Output Format
Format Extract
Format Insert
Format Assign
Output Format Status
Output Filter Configuration
Number of Filters
Format Extract
Output Index (Format Extract)
Serial Cmd: <K740,output
Options: 1 to 100
Start Location (Format Extract)
Serial Cmd: <K740,output
Default: 0
Options: 1 to n (maximum number of characters in the symbol data).
Length (Format Extract)
Serial Cmd: <K740,output index,start location,length>
Default: 0 (Disabled; end of format cell array)
Options: 1 to n (maximum number of characters in the symbol data).
Format Insert
Output Index (Format Insert)
Output Index refers to the database entry to be modified with this command. A formatted
output is built by extracting data from a symbol's original data output and/or inserting user-defined
characters.
It may be helpful to think of individual indexes as positions in the final formatted output.
Starting with index # 1, enter either an extract or insert command to begin building the
required output string. Then, with the next index number, enter either an extract or insert
command to continue building the output string. Continue this process until the string is complete.
Serial Cmd: <K741,output
Options: 1 to 100
QX Hawk Industrial Imager User Manual
<K740,output index,start location,length>
<K741,output index,length,hex string>
<K742,symbol number,status>
<K743,output format status>
<K744,filter number,symbology type,length,wildcard,placeholder,
data,unused,database index>
<K745,number of filters>
index,start location,length>
index,start location,length>
index,length,hex string>
Appendices
A-79
