42 C 2: S
HAPTER TARTING
Installation
Installation
Prerequisites
Installing the
Daughter Cards
Installing the ATM
Interface Module into
the Chassis
U
P
This section describes installing the ATM Switch Fabric Module.
Before you install the ATM Switch Fabric Module, ensure that you have
met all of the following prerequisite conditions:
1 Complete the chassis unpacking and installation procedure as described
in the 16-Slot Chassis Quick Installation Guide for the CoreBuilder 9000
Enterprise Switch or the 7-Slot Chassis Quick Installation Guide for the
CoreBuilder 9000 Enterprise Switch. You can install the chassis in a rack,
on a shelf, or on a tabletop.
2 Install the power supply as described in the 16-Slot Power Supply
Installation Guide for the CoreBuilder 9000 Enterprise Switch or the
7-Slot Power Supply Installation Guide for the CoreBuilder 9000
Enterprise Switch and install the power cable as described in the
Enterprise Management Engine Quick Start Guide for the
CoreBuilder 9000 Enterprise Switch.
3 Install the Enterprise Management Engine as described in the Enterprise
Management Engine Quick Start Guide for the CoreBuilder 9000
Enterprise Switch.
4 Install the ATM Switch Fabric Module as described in the
CoreBuilder 9000 ATM Switch Fabric Module Getting Started Guide
5 Read the CoreBuilder 9000 ATM Interface Module Getting Started Guide
to make sure that you have all of the required components to get your
system up and running and that you have completed all of the
prerequisite work.
6 To manage the ATM Interface Module and CoreBuilder 9000 ATM
Enterprise Switch through the Simple Network Management Protocol
(SNMP), you must install the 3Com Transcend
UNIX or for Windows NT.
7 For site requirements, see Appendix C in the CoreBuilder 9000 Enterprise
Switch Getting Started Guide.
For complete details on how to install the daughter cards into the ATM
Interface Module, see the CoreBuilder 9000 ATM Interface Module
Getting Started Guide.
For complete details on how to install the ATM Interface Module into the
CoreBuilder 9000 chassis, see the CoreBuilder 9000 ATM Interface
Module Getting Started Guide.
® Enterprise Manager for
