Control Board Adjustments (Cont.)
Menu 4. Lock times
DCB-05's lock function can be programmed for both hold and pulse operation. The lock output can also be
programmed to activate prior to the motor starting. The open and close cycle actions can be programmed
differently. The lock can be either OUTPUT1 or OUTPUT2 (see OPERATING MODES).
Parameter
OPEN LOCK TIME Set the time the lock is
activated for on open cycles
CLOSE LOCK TIME Set the time the lock is
activated for on close cycles
PRE-OPEN LOCK TIME
Time the lock is activated for prior to opening
PRE-CLOSE LOCK TIME
Time the lock is activated for prior to closing
Menu 5. Light times
DCB-05's light function can be programmed to operate a courtesy light or a warning light. The time the light
stays on for after a cycle is adjustable.
The light can also be activated prior to the gate moving so that a warning can be given of the pending movement.
Note the light output can be selected to be either OUTPUT1 or OUTPUT2. The parameters are shown below.
Parameter
ON AFTER CYCLE LIGHT TIME
Time light remains on for after a cycle
ON BEFORE OPEN CYCLE LIGHT TIME
Minimum time light is activated for prior to
opening
ON BEFORE CLOSE CYCLE LIGHT TIME
Minimum time light is activated for prior to
closing
Menu 6. Motor settings
The motor settings adjust various aspects of the gate travel. When a single gate installation is used, the SYNC
DELAY TIMES and M2 settings are ignored. The default value for the CLOSE SYNC DELAY time is automatically
calculated for LIMIT SWITCH/AMP TRAVEL installations.
The value calculated is selected so that the delay between M2 and M1 reaching the close position is equal to the
OPEN SYNC DELAY TIME. The MAX OVERRUN TIME is set to 0 for TIMED TRAVEL installations.
Min Max Default Step
0.0 Hold 0.5 0.1
0.0 Hold 0.5 0.1
0.0 25.5 0.0 0.1
0.0 25.5 0.0 0.1
Min Max Default
0 255 60
0 255 0
0 255 0
Owner Installation Instructions Elite® - Swing Gate Opener
Unit Menu No.
Sec 4
Sec 4
Sec 4
Sec 4
Step Unit Menu No.
1 Sec 5
1 Sec 5
1 Sec 5
