Remove the sprocket fixing screws
.
(see fig. 4.4.5-49)
Remove the sprocket.
Remove the screws that secure the
cam to the sprocket and remove the
cam.
Remove the Front Wheel
.
50)
Remove the bearings pin.
Remove the bearings
Proceed at reverse to refit the part.
A :
TTENTION WHEN ASSEMBLING
EXTREME ATTENTION AT THE CORRECT
POSITIONING OF THE SPACER
BECAUSE IT IS FUNDAMENTAL FOR THE
PROPER FUNCTIONING OF THE PAR T
4.4.5-48 Fixing screws of
the wheel to the frame
4.4.5-50 Wheel support
pin
4.4.5-52 Bearings on the
steering sprocket
(see fig. 4.4.5-
.
(see fig. 4.4.5-52)
,
PAY
436224,
.
4.4.5-49 Fixing screws of
the steering sprocket
4.4.5-51 Bearings in the
wheel fork
4.5 Solution Delivery Sys-
tem
4.5.1 Solution Tank
Put the machine in safe conditions.
Remove the recovery tank
4.3.4 at page 23) (see fig. 4.5.1-53)
Remove the battery tray
Remove the
carter.
(see fig. 4.5.1-55)
Remove the footrest.
Remove the electrical installation
carter
(see fig. 4.5.1-56)
Remove the support bracket of the
Main card.
Remove the traction pedal assembly.
Remove the seat and the deadman
microswitch
(see fig. 4.5.1-57)
Disconnect the water hose from the
brush deck
(see fig. 4.5.1-58)
Disconnect the control rod from the
water valve
(see fig. 4.5.3-62)
Remove the screws that secure the
solution tank to the machine frame.
Remove the tank, pulling it out from
the steering column, taking care not
to damage the steering wheel.
Turn the tank and remove the solu-
tion delivery system
Proceed at reverse to refit the part.
4.5.2 Hoses
Put the machine in safe conditions.
Loosen the clamps that hold the
hose to the fitting.
(see section
.
.
(see fig. 4.5.1-54)
steering column
.
.
.
.
.
.
(see fig. 4.5.1-60)
