Curve speed reduction Microswitch.
it is positioned below the platform,
tangent to a cam.
termined angle of rotation of the
steering, the microswitch opens and
the curve speed reduction function
is activated. The percentage of the
speed reduction is an adjustable pa-
rameter.
Deadman Microswitch.
switch is located below the seat.
With the operator on board, the trac-
tion and the brush deck can be acti-
vated.
5.3.5
Electrobrake
The machine is equipped with electro-
brake. The electro-brake is engageable
through an appropriate control lever po-
sitioned on the electro-brake itself, close
to the traction motor. looking at a global
security condition, even if the machine is
switched off and the electrobrake is dis-
engaged, the electrobrake blocks how-
After a prede-
ever, in case of exceeding a certain speed
(when pushing the machine or if the ma-
chine is on an inclined floor). If the ma-
chine is switched on, the drive is inhib-
ited if the electrobrake is disengaged.
The micro
5.3.6
The machine is equipped with an emer-
gency button, aimed at the protection
of the operator in case of sudden crit-
ical conditions. A press of the button
switches off the power to the Main card
and the machine stops immediately.
5.3.7
The traction pedal have an internal mi-
croswitch that closes when the pedal is
Emergency button
Traction Pedal
5-39
