Control Board Adjustments (Cont.)
Vacation mode
Vacation mode can be turned on or off using this
parameter.
Battery/solar mode
Solar mode can be turned on or off using this
parameter.
Open input polarity
The OPN input is normally confi gured for N/C
operation. This parameter allows its operation to be
changed to N/O.
Parameter
PE INPUT RESPONSE MODE Sets the PE response
mode. Options are OPEN and CLOSE cycles stop, Close
cycles stop or Close cycle reverse
PED INPUT = SWIPE MODE Selects PED input functions
as pedestrian access swipe input
REMOTE CODE ENABLED
Selects remote transmitter coding function
VACATION MODE
Selects vacation mode - disables remote control
BATTERY/SOLAR MODE
Selects Battery Backup/Solar operation
PASSWORD
Selects password protection for all changes
TX # GROUPING
Selects transmitter number group display format
OPN INPUT N/C OPERATION
Selects operating polarity of OPN input
STP INPUT N/C OPERATION
Selects operating polarity of STP input
OUTPUTS 1&2
Selects function of OUTPUT1 and OUTPUT2
OPN INPUT = 2ND PE
Open input acts as 2nd PE input
FAULT AUTO RESET
Password protection
The password feature enables all parameters and
confi guration settings to be protected unless a
password is entered. When this feature is turned on
the user is requested to enter the desired password
to be used. The password protection feature has a
time-out that expires after 60 seconds of inactivity.
Alternately the user may log out manually by pressing
exit when the main screen is displayed.
Min Max
NOT USED
OPN & CLS stop
CLS to stop
CLS to reverse
Off On
Off On
Off On
Off On
Off On
Off
Off On
Off
OUTPUT1= OUTPUT1=
LOCK LIGHT
OUTPUT2= OUTPUT2=
LIGHT LOCK
Owner Installation Instructions Elite® - Swing Gate Opener
Default Menu
No.
CLS to 7.1
reverse
Off 7.2
On 7.3
Off 7.4
On 7.5
Off 7.6
Off 7.7
Off 7.8
Off 7.9
OUTPUT1= 7.10
LOCK
OUTPUT2=
LIGHT
7.11
7.12
