ® CoreBuilder 7000HD CoreBuilder 7000HD Dual OC-12c Dual OC-12c ATM, 10/100 or ATM, 10/100 or Gigabit Ethernet Gigabit Ethernet ATM (OC-3c or OC-12c)
Page 320 10: ATM N HAPTER ETWORK ASICS...
Page 321: Network Interface Management
ETWORK NTERFACE ANAGEMENT This chapter provides basic concepts and information about: Network Interfaces Interim Local Management Interface (ILMI) Basic ILMI Functions Network -to- Network Interface (NNI) Gateway Interface (GWY)
Page 322: Network Interfaces
11: N HAPTER ETWORK NTERFACE ANAGEMENT Network Interfaces To enable individual ATM devices to function together in an ATM network, standard software interfaces are provided between each device and the devices to which it is connected. Three types of interfaces are used: User-Network Interface (UNI) —...
Page 323: Interim Local Management Interface (Ilmi)
CoreBuilder 9000 ATM Enterprise Switch. It supports Interface (ILMI) the bi-directional exchange of management information between ATM users and the CoreBuilder 9000 ATM Enterprise Switch to which they are connected. The ILMI provides status, configuration, statistics, and control information about link and physical layer parameters at the UNI.
Page 324: Uni Management Entity (Ume)
11: N HAPTER ETWORK NTERFACE ANAGEMENT UNI Management For each ATM device that participates in a UNI, a UNI Management Entity (UME) supports the ILMI functions for that UNI. When two ATM devices Entity (UME) are connected across a (point-to-point) UNI, two UMEs are associated with that UNI, one for each ATM device.
Page 325: Uni Address Registration
Basic ILMI Functions UNI Address The ILMI address registration provides the following services: Registration Initialization-time exchange of addressing information Restrictions on network-prefix/user-part combinations Acceptance of unassigned network prefixes Rejection of unacceptable values, either rejection of a specific network prefix by the user, or of a specific user part by the network Dynamic addition and deletion of additional network prefixes and user parts De-registration of addresses when ILMI Connectivity is lost...
Page 326 NTERFACE ANAGEMENT Organizational Scope for Group Address The CoreBuilder 9000 switch ILMI supports the organizational scope for a registered ATM group address. The organizational scope restricts the distribution of information that is related to the group address within the network. This variable supports the group address of an ATM device and the Anycast facility.
Page 327 This occurs when the attached edge device has more than one ATM-addressable component. For example, edge devices such as SuperStack II , Switch 2700 and the CoreBuilder 9000 interface modules ® can have multiple ATM-addressable Ethernet bridges. The ATM address of each bridge is registered by ILMI at the port to which the edge device is connected.
Page 328: Access To Service Registry Mib
Referencing Calls by Destination ATM Address - Member ID For easy reference, each ATM address registered at a port is assigned a member ID. The member ID, which is specific to the CoreBuilder 9000 ATM Enterprise Switch, consists of the port number followed by a two-digit number of the form 0n where 01 corresponds to the first ATM address registered, 02 to the second, and so on.
Page 329: Ilmi Connectivity Polling
Network -to- Network Interface (NNI) ILMI Connectivity The CoreBuilder 9000 ATM Enterprise Switch polling facility continuously verifies the connectivity of the ILMI channel of a port. It determines that Polling the adjacent IME has failed when it does not receive a response for 120 consecutive retry polling requests.
Page 330: Private Nni
The ATM switch determines the best path/route to a destination according to the topology database, using the routing engine. E-IISP The CoreBuilder 9000 ATM Enterprise Switch implements the P-NNI in the E-IISP NNI protocol. (For more information, see Chapter 12.)
Page 331: Gateway Interface (Gwy)
Gateway Interface (GWY) Gateway Interface The Gateway interface is provided for connecting the CoreBuilder 9000 (GWY) Enterprise ATM Switch to ATM switches of other vendors. For this purpose a simple, universal protocol, the IISP, is utilized. Interim InterSwitch IISP (PNNI phase 0) is the first phase standard for multiple switch Protocol (IISP) networks.
Page 332 11: N HAPTER ETWORK NTERFACE ANAGEMENT...
Page 333: E-Iisp Protocol
Hierarchy in an E-IISP Network Planning a Network with E-IISP E-IISP Hierarchic Routing Algorithm Introducing E-IISP is a 3Com proprietary hop-by-hop dynamic routing protocol. It was Enhanced Interim developed as an improvement to the ATM Forum IISP standard. E-IISP InterSwitch...
Page 334: Iisp Vs. E-Iisp
ROTOCOL IISP vs. E-IISP The IISP routing protocol is a simple, universal protocol used to connect the CoreBuilder 9000 ATM Enterprise Switch to ATM switches of other vendors. IISP (PNNI phase 0) is the first phase standard for multiple switch networks.
Page 335: Features Of E-Iisp
E-IISP also introduced the concept of hierarchy in a network design. Using E-IISP Network E-IISP, most 3Com ATM networks are based in the ATM address of 47.0.0.0.0.0.3c.0.0.a* that is, utilizing the last four bytes of the switch portion of the ATM address. In the ATM address space, hierarchy translates into a tree structure as shown in Figure 11.
Page 336: Hierarchic Atm Addressing
12: E-IISP P HAPTER ROTOCOL Figure 11 Connecting Switches in a Hierarchic Topology Network Core (Root of Hierarchy) Edge Devices (Branches) This type of topology is well-suited for installation in a group of buildings. Each of the trees A, B, C is installed in a separate building where the root node is located in the basement and the branches distributed throughout the floors.
Page 337 Hierarchy in an E-IISP Network The ATM address has 20 bytes, which are divided into a 13-byte Network Prefix and a 7-byte User Part. These are further divided into fields shown in Table 42. Table 42 Fields of the ATM Address Field Description Authority Format Identifier —...
Page 338: Configuring Network Atm Addresses
Fast Setup procedure or specific LMA commands (see “Update Network Prefix” on page 150) to register the network prefixes at each CoreBuilder 9000 ATM Enterprise Switch. See the CoreBuilder 9000 ATM Switch Fabric Module Getting Started Guide for a detailed description of the...
Page 339: Auto-Discovery
Switches receives the message and stores the received network prefix together with the port number on which the message was received. In this way, each CoreBuilder 9000 ATM Enterprise Switch knows the network prefix of each of its neighbors. For example, in Figure 11, switch A registers the ATM address prefixes of the three neighbors A1, A2, and B.
Page 340: Planning A Network With E-Iisp
12: E-IISP P HAPTER ROTOCOL Planning a Network This section discusses how you create a hierarchical topology to plan a with E-IISP network using the E-IISP protocol. Hierarchical Topology As discussed previously, the routing algorithm of E-IISP assumes that you have constructed your network with a hierarchical topology.
Page 341 Planning a Network with E-IISP Figure 14 Hierarchical Switch Addressing in Tree Topology An address with two significant nibbles is one level lower in the tree hierarchy than one significant nibble. Three significant nibbles indicate a third level address. Note that the higher-order nibbles are the second-level address.
Page 342: E-Iisp Hierarchic Routing Algorithm
The routing method consists of the following steps: 1 The CoreBuilder 9000 ATM Enterprise Switch receives the ATM address of the destination ATM user, the ATM destination address, from the signaling SETUP message that establishes the external link to the input port.
Page 343 E-IISP Hierarchic Routing Algorithm 3 If no match is found among its UNI neighbors, the CoreBuilder 9000 ATM Enterprise Switch compares the network prefix of the ATM destination address with the network prefix of the ATM address of each of its NNI neighbors.
Page 344: Hop Limit - Avoiding Loops
“Display Call Routed to ATM Address” on page 157. Crankback The crankback mechanism in the CoreBuilder 9000 switch automatically re-routes a call if a virtual channel cannot be established on the path fixed by the routing algorithm. This can happen for a number of reasons: No route to destination No VCC available —...
Page 345: Automatic Retry
E-IISP Hierarchic Routing Algorithm Automatic Retry After receiving the RELEASE message, the source CoreBuilder 9000 ATM Enterprise Switch again attempts to establish a virtual channel, but this time via an alternate path. The switch determines the alternate path automatically with the routing table that was established during the first connection attempt.
Page 346 12: E-IISP P HAPTER ROTOCOL Alternate routes are desirable for the following reasons: Dividing the load between nodes over several links reduces congestion (see next section) If one link fails, an alternate link can be used. If the node cannot be found or accessed via a link, it can be searched through another link after crankback.
Page 347: Load Balancing
(For more information, see “E-IISP Hierarchic Routing Algorithm” on page 368.) If two or more NNI neighbors have the same match type, the CoreBuilder 9000 ATM Enterprise Switch uses its routing table to assign a connection to each of the links in a round robin algorithm; the first connection to the first link, the second connection to the second link, and so on.
Page 348 12: E-IISP P HAPTER ROTOCOL...
Page 349: Establishing Atm Channels
ATM C STABLISHING HANNELS Asynchronous Transfer Mode (ATM) is a connection-oriented transport service, much like a telephone. Unlike Ethernet, where data is sent out on a common bus, ATM requires that a path or virtual channel be established to carry the call from the source station to the destination station before data transmission can begin.
Page 350: Virtual Channels
13: E ATM C HAPTER STABLISHING HANNELS Virtual Channels A virtual channel is a communications path that can carry a single call from the source station to the destination station. A channel is virtual because it does not necessarily correspond to a single physical line and, in fact, usually passes through many different network devices and cables before reaching its destination.
Page 351 Virtual Channels The figure shows three ATM devices: two ATM edge devices and an ATM Enterprise Switch between them. The virtual channel begins at the left edge device, passes through the ATM Enterprise Switch and terminates at the right edge device. Two external links of the virtual channel, shown as connect output ports of one device with input ports of the adjacent device;...
Page 352: Virtual Path - Channel Hierarchy
13: E ATM C HAPTER STABLISHING HANNELS Virtual Path — The values of VPI and VCI can be allocated independently of each other. Channel Hierarchy These two degrees of freedom allow you to construct a channel hierarchy. If several virtual channels with different VCI values are given the same VPI value, then you can group all these channels together by relating only to the VPI value.
Page 353: Permanent Virtual Channels
Virtual Channels Permanent Virtual You establish a permanent virtual channel (PVC) manually by Channels management. An established PVC connection is not automatically released and is not dynamically checked and reinitiated. The characteristics of the PVC connection include: Connections initiated by the network administrator Connections established and released manually Long-term duration connections in a LANE environment Point-to-point and point-to-multipoint connections...
Page 354: Signaling - External Links
13: E ATM C HAPTER STABLISHING HANNELS Signaling — This section describes establishing a switched virtual channel by signaling. External Links As discussed previously, a virtual channel is made up of two types of links: External links (connections) between ports of adjacent ATM devices Internal links between input and output ports of an ATM device stored in the ATM Enterprise Switch matrix.
Page 355: Signaling Protocol
Signaling — External Links This section discusses the signaling process; the next section discusses the routing process. Signaling Protocol ATM uses the UNI signaling standard protocol for dynamically establishing, maintaining, and clearing SVC connections between endpoints. The major features of the signaling protocol include: On demand connections Point-to-point and point-to-multipoint connections Multiple address formats...
Page 356: Signaling Messages
13: E ATM C HAPTER STABLISHING HANNELS Signaling Messages The signaling protocol that established the connection consists of a command set with a set of watchdog timers. The watchdog timers allow the system to declare an error and continue operating when an response to a command is not received within an expected time interval.
Page 357: Setup Message
Signaling — External Links SETUP Message The SETUP signaling message initiates the procedure for setting up the connection. It carries with it the requirements for the call. These essential requirements (which are discussed later in this section) must be accepted by network and the receiving device or the connection is not established.
Page 358: Signaling Protocol Profile
ATM device. The profile can be either network or user. When the CoreBuilder 9000 ATM Enterprise Switch port is connected to an end station or edge device, the CoreBuilder 9000 Enterprise ATM Switch port is normally defined as network (Net).
Page 359: Displaying Connections
Signaling — External Links A point-to-multipoint call has the following properties: The source end point serves as the root in a simple tree topology. When this link node sends information, all of the remaining nodes on the call receive copies of the information. Data flows only from the root to the destination nodes.
Page 360 13: E ATM C HAPTER STABLISHING HANNELS Figure 18 Signaling Message Sequence for a Point-to-Point Connection Point-to-Multipoint Connection Figure 19 shows the sequence of signaling messages for setting up a point-to-multipoint external link (connection) between a root station and a set of destinations (leaves) by signaling. From the Calling Party to The Enterprise ATM Switch: The calling edge device initiates the establishment of a connection to the first destination leaf by sending a SETUP message that contains the connection...
Page 361: Signaling Timers
Signaling — External Links The release procedures are similar to the establishment procedures. Figure 19 Signaling Message Sequence for a Point-to-Multipoint Connection Signaling Timers Each signaling protocol comes with a set of timers, one for each type of message in the protocol. These timers determine when an expected response to a message is overdue.
Page 362 13: E ATM C HAPTER STABLISHING HANNELS Table 46 and Table 47 display the various watchdog timers that are associated with the signaling messages. The start and stop timer conditions are shown. Table 46 Q.2931 Watchdog Timers — User End Timer Default Name...
Page 363: Timer Resolution
When the timer resolution is changed, all timers are affected. The CoreBuilder 9000 ATM Enterprise Switch is shipped with a default timer resolution of 500 msec (.5 secs). To change the value of an individual timer, you need to change the timer resolution proportionally.
Page 364: Signaling Aal
13: E ATM C HAPTER STABLISHING HANNELS Signaling AAL The signaling described previously takes place in signaling channels kept separate from the channels used for data transmission. The SAAL (Signaling AAL) is the adaptation layer used in these signaling channels. The SAAL provides a reliable transmission service to the signalling layer above it, because this layer does not possess any error-compensation mechanisms of its own.
Page 365: Sscop Timers
Signaling AAL SSCOP Timers Table 49 and Table 50 present the SSCOP watchdog timers. Table 49 SSCOP Timers SSCOP Timer Description Poll The maximum time between transmission of a POLL PDU, when SD or SDP PDUs are queued for transmission or are outstanding pending acknowledgment.
Page 366: Sscop Configuration Parameters
Control Frame Port Statistics” on page 218. Call Control A smart engine in the CoreBuilder 9000 ATM Enterprise Switch called the Call Control manages the signaling protocol. It establishes, maintains, and clears virtual connections between two ATM interfaces. The Call Control...
Page 367: Managing Signaling Protocol Parameters
ATM address and interface port. This database may be viewed through management tools. Based on this database, the CoreBuilder 9000 ATM Enterprise Switch can handle error conditions, notify the users on link down situations and manage to recover from clearing connections.
Page 368: Routing - Internal Links
The routing method consists of the following steps: 1 The CoreBuilder 9000 ATM Enterprise Switch receives the ATM address of the destination ATM user, the ATM destination address, from the signaling SETUP message that establishes the external link to the input port.
Page 369 UNI port, finishing the process successfully with a route established. 3 If no match is found among its UNI neighbors, the CoreBuilder 9000 ATM Enterprise Switch compares the network prefix of the ATM destination address with the network prefix of the ATM address of each of its NNI neighbors.
Page 370: Hop Limit - Avoiding Loops
Resources unavailable — Node internal resource problem Automatic Retry After receiving the RELEASE message, the source CoreBuilder 9000 again attempts to establish a virtual channel but this time via an alternate path. The alternate path is determined automatically by the CoreBuilder 9000 by means of the routing table that was established during the first connection attempt.
Page 371: Atm Switching
ATM S WITCHING The previous two chapters presented the concept of virtual channels: what a virtual channel is and how it is built. This chapter discusses how ATM data travels, or is switched, over a virtual channel. This chapter provides basic concepts and information about: ATM Switching Traffic Statistics ATM Switching...
Page 372 14: ATM S HAPTER WITCHING Figure 20 shows how a call is transferred over a virtual channel. Figure 20 ATM Switching ATM Edge Device ATM Switch aaaaaa ATM Edge Device aaaaaa a aa bb b bbbbbb ATM edge device converts packets A, B into cells a,b, Two calls, A and bbbbbb...
Page 373: Traffic Statistics
Traffic Statistics The call is transferred by the following steps: 1 The edge device translates the Ethernet frames into ATM cells and forwards them to the ATM output port. 2 The ATM output port writes the VPI/VCI values for the external link for the VC on the cell header and transmits the cells on the line that connects the port to the switch.
Page 374 14: ATM S HAPTER WITCHING...
Page 375: Lan Emulation
LAN Emulation Overview Emulated LAN Components Emulated LAN Connections Operation of the LAN Emulation LAN Emulation in the CoreBuilder 9000 ATM Enterprise Switch LAN Emulation Redundancy LAN Emulation LAN Emulation (LANE) is a method of connecting LAN users over an ATM...
Page 376: Emulated Lan Components
15: LAN E HAPTER MULATION Emulated LAN LAN Emulation is implemented as a set of connection services collectively Components called an Emulated LAN (ELAN). Each ELAN is composed of a set of LAN Emulation Clients (LEC) and a single LAN Emulation Service. The latter consists of an LE Configuration Server (LECS), an LE Server (LES), and a Broadcast and Unknown Server (BUS).
Page 377: Broadcast And Unknown Server (Bus)
Emulated LAN Components Broadcast and The BUS is the LE connection service that handles ATM traffic other than Unknown Server direct transmissions between LECs. It handles the following: (BUS) Data sent by a LEC to the broadcast MAC address All multicast traffic Initial unicast frames that are sent by a LEC before the data direct virtual connection to the ATM address has been resolved Unknown traffic...
Page 378: Emulated Lan Connections
15: LAN E HAPTER MULATION Emulated LAN LECs and LESs communicate with each other by means of ATM virtual Connections channel connections (VCCs). Control signals and data transmissions are handled by separate VCCs: Control VCCs and Data VCCs. Figure 21 Basic LAN Emulation Client Connections Control VCCs The control VCCs carry control traffic such as LE_ARP requests and responses.
Page 379: Data Vccs
Emulated LAN Connections Data VCCs Data VCCs carry data frames between LECs and between a LEC and the BUS. Unicast data is normally sent from one LEC to another LEC by data-direct VCCs. Data direct VCCs are set up dynamically in a SVC environment by a transmitting LEC after ascertaining the ATM LEC destination address for the packet to be transmitted.
Page 380: Frame Ordering
15: LAN E HAPTER MULATION Figure 22 illustrates the VCCs active among LAN Emulation Components. Figure 22 VCCs in LAN Emulation Components Frame Ordering There are two paths for unicast frames between a sending LAN Emulation Client and a receiving client: one via the BUS and one via a data direct VCC between them.
Page 381: Operation Of The Lan Emulation
Operation of the LAN Emulation Operation of the The following functions are performed by the LAN Emulation. The LAN LAN Emulation Emulation Clients (LEC) and the LAN Emulation Servers interact by way of a well-defined interface (LUNI). Connecting a LEC to an ELAN Address Registration Address Resolution Connection Management...
Page 382: Address Registration
15: LAN E HAPTER MULATION The processes connecting the LEC to the ELAN are shown in Figure 23. Figure 23 Connection Processes of the LEC-to-LE Service Address Registration The address registration function is the mechanism by which LECs provide address information to the LAN Emulation Server. The LAN destinations may also be unregistered as the state of the client changes.
Page 383: Address Resolution
Operation of the LAN Emulation Address Resolution Address resolution is the procedure by which a LEC associates a LAN destination with the ATM address of another LEC or the BUS. Address resolution allows clients to set up data direct VCCs to carry frames. (See Figure 24.) Figure 24 Address Resolution Connection...
Page 384: Lan Emulation In The Corebuilder 9000 Atm Enterprise Switch
ELAN LES addresses to 13 bytes switch prefix, 6 bytes switch MAC address and a 1 byte selector that signifies the ELAN of the LES (0-f). The BUS address within the CoreBuilder 9000 ATM Enterprise Switch is identical to the LES address for the corresponding ELAN.
Page 385: Connecting A Lec To An Elan
As mentioned in “LAN Emulation Configuration Server (LECS)” on an ELAN page 377, the LECS in the CoreBuilder 9000 enables a LEC to join an ELAN to obtain a LES address. The LEC connects to the LECS within one of the CoreBuilder 9000 ATM Enterprise Switches in the ATM cloud through the standard addressing protocol.
Page 386 1 Get the LECS address via ILMI. 2 Use the well-known LECS address. 3 Use the LECS PVC (not supported by the CoreBuilder 9000 ATM Enterprise Switch). LECS Search Policy When a LEC requests to join an ELAN, it can supply the following...
Page 387 LES and BUS connections were presented in “Emulated LAN Connections” on page 378. After the initial registration of the LAN Emulation Client (LEC) with the CoreBuilder 9000 ATM Enterprise Switch, the LEC sets up the Control Direct VCC, a direct bi-directional point-to-point connection with the LES.
Page 388: Address Resolution
15: LAN E HAPTER MULATION Address Resolution When a LEC needs to forward a unicast data frame whose LAN destination is not found in its local Forwarding Data Base, it attempts to locate a LEC that represents the LAN destination on the ATM network. To do this, it turns to the LES in a process called address resolution.
Page 389 When the “Respond” policy is selected, the address table of the LES in the CoreBuilder 9000 ATM Enterprise Switch is searched for the LAN destination. If the LAN destination is not found, then this additional policy...
Page 390: Unknown Multicast And Broadcast Frames
15: LAN E HAPTER MULATION That is, the operator can select between the two options as shown in Table 57. Table 57 LE_ARP Response Policies for Route Descriptors Name Description Reject Reject the LE_ARP request. Forward Request Forward the LE_ARP request to all LECs in accordance with the LE_ARP response policy.
Page 391: Lan Emulation Redundancy
Emulation services and is relevant to networks that have more than one CoreBuilder 9000 ATM Enterprise Switch installed. The following topics are included: LANE Services in the CoreBuilder 9000 ATM Switch Fabric Module Redundant LANE Services LECS Redundancy Facility — Configuring the LECS-Order Database LES Redundancy Facility —...
Page 392: Lane Services In The Corebuilder 9000 Atm Switch Fabric Module
Services the network ELANs in case of failure of one or more of the CoreBuilder 9000 ATM Enterprise Switches or failure of the physical links that connect them. The system ensures that the LANE services that were provided by the LECS and LESs of the failed switch are efficiently and reliably transferred to backup LECS and LESs in other CoreBuilder 9000 ATM Enterprise Switches in the network.
Page 393: Lecs Redundancy Facility - Configuring The Lecs-Order Database
You provide for LECS redundancy by enabling the LECS in up to five Facility — CoreBuilder 9000 ATM Enterprise Switches in the network. A LECS-order Configuring the database with up to five entries is provided in each switch to support LECS-Order Database LECS redundancy.
Page 394 15: LAN E HAPTER MULATION LES Redundancy When a network has more than one CoreBuilder 9000 ATM Enterprise Facility — Switch, you can create redundant LESs for an ELAN. When you designate Configuring the ELAN a primary LES in a switch to be the active LES for an ELAN, you can...
Page 395 LAN Emulation Redundancy Assigning the Active LES for an ELAN — Monitoring LES Status On-line Before it assigns the primary or secondary LES of an ELAN to be active, the LECS determines if they are operational. For this purpose, each LECS continuously monitors the operating status of all LESs in its topology database by trying to establish a ATM point-to-point connection with the LES.
Page 396 15: LAN E HAPTER MULATION The LECS has determined that the primary LES, LES 1, is operational by connecting to it and has assigned it to be the active LES in the ELAN. The connection has reported 20 LECs attached. Failure Recovery —...
Page 397 LES again by using an LMA command. (See “Make Primary LES Active” on page 266.) You need to perform this command on all CoreBuilder 9000 ATM Enterprise Switches with active LECS and verify the result. Normally, since their topology database is identical, all LECS in the network respond in the same way to a LES failure;...
Page 398: Selecting Lan Emulation Redundancy Mode
When those LECs turn to the LECS to be readmitted to the ELAN, they are directed to the primary LES and the ELAN is reunited. Two types of LAN redundancy are available in the CoreBuilder 9000 ATM Selecting LAN Enterprise Switch: LECS-based LANE redundancy as described previously,...
Page 399: Lane Redundancy Start-Up Delay
The following restrictions obtain: Limitations Number of LECs that are allowed to connect to the CoreBuilder 9000 ATM Enterprise Switch: 1000 Number of redundant ELANs: 128 If you assign a redundant LES to more than 64 ELANs, you cannot change to the LECS-based LANE redundancy mode.
Page 400: Lane Redundancy Planning
15: LAN E HAPTER MULATION LANE Redundancy Consider the following issues when you plan your network to support Planning LANE redundancy: Allow for route recovery in case of switch or link failure to provide ATM address structure and physical network connectivity. Do not allow primary and secondary LESes for an ELAN to be on the same switch.
Page 401: Traffic Management
® 9000 ATM Enterprise Switch. The following topics are discussed: Traffic Management Basics Traffic Management in the CoreBuilder 9000 ATM Enterprise Switch Traffic ATM technology supports a wide variety of services and applications. Management Basics Each type of application, whether it be voice, video, or data, has its own special transmission performance requirements such as delay sensitivity and information loss tolerance.
Page 402: Traffic Management In The Corebuilder 9000 Atm Enterprise Switch
16: T HAPTER RAFFIC ANAGEMENT Traffic One of the most powerful features of the CoreBuilder 9000 ATM Management in the Enterprise Switch is its ability to handle traffic congestion and protect CoreBuilder 9000 high priority data. ATM Enterprise Switch Traffic Management...
Page 403: Setting Up Traffic Management Hardware
Control Flow for Setting Up Traffic Management Figure 26 shows the control flow that occurs when you set up Traffic Management in the CoreBuilder 9000 ATM Enterprise Switch. The Traffic Management process for a call begins when a call connection is initiated.
Page 404: Efci
16: T HAPTER RAFFIC ANAGEMENT Figure 26 Setting up Traffic Management Control Flow EFCI A network element in an pre-congested state sets the Explicit Forward Congestion Indication (EFCI) congestion notification mechanism in a cell header. It is part of the standard ABR class of service. In Figure 27, the output ALP (1) senses pre-congestion and begins to mark headers of outgoing cells with the EFCI notation.
Page 405: Output Data Loss Prevention
Module is directed to the same output port, the flow in the output port can exceed the line rate of 622 Mbps. Several safeguards in the CoreBuilder 9000 ATM Enterprise Switch prevent loss of output data in this situation. Priority Output Queues...
Page 406 RAFFIC ANAGEMENT Priority Output Queues One primary way in which the CoreBuilder 9000 ATM Enterprise Switch controls output data loss is by prioritizing the output data. A data frame for which certain losses or delays in transmission can be tolerated according to its QoS is designated as lower priority data.
Page 407: Input Data Loss Prevention
Traffic Management in the CoreBuilder 9000 ATM Enterprise Switch The Back Pressure Cell Storage method works as follows: In Figure 27, a precongested state is created on the output channel when not all the cells can be transmitted through the Framer out to the line, and they begin backing up.
Page 408: Activating Methods By Threshold
RAFFIC ANAGEMENT Partial Packet Drop Partial Packet Drop (PPD) in the CoreBuilder 9000 ATM Enterprise Switch reduces traffic congestion by dropping incoming data frames. PPD is employed when the input queues are overflowing, cells are being lost, and the frame is corrupted. This method is known as Partial Packet Drop because the “tail”...
Page 409 Traffic Management in the CoreBuilder 9000 ATM Enterprise Switch Table 60 shows a typical threshold regime for input and output queues. The first row of the table shows the lowest threshold, that is, the first threshold o be activated. Table 60 Thresholds for Traffic Management Methods...
Page 410 16: T HAPTER RAFFIC ANAGEMENT...
Page 411: Device Management
The following topics are discussed in this chapter: Overview Local Management Application (LMA) SNMP Agent Ethernet Encapsulation Type CoreBuilder 9000 ATM Enterprise Switch Service Console Overview Two methods enable you to administer and manage the CoreBuilder 9000 ATM Enterprise Switch: A proprietary Local Management Application (LMA).
Page 412 (E th e rn e t P o rt) Figure 29 depicts the various protocols that can access the CoreBuilder 9000 ATM Enterprise Switch management applications. A detailed discussion of each application follows. Figure 29 Protocols Used to Access the Management Applications.
Page 413: Local Management Application (Lma)
Telnet over TCP/IP over LAN Emulation through one of the ATM ports At system setup, you must activate the LMA to configure the communication modes that are needed to access the agents through the various networks. See the CoreBuilder 9000 ATM Switch Fabric Module Getting Started Guide for additional configuration information.
Page 414: Security
17: D HAPTER EVICE ANAGEMENT Security Local Management security rests on a hierarchy of passwords: Admin, Write, and Read. For additional information on Local Management security, see “Password Setup” on page 60. Figure 30 CoreBuilder 9000 ATM Enterprise Switch Administration Console...
Page 415: Snmp Agent
SNMP Agent Simple Network Management Protocol (SNMP) is a standard management protocol for multi-vendor IP networks. Each CoreBuilder 9000 ATM Enterprise Switch has one SNMP agent that monitors objects on the switch and reports data to a network management system.
Page 416: Snmp Traps
ATM Switch Fabric Module exceeds a certain hard-coded limit. Managing by SNMP You can manage the CoreBuilder 9000 ATM Enterprise Switch via SNMP-based external network management applications running on a workstation. (See Figure 31.) One such application is the 3Com Transcend Enterprise Manager.
Page 417: Access Methods
Use the LMA to configure the CoreBuilder 9000 ATM Enterprise Switch’s IP address, subnet mask, NMS IP address, and the default gateway via the LMA to enable access to the SNMP agent. See the CoreBuilder 9000 ATM Switch Fabric Module Getting Started Guide for additional configuration information.
Page 418: Ethernet Encapsulation Type
SNMP. The Ethernet frames that the managing device transmits to the CoreBuilder 9000 ATM Enterprise Switch Ethernet port can be either of two types, depending on how the Ethernet data is encapsulated in the Ethernet frame. These are referred to as Ethernet encapsulation types: Standard encapsulation - according to 802.3...
Page 419: Switch Redundancy
WITCH EDUNDANCY This chapter covers the following topics: Need for a Redundant Switch Fabric Module Identifying the Active Switch Fabric Module Conditions for Switch-over to Redundant Module Switch Fabric Module Configuration Database Information Based on the MAC Address Resetting to Factory Defaults Upgrading the Software Standby Suspend State Need for a...
Page 420: Identifying The Active Switch Fabric Module
18: S HAPTER WITCH EDUNDANCY Identifying the ® While the CoreBuilder 9000 ATM Enterprise Switch boots, the ATM Active Switch Fabric Switch Fabric Module that is installed in slot 8 (of a 16-slot chassis) is Module assigned as the Active Switch and the Switch Fabric Module that is installed in slot 9 is designated as the Standby or Redundant Switch.
Page 421: Information Based On The Mac Address
Main (active) Switch. However, each switch fabric module board has a Address unique MAC address burned into its EPROM. This MAC address is used by the CoreBuilder 9000 ATM Enterprise Switch for two purposes: For the IP stack For the LES ATM address user part...
Page 422: Standby Suspend State
18: S HAPTER WITCH EDUNDANCY Standby Suspend You can place a standby switch in standby suspend state via the State (1)\ (4)\ (3) \(2) option in the LMA. When a redundant switch fabric module is in standby suspend state, it cannot replace the active switch fabric module in the event of a reset or failure.
Page 423: Viewing Network Statistics
To view statistics: 1 From the CoreBuilder 9000 LMA Main Menu, enter 4 to access the Statistics menu (STS). 2 Type the number indicated in Table 62 to view the desired statistic type.
Page 424 19: V HAPTER IEWING ETWORK TATISTICS Table 62 The Statistics Menu (continued) Menu Option Description 2 ATM: The ATM layer statistics can be consulted if, for example, a ATM Layer VPI/VCI is not recognized when setting up a call. These statistics also provide information on the capacity of traffic within ports.
Page 425 PPENDIXES Appendix A ATM Switch Fabric Module Specifications Appendix B Downloading Software Appendix C Protocols and Interfaces Appendix D Technical Support...
Page 427: Atm Switch Fabric Module Specifications
ATM S WITCH ABRIC ODULE PECIFICATIONS Physical Table 63 ATM Switch Fabric Module Specifications Specification Metric Imperial Height 38.8 cm 15.3 in. Width 3.81 cm 1.5 in. Depth 32.7 cm 12.8 in. Weight 1700 g 3.74 lb Environmental Table 64 Environmental Specifications Specification Metric Imperial...
Page 428: Electromagnetic Compatibility
A: ATM S PPENDIX WITCH ABRIC ODULE PECIFICATIONS Electromagnetic Table 66 Electromagnetic Compatibility Compatibility Specification Standard Meets FCC part 15 Subparagraph B, Class A limits. Directive complied with: EMC 89/336/EEC as amended by 92/31/EEC and 93/68/EEC. Emission EN50081-1 (EN55022) Immunity EM50082-1 (IEC801-2,-3,-4) Standards Table 67 Standards Supported...
Page 429: Downloading Software
CoreBuilder 9000 ATM Enterprise Switch Facility functioning normally. You can upgrade this software as needed. Consult your local 3Com representative for information about upgrading the software. You can download three CoreBuilder 9000 software units: ATM Switch Fabric Module Software...
Page 430: Hardware And Software Requirements
Connect your PC to the RS-232 Control Port of the ATM Switch Fabric Instructions Module. Putting the Standby If you have two Switch Fabric Modules installed in your CoreBuilder 9000 Switch Fabric Module chassis, you must put the standby Switch Fabric Module into Suspend into Suspend Mode Mode using the following procedure: 1 Enter the LMA command 1 4 3 2 at the main menu prompt.
Page 431: Preparations
RS-232 Upgrade Instructions Preparations Before you begin the download procedure, log into the CoreBuilder 9000 Enterprise ATM Switch Local Management Access (LMA) . To use the RS-232 download, the switch must be put in a special state, in Downloading the Software Files which the operational software does not take control.
Page 432: Tftp Upgrade Instructions
3 To change the standby switch to standby mode, enter the command 1 4 3 2 (Standby In-Service/Suspended) at the Main Menu prompt. 4 To reboot the CoreBuilder 9000, switch the power off and then back on or enter the command 1 7 at the Main Menu prompt.
Page 433: Putting The Standby Switch Fabric Module In In-Service Mode
After you have downloaded your software, verify the success status of Download Status the download as follows: 1 Log in to the CoreBuilder 9000 LMA. See “Starting Up” in the ATM Switch Fabric Module Getting Started Guide for complete login instructions.
Page 434 B: D PPENDIX OWNLOADING OFTWARE Table 70 Download Messages (continued) Message Meaning and Action Check the following: System Loader cannot cable connection reach the server if TFTP server is up TFTP server IP address After downloading switch fabric Flash memory partially module software: Download erased software again via RS-232 port.
Page 435: Protocols And Interfaces
ROTOCOLS AND NTERFACES This appendix describes basic concepts and information about interfaces and management protocols that are used in the ATM system including the following topics: Physical Layer Interfaces ATM Layer Operation and Maintenance (OAM) ATM Adaptation Layer (AAL) Physical Layer Traditionally, the physical layer deals with bits and its function is to move a Interfaces bit from place to place.
Page 436 C: P PPENDIX ROTOCOLS AND NTERFACES Cell Delineation: This function permits the identification of cell boundaries in the payload. It uses the Header Error Control (HEC) field in the cell header. Path Signal Identification: An integrity check is performed on the end-to-end signal.
Page 437: Physical Layer Interface
Physical Layer Interfaces DS-3 Physical Layer DS-3 is an important interface because it is widely deployed on public UNIs. Although the DS-3 rate is 44.76 Mbps, the nominal bit rate that is Interface available for the transport of ATM cells is 40.704 Mbps. This is due to the overhead induced by the Physical Layer Convergence Protocol (PLCP).
Page 438: Atm Layer
C: P PPENDIX ROTOCOLS AND NTERFACES ATM Layer This section presents the structure of the ATM cell and ATM layer. ATM Cell Structure The ATM cell is defined as 48 bytes of payload and 5 bytes of header information totaling 53 bytes. The header contains enough information to allow the network to forward each cell to its proper destination.
Page 439: The Atm Layer
ATM Layer Table 71 ATM Cell Header Fields (continued) Field Full Field Name Description Payload Type Identifier This is a 3 bit field used to indicate whether the cell contains user information or connection associated layer management information (F5 flow). The PTI is also used to indicate a network congestion state or for network resource management, and is used to mark the end of frame for AAL5 adaptation layer.
Page 440: Operation And Maintenance (Oam)
C: P PPENDIX ROTOCOLS AND NTERFACES The ATM layer supports fault management, including alarm surveillance and connectivity verification functions. OAM cells are used for exchanging operation related information. ATM cells with valid VPI/VCI values are discarded and Layer Management is informed. Traffic management at the public UNI monitors traffic on each connection and takes the proper action to protect the network resources and ensure that the user-network traffic agreements are respected.
Page 441 Operation and Maintenance (OAM) The virtual channel connection (VCC) operation information is carried via the F5 flow OAM cells. These cells have the same VPI/VCI values as the user-data cells but are identified by preassigned code points of the PT field.
Page 442: Atm Adaptation Layer (Aal)
C: P PPENDIX ROTOCOLS AND NTERFACES ATM Adaptation The role of the ATM Adaptation Layers (AALs) is to define how to deal Layer (AAL) with the contents of cells. The AAL performs Segmentation and Reassembly (SAR) on cells. It formats data into the 48 byte ATM cell payload, in effect adapting applications to the cell-based ATM layer.
Page 443: Aal5
ATM Adaptation Layer (AAL) AAL5 The AAL5 is the data-oriented adaptation layer. The CRC is appended to the end of the frame to protect the user information against bit and cell errors. It is padded to align to 48 bytes (Figure 35). To indicate frame boundaries and determine when to reassemble and when to stop reassembling, the space bit for Payload Type (PT) in the cell header is zero except for the last cell in the packet (when it is a one).
Page 444 C: P PPENDIX ROTOCOLS AND NTERFACES Figure 35 AAL5 Frame Format Figure 36 Segmentation - Converting an ATM Frame to Cells...
Page 445: Technical Support
Download drivers, patches, software, and MIBs across the Internet from the 3Com FTP Site 3Com public FTP site. This service is available 24 hours a day, 7 days a week.
Page 446: Com Bulletin Board Service
Up to 53,333 bps 1 847 262 6000 Access by Digital Modem ISDN users can dial in to the 3Com BBS using a digital modem for fast access up to 64 Kbps. To access the 3Com BBS using ISDN, use the following number:...
Page 447: Com Facts Automated Fax Service
3Com. Support from 3Com If you are unable to obtain assistance from the 3Com online technical resources or from your network supplier, 3Com offers technical telephone support services. To find out more about your support options, please call the 3Com technical telephone support phone number at the location nearest you.
Page 448 01 800 CARE (01 800 2273) Brazil 0800 13 3266 Peru AT&T +800 666 5065 Chile 1230 020 0645 Puerto Rico 800 666 5065 Colombia 98012 2127 Venezuela AT&T +800 666 5065 1 800 NET 3Com North America (1 800 638 3266)
Page 449: Returning Products For Repair
Returning Products for Repair Returning Products Before you send a product directly to 3Com for repair, you must first for Repair obtain a Return Materials Authorization (RMA) number. Products sent to 3Com without RMA numbers will be returned to the sender unopened, at the sender’s expense.
Page 450 D: T PPENDIX ECHNICAL UPPORT...
Page 451 ® chassis The hardware housing unit for the CoreBuilder 9000. CoreBuilder 9000 A high performance modular switching family, which runs on an ATM or Ethernet backplane. daughter card Can be either OC-3, OC-12, single-mode or multi-mode or UTP5. These cards are attached to the ATM Interface Carrier Module, to make the Interface Module complete.
Page 452 Extended Interim Interswitch Protocol. A signaling protocol that uses network-to-network (NNI-based) signaling for communication. Enterprise The management engine for the CoreBuilder 9000 ATM Enterprise Management Engine Switch. (EME) Enterprise Network A nework structure that is similar to a campus network.
Page 453 LOSSARY Partial Packet Drop A procedure for discarding cells related to one user frame to minimize the impact of congestion. (PPD) Port Status LED LEDs that indicate the status of each port. Software Error LED LEDs that light up in a binary pattern to indicate the nature of the software error.
Page 454 LOSSARY...
Page 455 63 Transcend Enterprise Manager (TEM) 42, 416 administration console 32, 414 World Wide Web site 19 management capabilities 47 3Com bulletin board service (3Com BBS) 446 administrative status 164, 166 3Com Facts 447 alarm surveillance 440 3Com URL 445...
Page 456 NDEX network prefix 337 management through 413 of BUS 387 operational status 164, 166 of destination LEC 386 originator 165, 166 of LES in LECS 377 port ID 164, 166 registered in LES 376 ATM Switch Fabric Module 29, 42 registration at UNI 325 installation prerequisites 42 user part 337...
Page 457 29, 419 mode 104 software units 429 syncronization 117 troubleshooting 423 clock source CoreBuilder 9000 ATM Interface Module Getting getting status 117 Started Guide 42 resetting 120 CoreBuilder 9000 Enterprise Switch setting 118, 119 16-Slot Chassis Quick Installation Guide 42...
Page 458 437 safety information 38 frame alignment 437 Enterprise Management Engine Quick Start Guide for growth octets 437 the CoreBuilder 9000 Enterprise Switch 42 HEC generation & verification 437 environmental specifications 427 mapping ATM cells 437 operating humidity 427...
Page 459 PVC call 171 fault management history of ATM 307 ATM layer 440 humidity OAM 441 operating 427 fax service (3Com Facts) 447 storage 427 features CoreBuilder 9000 34 signaling protocol 355 flow control 32 i960 processor 31 ATM layer 439...
Page 460 301, 302, 303 LEC to ELAN join state 296 connecting 381 LEC to LES connecting 381 connection management 381 key features of the CoreBuilder 9000 34 registration 381 LECS database 245 database statistics 261 LAN 295, 376 disable 232...
Page 461 NDEX LEDs maximum NNI hops interface 428 displaying 181 management 428 media type 104 legacy end stations member ID 328 connecting 375 menus access to submenus 52 ATM addresses registered in 376 key functions 53 configurations reset 292 selecting options 51 directory populating 376 Message Identification (MID) 442 general information 272...
Page 462 440 point-to-point call ATM port connection type 164, 166 PVC 171 point-to-point connection paper documentation SVC 358 CoreBuilder 9000 25 port Partial Packet Drop (PPD) 408 ID number 102, 104 password in interface modules 30 admin 414 interface type 104...
Page 463 NDEX power supply redundant ELAN installing 42 general information 268 PPD 33 specific information 270 precautions redundant LES 396 handling 38 general information 272 safety 37 specific information 273 prefix, switch 384 redundant LES from ELAN prerequisites de-assign 265 installation 42 redundant LES to ELAN primary LES 394 assigning 264...
Page 464 NDEX segment ID standby switch fabric module configure 259 suspend mode 430 Segmentation and Reassembly (SAR) 311 startup delay ATM adaptation layer 442 updating 239 server farms 33 statistics service AAL5 control frame port 218 console 418 AAL5 layer 424 service registry MIB 328 ATM Layer 424 setting...
Page 465 408 URL 445 buffer level threshold 408 User Network Interface (UNI) 81 technical support displaying signaling timers 200 3Com URL 445 general 35 bulletin board service 446 ILMI 323 fax service 447 ILMI MIB 323 network suppliers 447...
Page 466 NDEX workgroup topology overview 314 World Wide Web (WWW) 445 write access level 414 write community string configuration displaying 76 write-access password updating 62...
Page 467 If it appears that any product that is stated to meet this standard does not perform properly with regard to such date data on and after January 1, 2000, and Customer notifies 3Com before the later of April 1, 2000, or ninety (90) days after purchase of the product from 3Com or its authorized reseller, 3Com shall,...
Page 468 (48) hours of installation but no later than thirty (30) days after the date of purchase, and this is verified by 3Com, it will be considered dead- or defective-on-arrival (DOA) and a replacement shall be provided by advance replacement. The replacement product will normally be shipped not later than three (3) business days after 3Com’s verification of the DOA...

3Com CoreBuilder 9000 User Manual

Table of Contents

About this Guide

Overview

Startingu

Integrated Fast Setup

Using the Local Management Application

Menu Index

Configuring the Platform

Managing Network Interfaces

Configuring Virtual Channels

Viewing Statistics

Managing Lan Emulation

Atm Network Basics

Network Interface Management

E-Iisp Protocol

Establishing Atm Channels

Atm Switching

Lan Emulation

Traffic Management

Device Management

Switch Redundancy

Viewing Network Statistics

Atm Switch Fabric Module Specifications

Downloading Software

Protocols and Interfaces

Technical Support

Quick Links

User Guide

Chapters

Related Manuals for 3Com CoreBuilder 9000

Summary of Contents for 3Com CoreBuilder 9000
