Traction Sets

Parameter Default
Traction Sets: 1.5
Acc Ramp: #.# [s]
Traction Sets: 0.7
Dec Ramp: #.# [s]
Traction Sets: 0.7
Rev Ramp: #.# [s]
Traction Sets: 100
FW Speed: ### [%]
Traction Sets: 60
BW Speed: ### [%]
Traction Sets:
Min Speed: ### [%]
Traction Sets:
Ref 0: #.# [V]
Traction Sets:
Ref FW: #.# [V]
Traction Sets:
Ref BW: ## [V]
Traction Sets: 0.200
Ref DB: 0.### [V]
Traction Sets: 1.5
Brake Del: ### [S]
Traction Sets: 50
Mode1 V: ## [%]
Traction Sets: 25
Mode1 I: ## [A]
Traction Sets: 12
Runaway: ### [Volt]
Traction Sets:
optional3: ##
Traction Sets:
optional2: ##
Traction Sets:
optional1: ##
Traction Sets: 70
I Max: ## [Amp]
Traction Sets: 20
I Nom: ## [Amp]
Traction Sets: 10
T Nom: ## [s]
Min Max Description
0.5 5.0 Acceleration ramp. The time necessary to arrive at the maximum
speed.
0.5 5.0 Deceleration ramp. The time necessary to stop the machine when the
safety lever is released.
0.5 5.0 The time necessary to invert the way.
20 100 Maximum speed in forward way (expressed in %).
20 100 Maximum speed in reverse way (expressed in % respect the maximum
speed in forward way).
0 0 20 Minimum speed when the safety lever is pressed.
7 0 150 Minimum voltage of the potentiometer when released.
9 5 150 Maximum voltage of the potentiometer in forward speed when safety
lever is pressed.
9 5 150 Maximum voltage of the potentiometer in backward speed when safety
lever is pressed.
0.000 0.500 Potentiometer dead band
0.0 10 Engaging time of electronic brake when the machine is stopped.
10 100 Voltage setting for the curve speed reduction microswitch.
0 90 Current intensity setting for the curve speed reduction microswitch.
0 20 Parameter not managed.
0 0 Parameter not managed.
0 0 Parameter not managed.
0 0 Parameter not managed.
10 70 Maximum output from the main card to the traction motor.
5 30 Rated Current; with T Nom detect the amperometric protection
threshold. (Alarm + stop traction motor).
1 10 Rated Timer; with I Nom detect the amperometric protection thresh-
old. (Alarm + stop traction motor).
