Control Board Adjustments (Cont.)
Menu 3. Auto-Close times
The Auto-Close modes automatically closes the gate after it has been operated. To implement this, DCB-
05 starts a timer once the gate has reached its desired open position. The timer then counts down and
when it expires, the DCB-05 starts to close the gate. Details of the four Auto-Close modes are outlined
below. Automatic Technology strongly recommend using a PE Beam for added safety.
Standard Auto-Close
This mode is selected by entering a non-zero time
for the STD Auto-Close parameter.
When selected, the gate will Auto-Close after being
fully opened (except when the gate has reversed
to the open position after a motor obstruction or
overload).
Countdown is suspended by: PE, OPN or SWP
input being active. The countdown is aborted if the
STP input is activated.
If the gate is already open and the OPN or the SWP
input is activated, then the countdown will start.
PE Triggered Auto-Close
This mode is selected by entering a non-zero time
for the "PE Auto-Close" parameter.
This mode is used to auto-close the gate but only
after a vehicle have passed through the gateway
and triggered the PE input. The swipe input can
be used to clear the PE triggered status so that
the PE input must be activated again before the
countdown will start.
As with the other PE modes, the STP input will
abort countdown and the OPN and SWP inputs will
restart the countdown if the gate is OPEN.
Parameter
STD AUTO-CLOSE TIME
Sets and enables the standard Auto-Close time
PE AUTO-CLOSE TIME Sets and enables the PE
triggered Auto-Close time
PEDESTRIAN AUTO-CLOSE TIME Sets and
enables the Pedestrian Auto-Close time
PE PEDESTRIAN AUTO-CLOSE TIME Sets and
enables the PE Pedestrian Auto-Close time
AUTO-CLOSE AFTER CLOSE OBSTRUCTION
Enables Auto-Close feature after close
obstructions
AUTO-CLOSE AFTER OPEN OBSTRUCTION
Enables Auto-Close feature after open
obstructions
AUTO-CLOSE AFTER POWERUP
Enables Auto-Close feature after powerup
26 Elite® - Swing Gate Opener
Pedestrian Access Auto-Close
This mode is selected by entering a non-zero time for
the "Ped'n A/C" parameter.
When selected, the gate will Auto-Close after being
opened for pedestrian access unless it was following a
reverse from an obstruction.
PE Triggered Pedestrian Auto-Close
This mode is selected by entering a non-zero time
for the "PE Ped'n A/C" parameter.
This mode is the same as the PE triggered auto-
close mode, but it only operates during pedestrian
access. As the SWP input is not available during
pedestrian access, the PED input can be confi gured
to act in a SWP mode by setting the "PED I/P =
PED SWIPE MODE" parameter to ON.
Auto-Close After Obstruction
Two parameters are provided to enable the Auto-Close
feature to be activated after obstructions. Normally the
Auto-Close feature is not enabled after obstructions
for safety reasons. PE beams must be used for these
features to be activated.
Min
0.0
0.0
0.0
0.0
Off
Off
Off
Owner Installation Instructions
Max Default Step Unit
300.0 0.0 1.0 Sec
60.0 0.0 1.0 Sec
60.0 0.0 1.0 Sec
60.0 0.0 1.0 Sec
On Off
On Off
On Off
Menu No.
3
3
3
3
3
3
3
