Control Board Layout

PE V+ is used to power photo electric beam.
01
PE In for photo electric beam for safety
02
PE (v-) is used to supply (-) volt to photo
03
electric beam.
Aux control input
04
OPN Programmable N/O or N/C input terminal
05
STP Programmable N/O or N/C input terminal
06
CLS N/O input terminal
07
OSC N/O input terminal
08
SWP N/O input terminal
09
PED N/O input terminal
10
COM terminal for input terminals 1 to 8
11
12 OUTPUT 2 (optional relay module coil drive)
OUTPUT 2 (optional relay module coil drive)
13
OUTPUT 1 N/C relay contact
14
OUTPUT 1 COM relay contact
15
OUTPUT 1 N/O relay contact
16
MOTOR 2 terminal 1
17
MOTOR 2 terminal 2
18
MOTOR 2 close limit switch input terminal
19
MOTOR 2 open limit switch input terminal
20
COM terminal for Terminals 16,17,19 & 20.
21
MOTOR 1 close limit switch input terminal
22
MOTOR 1 open limit switch input terminal
23
MOTOR 1 terminal 1
24
MOTOR 1 terminal 2
25
18 Elite® - Swing Gate Opener
26
27
28
29
30
31
32
33
34
Owner Installation Instructions
24VDC (+) output for powering accessories
24VDC (-) output for powering accessories
Standby battery / solar charger connector
24VAC power input (from transformer)
10 amp fuse
Programmer Input
Console keypad
Console display (LCD)
Antenna connector
