Canon iR C3380 series Service Manual page 446

Chapter 15
Ref. Description
PS16 Loop detection sensor 2
PS17 Front door sensor
PS18 Lower right door sensor
PS19 Right door sensor
PS20 Cassette 2 paper absent sensor
PS21 Cassette 1 paper level sensor A
PS22 Cassette 1 paper level sensor B
PS23 Cassette 2 paper level sensor A
PS24 Cassette 2 paper level sensor B
PS25 Cassette 1 re-try sensor
PS26 Cassette 2 re-try sensor
PS27 No. 1 delivery sensor
PS28 Fan shutter home position sensor
PS29 Fan shutter position detection sensor
2/3 delivery door open/ closed detection
PS30 sensor
TS1 Toner sensor (Y)
TS2 Toner sensor (M)
TS3 Toner sensor (C)
TS4 Toner sensor (K)
PS1A No. 2 delivery sensor
PS2A No.2 delivery tray full detection sensor
PS3A Duplexing paper inlet sensor
PS4A Reverse sensor
PS5A No. 3 delivery sensor
15-12
Parts
DC controller PCB
number
WG8-5772 J217-4 to 6
WG8-5772 J213-4 to 6
FK2-0149 J222-B8 to 10
WG8-5772 J213-1 to 3
FK2-0149 J219-B1 to 3
FK2-0149 J219-A4 to 6
FK2-0149 J219-A7 to to 9
FK2-0149 J219-B4 to 6
FK2-0149 J219-B7 to 9
FK2-0149 J219-A10 to 12
FK2-0149 J219-B10 to 12
FK2-0149 J225-B5 to 7
WG8-5772 J223-18 to 20
WG8-5772 J223-15 to 17
FK2-0149 J212-5 to 7
FH7-7422 J2015
FH7-7422 J2017
FH7-7422 J2003
FH7-7422 J2004
J744-3 to 5(Extension delivery
FH7-7312
controller PCB)
J743-1 to 15 (Extension delivery
FH7-7312
controller PCB)
J742-4 to 6 (Extension delivery
FH7-7312
controller PCB)
J745 (Extension delivery controller
FH7-7312
PCB)
J742-9 to 11 (Extension delivery
FH7-7312
controller PCB)
Jam code/ error code
-
010D/ 020D/ 0A0D
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
0109/ 0209/ 0A09/ 0A09
-
010C/ 020C/ 0A0A/ 0A0C
010A/ 020A/ 0A0B/ 0A0A
010B/ 020B/ 0A0B
