Setup
Symbol Type
This field allows the user to configure the database to operate on specific symbol types for
selected database index. Symbol type-specific parameters must be configured with the
appropriate symbol type command. For example, fixed length Code 128 is required; it
must be set up with the Code 128 command <K474>. To configure a symbol type, simply
add the number value associated with the symbol type to the field parameter.
Example: If Data Matrix and Code 39 are required, the parameter would be 2 + 16 = 18.
See I/O Parameters for a description of how to enter these values via serial command.
Disabled
When disabled, the database uses the current Symbol Type setup to determine active
symbol types.
Any Type
All of the preceding symbol types, except Pharmacode, are enabled while this database
index is being used.
Add 1.
Data Matrix
If enabled, Data Matrix will be active for this database index.
Important: The ECC Level must be configured using the Data Matrix command <K479>.
If no ECC level has been configured, then it will not decode a Data Matrix symbol.
Add 2.
QR Code
If enabled, QR Code will be active for this database index.
Add 4.
Code 128
If enabled, Code 128 will be active for this database index.
Add 8.
Code 39
If enabled, Code 39 will be active for this database index.
Add 16.
Codabar
If enabled, Codabar will be active for this database index.
Add 32.
