List of Components
1
CB Battery charger
CBR Charger safety contact
CD Control Card
EL Solenoid Valve
FE Emergency button
5-33
J Main Card
LAMP Safety blinking light
M1 Traction Motor
M1E Traction Motor electrobrake
M2 Brush Motor
M3 Vacuum Motor
ML Control microswitches
MS Seat microswitch
MULTIM Curve sensor microswitch
PM Potentiometer and pedal microswitch
1
Optional
