Fimap MXR Workshop Manual page 48

Vacuum Sets
Parameter
Vacuum Sets:
I Max: ## [Amp]
Vacuum Sets:
I Nom: ## [Amp]
Vacuum Sets:
T Nom: ## [s]
Vacuum Sets:
5-48
T Off: ## [s]
Vacuum Sets:
T reset: ## [s]
Vacuum Sets:
Eco Speed: ## [V]
Vacuum Sets:
Rit Up: ## [s]
Vacuum Sets:
optional3: ##
Vacuum Sets:
optional2: ##
Vacuum Sets:
optional1: ##
Default Min Max Description
40 10 50 Maximum current from the main card to the vacuum motor.
18 5 20 Rated current; with T Nom manages the amperometric protection
(alarm + stop vacuum motor).
30 1 100 Rated timer; with I Nom manage the amperometric protection (alarm
+ stop vacuum motor).
20 0 30 Delay of switching on of the vacuum motor when the switch is
pressed.
60 0 100 Timing of reset amperometric protection (overcurrent).
17 15 20 Value of Voltage reduction of vacuum motor, during ECO mode
3 0 10 Parameter not managed.
0 0 Parameter not managed.
0 0 Parameter not managed.
0 0 Parameter not managed.
