Control Board Adjustments; Menu 2 Current Trips - Automatic Technology Elite Installation Manual

Standard Operation Modes
Close (Cls) Input
(Activated by CLS terminal with N/O switch, by transmitter button with CLS function assigned or by the DOWN
button on the console.) Activating the CLS input will cause the gate to close. Holding the input active will
prevent opening.
Swipe (Swp) Input
(Activated by SWP terminal with N/O switch or by transmitter button with SWP function assigned)
Activating the the SWP input will cause the gate to be opened. If the terminal input is held, it will prevent the
gate being closed. The swipe input also effects P.E TRIGGERED AUTO CLOSE.
Open (Opn) Input
(Activated by OPN terminal with N/O switch, by transmitter button with OPN function assigned or by console's
UP button) Activating the OPN input will cause the gate to open. Holding the input will prevent closing.
Stop (Stp) Input
(Activated by STP terminal with N/O switch, by transmitter button with STP function assigned or by console's
EXIT button) Activating the STP input while the gate is moving will cause the gate to be stopped. If the STP
terminal is held, it will prevent the gate from being moved.
Photo Electric Safety Beam (PE) Input
When the PE input is active, the gate is prevented from being closed. If the PE input is triggered while the gate
is closing, DCB-05 will stop the motors and then open the gate. The PE input has no effect while the gate is
opening.
Vacation Mode
DCB-05 supports a Vacation mode where remote control access is disabled. The mode is activated by pressing
a transmitter button with the VAC function assigned until the console displays that vacation mode is enabled
(approx. 5 seconds).
When activated any transmitter button which is assigned VAC will be ignored. To turn the Vacation mode off,
simply press a transmitter button with the VAC function assigned (only requires a brief activation). Vacation
mode can also be turned on or off manually by editing the VACATION MODE parameter.
DCB-05 can be instructed, via the pedestrian control feature, to partly open and provide pedestrian access but
prevent vehicle access. This is achieved by partly opening the motor 1 gate leaf. If dual motors are used, motor
2's gate leaf is held closed. The partly open position of motor 1's gate leaf is initially set to a position halfway
between open and closed. This initial position can be adjusted by the installer to any position within the gates
travel range by selecting a pedestrian access travel time (from closed). The setting is accessed from "MENU
10.4 Set Pedestrian". The time is adjustable in 1 second steps.

Control Board Adjustments

DCB-05's standard operation can be altered by editing various parameters. This section describes the
parameters and the effect they have.
Menu 2. Current Trips
The obstruction margins are used to alter the sensitivity of the allowable variation between the "normal" speed
profi le and DCB-05 to obstructions. Increasing the value increases the force required to detect an obstruction.
Parameter (Limit Switch)
M1 MARGIN Sets obstruction detection margin for M1
M2 MARGIN Sets obstruction detection margin for M2
SETTLE TIME disable the obstruction detection in the
start of the cycle
Min Max Default Step
0.0 5.0 0.7 0.1
0.0 5.0 0.7 0.1
0.1 2.0 1.0 0.1
Owner Installation Instructions Elite® - Swing Gate Opener
Unit Menu
No.
AMPS 2
AMPS 2
SEC 2
