Add ELAN ATM
Add an ELAN ATM address for a specified ELAN ATM address database.
Address
This database is disconnected from the real database.
Command Actions
Enter menu sequence:
Enter a parameter at the prompt
Direct access sequence:
Command Result
System action taken:
System message display:
Example
Enter:
elan_73_9 47.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0.0
The system responds with the confirmation:
ATM address was added to this elan.
Parameter
ELAN name
ATM Address
2 1 5 5 3
LECS ELAN Database Operations
(2) LEM: LAN Emulation
(1) LCS: LE Configuration Services
(5) LNT: LECS Network topology
(5) ATM: ATM Address Info
(3) ADD: Add new MAC address
Format or Range
Up to 32 characters. (For more information, see
"Display ELANs" on page 245.)
20 Hex bytes separated by dots
2 1 5 5 3 [parameters]
The ATM address for the selected ELAN is added to the
debug mode ATM address database.
ATM address was added to this elan.
255
