Search and Configure Mode
Search and Configure Mode is intended primarily for initial setup of a QX Hawk in a network.
This parameter controls whether or not the QX Hawk will respond to ESP's Search function
in the Ethernet TCP/IP connect dialog section of the
Changes to this parameter are saved to NOVRAM and are set to default on power on.
A Reset <A> is required for settings to take effect.
Important: Once this setting is Disabled, ESP will only be able to connect to the imager if
you know the IP address and enter it in the IP Address field of the Ethernet TCP/IP connect
dialog. Search and Configure Mode can be re-enabled by defaulting the QX Hawk.
Enabled
When enabled, Search and Configure Mode will find the imager and settings can be
changed.
Timed Window
When Timed Window is selected, Search and Configure Mode will find the imager and
settings can be changed, but only 60 seconds from the last reset. After 60 seconds,
Search and Configure Mode will be disabled.
QX Hawk Industrial Imager User Manual
Connection Wizard:
After the QX Hawk is in full use in
an application, you may want the
imager to continue to appear in
the Search response list for future
searches. This can help prevent
disruption of the system that may
occur is ESP were to show only
unconfigured units.
Parameters
5-21
