- Page 1 ATS Series Sectional Door Opener Installation Manual TEMPO ATS-2 SYNCRO ATS-3 SECTIONAL DOOR OPENER SMART SECTIONAL DOOR OPENER Doc # 160420_03 Released 18/03/21...
-
Page 2: Table Of Contents
ATS Series Installation Manual Table of Contents Installation Instructions 1. Installation Safety Warnings! 15. Coding a Transmitter 15.1 Storing the Transmitter Code 2. Before you Begin 15.2 Installation of the Wall Mounted Transmitter 14 3. Tools Required 15.5 Remotely Coding Transmitters 4. -
Page 3: Installation Safety Warnings
Disconnect the power cord from mains power before making any repairs or removing covers. Only experienced service personnel should remove covers from the opener. • If the power supply cord is damaged, it must be replaced by an Automatic Technology service agent or suitably qualified person. •... -
Page 4: Before You Begin
ATS Series Installation Manual 2. Before you Begin 2.1 Examine the conditions in the garage: a. Look at the ceiling: i. Is it plastered? The opener is mounted to a perforated angle which MUST be securely fastened to a structural support. You will need to locate the structural beams in the ceiling which are generally 400mm apart. -
Page 5: Kit Contents
ATS Series Installation Manual 4. Kit Contents 1. 1 x ATS drive unit 8. 1 x Door bracket PLUS 2. 1 x Wall mount transmitter 9. 3 x Pin Snap SSP 8 ZNU 31080 15. 2 x Track Bracket 3. 2 x Transmitters and batteries 10. -
Page 6: Fit The Opener
ATS Series Installation Manual 6. Fit the Opener 6.1 Secure C-Rail to Opener: a. Remove the Opener from the box. b. Locate and insert the shaft of drive unit into the C-Rail’s sprocket. c. Fix the two track brackets with four (4) M4 x 8 screws supplied in accessory pack. -
Page 7: Perforated Angle
ATS Series Installation Manual 8. Perforated Angle (Not supplied) 8.1 Attach Perforated Angle (not supplied) or equivalent a. Measure across the ceiling from the centre point 3155mm (+/- 50mm) to find a supporting beam. b. Create a perforated angle which best suits your site. Use a hack saw to cut the L shape metal strips. Secure the perforated angle to a supporting beam using diagrams shown below. -
Page 8: Safety Beam Kit (Ats-3 Only)
ATS Series Installation Manual 10. Safety Beam Kit (ATS-3 Only) WARNING! The Opener must be fitted with Safety Beams if: • the closing force at the bottom edge of the door exceeds 400N (40kg) and/or; • the opener has a smart device fitted to operate the door, when not in line-of-sight. CAUTION! The Safety Beam must be installed and connected before the travel limits are set. -
Page 9: Specifications
ATS Series Installation Manual 11. Specifications Technical Specifications SYNCRO TEMPO ATS-3 ATS-2 Rated voltage range: 230V - 240Va.c. 230V - 240Va.c. Rated frequency: 50Hz / 60Hz 50Hz / 60Hz Rated power input: 165W 165W Door opening: Maximum Door Area: Maximum Door Weight:... -
Page 10: Setting Limits
ATS Series Installation Manual 12. Setting Limits 12.1 Set the Limit Positions and adjust drive speed: The Limit Positions can vary due to site conditions, such as uneven ground. When setting the Close limit, ensure the position is when the door makes first contact with the ground. -
Page 11: Clearing The Door Limit Positions
ATS Series Installation Manual 12. Setting Limits NOTE: If unhappy with the speed or travel limit setting, restart this procedure by clearing the door limit positions as per below first. 12.2 Clearing the Door Limit Positions Limit positions can be deleted by: a. -
Page 12: Safety Testing
ATS Series Installation Manual 13. Safety Testing CAUTION: Take care when completing a safety test. Failure to follow this warning can result in serious personal injury and/or 13.1 Test the Close Cycle property damage. a. Press the OPEN button or transmitter button to open the door (If the door starts closing, press the transmitter button to stop the door, then press transmitter again to open). -
Page 13: Auto-Close
ATS Series Installation Manual 14. Auto-Close Auto-Close mode is a function that automatically closes the door after a pre-set time. Safety beams must be installed in order to run the Auto- Close function. There are two types of Auto-Close available: i. -
Page 14: Coding A Transmitter
ATS Series Installation Manual 15. Coding a Transmitter 15.1 Storing the Transmitter Code BUTTON The opener can only operated from remote control transmitters that have been programmed into its TRANSMITTER FUNCTION memory. Up to 64 codes can be stored in the memory. a. -
Page 15: Smart Phone Control (Ats-3 Only)
ATS Series Installation Manual 16. Smart Phone Control (ATS-3 Only) This device allows for operation of the door when not in line-of-sight of the door and opener. The door may operate unexpectedly, therefore do not allow anything to stay in or near the path of the door. -
Page 16: Home Owner Safety Warnings
ATS Series Installation Manual 17. Home Owner Safety Warnings! This automatic garage door opener is designed and tested to offer safe service provided it is installed and operated in strict accordance with the following safety warnings. Failure to comply with the following instructions may result in death, serious personal injury or property damage. WARNING! IMPORTANT SAFETY INSTRUCTIONS IT IS IMPORTANT FOR THE SAFETY OF PERSONS TO FOLLOW ALL INSTRUCTIONS. -
Page 17: Opener Safety & Security
ATS Series Installation Manual 18. Opener Safety & Security 18.1 Your Door CAN NOT be used by the opener when: WARNING! When operating the manual a. There is a locking device installed. release (while the door is open) the door b. -
Page 18: User Operating Controls
8. BATTERY STATUS LED (Yellow) Illuminates when battery is charged and flashes when battery is charging, in use or battery failed. Battery function not available with ATS-2 model. 9. REMOTE CONTROL Flashes on remote lockout and flickers on remote control activity STATUS LED (Red) 10. -
Page 19: Troubleshooting
ATS Series Installation Manual 21. Troubleshooting Symptom Possible cause Remedy The opener does not Garage door in poor condition e.g. Check the door’s operation work from the transmitter springs may be broken The opener does not have power Plug a device of similar voltage (e.g. a hairdryer) into the power point and check that it is OK The battery in the transmitter is flat Replace the battery... - Page 20 ATS Series Installation Manual 21. Troubleshooting Main Light = Service / Warning Indicator: Requirements for a service and user warnings are indicated after operation by the main light repeatable flashing OFF a number of times followed by a pause. The below table identifys the issues and remedies. Flashes Issue Remedy Normal operation (door is fully open)
-
Page 21: After Installation Care
ATS Series Installation Manual 22. After Installation Care 22.1 Service Checklist Preventative servicing of your garage door and opener, is WARNING! Failure to maintain your just as important as servicing your car. Much like the engine garage door voids the warranty on your of your car, your garage door is made up of numerous garage door opener. -
Page 22: Battery Replacement
When batteries reach the end of their usual life in accordance with Australian Battery Recycling Initiative please follow the next simple steps for protecting the environment. Refer to the Automatic Technology website for information on where to recycle batteries in Australia. -
Page 23: Appendix
ATS Series Installation Manual 23. Appendix A - Status Indication during Operating Mode. LEDs Light Status Description BLUE GREEN YELLOW PURPLE solid Open DOOR OPEN CLOSED LEDS flashing Open with Autoclose timer running flashing Opening / Obstructed on Open solid Closed flashing Closing / Obstructed on Close... -
Page 24: B - Adjustment Mode Instructions
ATS Series Installation Manual B - Adjustment Mode Instructions a. Press the MODE button repetitively until the GEAR LED starts flashing b. Referring to the table below, select the desired parameter using the OPEN and CLOSE buttons and observing the number of flashes on the GEAR LED. -
Page 25: D - Battery Functions
ATS Series Installation Manual D - Battery Functions a. Holding the STOP button for 10secs when running from battery backup will shut the PCB down so as to reduce battery current consumption to a minimum. b. Holding the STOP button for 4secs when a battery is fitted and running from mains power will cause the controller to test the battery state to determine if it is disconnected / open circuit, missing, faulty or ready. -
Page 26: F - Setting The Pet Mode Position
Press MODE button to exit the door selection mode. Proceed to Section 12 to set the limits. Automatic Technology office location Head Office 6-8 Fiveways Blvd, Keysborough 3073 Phone (03) 9791 0200 Prefixed trademarks are the property of Automatic Technology (Australia) Pty Ltd ABN 11 007 125 368. © 2020 Automatic Technology Australia Pty Ltd. ata-aust.com.au...
