Default/Reset/Save
Customer Default Parameters
Customer default parameters (saved by <Zc>) are the same set of parameters as power-on
parameters but are saved in a different, isolated section of NOVRAM. This allows a user
essentially to create a back-up set of parameters that can be recalled in the event that the
current parameters or power-on parameters have been accidentally changed or are no
longer desired.
It is important to note that a hardware default (jumper the default pin to ground) does not
affect customer default parameters. For example, a user that has inadvertently changed
communication settings and saved them with a
settings or have the capability to communicate within those settings. By first doing an EZ
Button default to restore the known Microscan defaults, the user can then recall the previous
customer-saved settings with an
Restore Customer Defaults
Use the EZ Button to default the scanner by holding it down while applying power to the
scanner (if this feature is enabled).
Microscan Default Parameters
Microscan default parameters are contained in the firmware and cannot be changed.
Software Defaults
Microscan default parameters can be recalled (loaded into current settings) with the
<Ard> command or recalled and saved for power-on with the
Hardware Default
If a software default and reset is not possible, it may be necessary to reset the imager by
shorting (connecting) specific pins. This procedure has the same effect as the
software command.
Important: For this reset to occur, this command must be executed within 60 seconds of a
power-on or a reset.
1. Apply power to the imager.
2. Locate default pin and ground. Ensure that the correct pins are located, as connecting
the wrong pins may cause serious damage to the imager.
3. Momentarily connect the wires (or pins) and listen for a series of short beeps that last
approximately 3 seconds.
4. Within 3 seconds, disconnect and then re-connect the two wires again. A longer beep
should be heard. If not, repeat the process above.
Default on Power-On
Use the EZ Button to default the imager by holding it down while applying power to the
imager (if this feature is enabled).
7-24
<Z> command, may not know the correct
<Arc> or <Zrc> command.
QX Hawk Industrial Imager User Manual
<Zrd> command.
<Zrd>
