Joysticks - Genie Z-60/34 Service Manual

November 2003
REV A
4 Attach a grounded wrist strap to the ground
screw inside the platform control box.
Component damage hazard.
Electrostatic discharge (ESD) can
damage printed circuit board
components. Maintain firm contact
with a metal part of the machine
that is grounded at all times when
handling printed circuit boards OR
use a grounded wrist strap.
5 Carefully disconnect the wire connectors from
the circuit board.
6 Remove the ALC-500 circuit board mounting
fasteners.
7 Carefully remove the ALC-500 circuit board
from the platform control box.
Part No. 75861
1-2

Joysticks

How to Calibrate a Joystick
The joysticks on this machine utilize digital Hall
Effect technology for proportional control. If a
joystick is disconnected or replaced, it must be
calibrated before that particular machine function
will operate.
1 Pull out the red Emergency Stop button to the
on position at both the ground and platform
controls.
2 Turn the key switch to platform control. Do not
start the engine.
3 Select a joystick to calibrate.
4 Move the joystick full stroke in either direction
and hold for 5 seconds.
5 Return the joystick to the neutral position,
pause for a moment, then move the joystick full
stroke in the opposite direction. Hold for 5
seconds and return the joystick to the neutral
position.
Result: The alarm should sound indicating
successful joystick calibration.
6 Repeat this procedure for each joystick
controlled machine function including the thumb
rocker steer switch.
Genie Z-60/34
Section 4 • Repair Procedures
PLATFORM CONTROLS
The joystick must be calibrated
before the threshold, max-out or
ramping can be set.
Perform this procedure with the
engine off.
No machine fuction should
operate while performing the
joystick calibration procedure.
4 - 3
