Chapter 17
Address Bit
P005 0
1
2
3
4,5
6
7
P006 0-7
P007 0-7
P008 0-7
P009 0-7
P010 0-7
P011 0-7
17.3.5 <SORTER>
/ / / / iR C3380i / iR C3380 / iR C2880i / iR C2880
Address Controller
P001

SORTER

P002 SORTER
P003 SORTER
P004 SORTER
P005 SORTER
P006 SORTER
P007 SORTER
17-16
Description
cycle end sensor
length sensor 2
length sensor 1
A4/LTR identification sensor
not used
delivery sensor
DF open sensor
for R&D
for R&D
for R&D
for R&D
for R&D
for R&D
Bit Description
0 inlet feed motor A
1 inlet feed motor B
2 inlet feed motor A-
3 inlet feed motor B-
4 inlet feed motor switch 0
5 inlet feed motor switch 1
6 inlet feed/stack delivery motor standby signal
7 common solenoid ON signal
0 punch feed motor A
1 punch feed motor A-
2 punch feed motor B
3 punch feed motor B-
4 punch feed motor current switch 0
5 punch feed motor current switch 1
6 tray 2 motor clock
7 tray 1 motor clock
0-3 for R&D
4-7 not used
0 saddle connection detection signal
1 not used
2 swing HP sensor
3 upper cover open/closed sensor
4 front cover open/closed sensor
5 front cover interlock sensor
6 gear change HP sensor
7 not used
0,1 for R&D
2 punch transmission request signal
3 saddle 13V ON signal
4-7 not used
0 punch connection detection
1,2 not used
3 punch motor standby
4 inlet sensor (IRQ0)
5 paper trailing edge sensor (IRQ1)
6 punch communication input (IRQ2)
7 not used
0 tray approach sensor
1 tray 2 area sensor 1
2 tray 2 area sensor 2
3 tray 2 area sensor 3
4 tray 2 paper sensor
5 tray 2 paper surface sensor
6 inlet motor lock sensor
7 stack edging motor lock input
Remarks
1: detected
1: detected
1: detected
1: detected
0: detected
1: detected
T-17-21
Remarks
0: ON
0: ON
1: ON
0: ON
1: ON
1: ON
0: ON
1: ON
0: ON
0: ON
1: ON
1: ON
0: ON
1: ON
0: ON
1: ON
1: ON
1: ON
0: ON
0: ON
0: ON
0: ON
0: ON
1: ON
1: ON
