Control
board layout
12
Easy Slider - Sliding Gate Opener
*24VDC output for powering accessories 3A(max)
01
02
*Lock relay output N/C contact
03
*Lock relay output COM contact
04
*Lock relay output N/O contact
05
Slave/Master connections
06
*COM terminal for inputs terminals 8 - 14
07
08
*P.E N/C input terminal
*OPN N/C input terminal
09
*STP N/C input terminal
10
*CLS N/O input terminal
11
12
*OSC N/O input terminal
*SWP N/O input terminal
13
*PED N/O input terminal
14
15
*PE input jumper (remove when 8 is used)
*OPN input jumper (remove when 9 is used)
16
*STP input jumper (remove when 10 is used)
17
*Console Exit button
18
19
*Console Previous button
*Console Down/Close button
20
*Console Up/Open button
21
*Console SET button
22
*Console Next button
23
*Antenna connector
24
*Console Display
25
26
Motor installation side selector
*Optional light module interface connector
27
*Standby battery charger/solar connector
28
* Not present on slave unit
