- Page 1 Easy Slider Sliding Gate Opener INSTALLATION INSTRUCTIONS | OWNERS COPY...
- Page 2 Automatic Technology Australia Sliding Gate Opener in accordance with these installation instructions.
-
Page 3: Table Of Contents
Menu 9.6 Import labels Code operation (location empty) Accessories installation Code operation (location used) Trouble shooting guide Delete operation Specifications Edit operation Parts list Copy operation Warranty and exclusion of liability Owner Installation Instructions Easy Slider - Sliding Gate Opener... - Page 4 If the power supply cord is damaged, it must be replaced by an ATA service agent or suitably qualified person. Make sure that remote controls are kept out of reach of children. Easy Slider - Sliding Gate Opener Owner Installation Instructions...
-
Page 5: Important Safety Instructions
DO NOT use if repair or adjustment is needed since a fault in the installation or an incorrectly balanced gate may cause injury. Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 6: Features
A revolutionary gate travel limit setting system. The ALPS technology eliminates manual adjustment of the gates limits position using mechanical parts such as micro switches and cams. In addition, the opener’s display console guides you through the installation and set up. Easy Slider - Sliding Gate Opener Owner Installation Instructions... - Page 7 The opener is equipped with a unique manual disengaging device. If the power to the opener is disrupted for any reason the gate can disengaged via a key lock located on the operator. This will allow you to manually open or close the gate. Owner Installation Instructions Easy Slider - Sliding Gate Opener...
-
Page 8: Product Description
The drive unit consists of a powerful 24V DC motor, rugged gearbox assembly and travel limits position encoder. It also provides a key lockable manual release lever. When used with suitable cable glands the enclosure meets the IP33 standard for ingress of dust and water. Easy Slider - Sliding Gate Opener Owner Installation Instructions... - Page 9 Step 1. Initial checking Before commencing installation of the Easy Slider sliding gate opener, check the following: 1. The gate moves freely and easily by hand for the full opening and closing travel.
-
Page 10: Drive Unit Installation
7. Drill the four mounting holes where the lines intersect. 8. Hammer the loxins into position. Place the Drive Unit into position and fix with the four bolts so that you are still able to move the Drive Unit. Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 11: Rack Installation
(Fig. 05). 6. Tighten the racks. This will ensure that the drive unit pinion canrun along the racks without obstruction. Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 12: Control Board Layout
*Console Up/Open button *Console SET button *Console Next button *Antenna connector *Console Display Motor installation side selector *Optional light module interface connector *Standby battery charger/solar connector * Not present on slave unit Easy Slider - Sliding Gate Opener Owner Installation Instructions... - Page 13 Control board layout Owner Installation Instructions Easy Slider - Sliding Gate Opener...
-
Page 14: Menu Structure
Menu structure Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 15: Initial Electrical Installation
fig Step 3. Selecting left or right hand installation Refer to (Fig. 08) and (Fig. 09), place the motor connector for each drive unit as required. Left hand fig Right hand Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 16: Powering Up Drive Unit
Step 1. Navigating to “set gate travel menu” 1. Press PREV to navigate to the Menu 10 (Fig. 12). 2. Press SET to display MENU 10.1. 3. Press SET again to enter the limit setting procedure. Easy Slider - Sliding Gate Opener Owner Installation Instructions... - Page 17 SETTING PEDESTRIAN POSITION procedure. Errors during setting of travel limit During the above procedure many error checks are preformed. If an error is detected a message will be displayed indicating the error. Owner Installation Instructions Easy Slider - Sliding Gate Opener...
-
Page 18: Setting Travel Limits For Dual Leaf Gate
The procedure documented here shows the �� � � � steps for when M1 is selected. If M2 is selected to open first, then the displayed motor numbers will be the opposite to those shown here. Easy Slider - Sliding Gate Opener Owner Installation Instructions... - Page 19 �� POSITION procedure. Errors during setting of travel limit During the above procedure many error checks are preformed. If an error is detected a message will be displayed indicating the error. Owner Installation Instructions Easy Slider - Sliding Gate Opener...
-
Page 20: Setting Pedestrian Position
� � � � � � � � � � � � � � � � � � � � � � � � � � � � � � � fig Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 21: Description Of Standard Operation
Vacation mode can also be turned on to stop. The next trigger will move the gate in the or off manually by editing the VACATION MODE opposite direction to that last travelled. parameter. Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 22: Control Board Adjustments
P.E PEDESTRIAN AUTOCLOSE TIME Sets and 300.0 enables the PE Pedestrian auto-close time AUTOCLOSE AFTER CLOSE OBSTRUCTION Enables autoclose feature after close obstructions AUTOCLOSE AFTER OPEN OBSTRUCTION Enables autoclose feature after open obstructions Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 23: Menu 4 Lock Times
Sets the full speed motor voltage GATE LEAF SYNCHRONISING DELAY Revs Sets the # of turns delay between gates opening EXTRA SYNCHRONISING DELAY FOR CLOSE Revs Additional # turns delay between gates opening Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 24: Menu 7 Operating Modes
VACATION MODE Selects vacation mode - disables remote control BATTERY/SOLAR MODE Selects Battery Backup/Solar operation PASSWORD Selects password protection for all changes OPN INPUT N/O OPERATION Selects operating polarity of OPN input Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 25: Viewing And Editing Parameter
Default?” screen, giving option of EXIT to return to sub menu. Press EXIT again to return Exits back to View Mode loading default value with no changes made to the MAIN SCREEN. Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 26: Coding Transmitter
Press EXIT to return to the MAIN SCREEN and test the � � � � � � � � � � � � � transmitter. fig NOTE: To edit the other settings, refer to TRANSMITTER EDIT PROCEDURE. �� � � � Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 27: Transmitter Edit Procedure
If all button functions are set to OFF, when SET is pressed, the opener will prompt to confirm if the transmitter is to be deleted. Press SET to delete or EXIT to continue editing. Owner Installation Instructions Easy Slider - Sliding Gate Opener... - Page 28 4. Repeat step 2. 5. Press SET to record changes. The second line of the display shows a list of available characters with the current value indicated at the cursor position. Easy Slider - Sliding Gate Opener Owner Installation Instructions...
-
Page 29: Transmitter Management
� � � � � � � � � � � � � � � � � � � � � � � � � � fig fig �� � � � Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 30: Code Operation (Location Empty)
TRANSMITTER PROCEDURE for each transmitter to be fig coded. Coding is terminated by pressing the EXIT button. Exiting the list To exit the transmitter list simply press EXIT to return to the Code Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 31: Remote Code Set Procedure
ID label of the new transmitter is set to: R/C Tx ###, where ### is the existing transmitters store number. This ensures that the originator of any remote coded transmitter can be identified. Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 32: Diagnostic Tools (Menu 8)
Menu 8.4 Memory usage � � � � � � This tool displays the number of transmitter store � � � � � � � location used and the number free (Fig. 63). fig Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 33: Menu 8.5 Service Counter
24: M1 Direction Faults 11: M2 Close Stall 25: M2 Direction Faults 12: M1 Open Obstructions 26: M1 Sensor Faults 13: M2 Open Obstructions 27: M2 Sensor Faults 14: M1 Close Obstructions Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 34: Memory Tools (Menu 9)
This option is provided so that transmitter labels entered using Transmitter Management software on a P.C can be loaded into memory without altering the transmitters themselves. Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 35: Accessories Installation
See Page XX for Light Times set up. WARNING: A qualified electrician must perform the installation where 240V AC power is used. Light power supply fig Light relay module Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 36: Trouble Shooting Guide
In such an instance please contact your ATA dealer for an alternative frequency replacement kit. As this is not a warrantable situation but an environmental issue charges may apply for the changeover. Easy Slider - Sliding Gate Opener Owner Installation Instructions... -
Page 37: Specifications
2. Intermittent operations may occur in areas which experience very strong wind gusts. A strong wind puts extra pressure on the gate and tracks which may in turn trigger the safety obstruction detection system intermittently. NOTE: Specifications are subject to change without notice. Owner Installation Instructions Easy Slider - Sliding Gate Opener... -
Page 38: Parts List
37. PCB support 02430 38M. Control board CB-11 V-1.02 master 01060 38S. Control board CB-11 V-1.02 slave 01062 39M. PCB cover assy ESV24/240 master 02490 39S. PCB cover assy ESV24/240 slave 02491 Easy Slider - Sliding Gate Opener Owner Installation Instructions... - Page 39 Owner Installation Instructions Easy Slider - Sliding Gate Opener...
-
Page 40: Warranty And Exclusion Of Liability
Trade Practices Act 1974 (Cth). 2. Subject to all of the matters set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants: (a) swing and sliding gate opener drive units for twelve (12) months or 2500 cycles, whichever occurs first;... - Page 41 Web: www.ata-aust.com.au Email: sales@ata-aust.com.au ©March 2005 Automatic Technology Australia Pty Ltd. All rights reserved. SecuraCode® is a registered trademark of Automatic Technology Australia Pty Ltd. In an ongoing commitment to product quality ATA reserve the right to change specification without notice.
