Section 3 • Scheduled Maintenance Procedures
CHECKLIST B PROCEDURES
7 Inspect the head cooling passages and fins for
physical damage or foreign material, using a
flashlight.
8 Clean the cylinder head cooling passages of
debris and foreign material.
9 Install the engine side cover.
10 Swing the engine pivot plate in towards the
machine.
11 Install the bolts that were just removed into the
original holes to secure the engine pivot plate.
Crushing hazard. Failure to install
the bolts into the engine pivot plate
to secure it from moving could
result in death or serious injury.
3 - 22
B-7
Check the Lug Nut Torque
(including the tires and wheels)
Maintaining the tires and wheels in good
condition is essential to safe operation and good
performance. Tire and/or wheel failure could result
in a machine tip-over. Component damage may
also result if problems are not discovered and
repaired in a timely fashion.
1 Check all tire treads and sidewalls for cuts,
cracks, punctures and unusual wear.
2 Check each wheel for damage, bends and
cracked welds.
3 Check each lug nut for proper torque. Refer to
Section 2, Specifications.
4 Check the pressure in each air-filled tire. Refer
to Section 2, Specifications.
Genie Z-60/34
November 2003
Bodily injury hazard. An over-
inflated tire can explode and could
cause death or serious injury.
Tip-over hazard. Do not use
temporary flat tire repair products.
The tires on some machines are
foam-filled and do not need air
added to them.
