User Defined Tag Echo, Command Echo, Output Control Echo
These are a direct echo of the equivalent fields in the OUT assembly. They provide the
PLC programmer with a method of verifying that the OUT data has been received by QX Hawk.
External Input Status (Physical Pin State)
Bit # Pin Name
0 Trigger
1 New Master
2-31 Reserved
0 = no current sensed on input
1 = current sensed on input
External Output Status (Physical Pin State)
Bit # Pin Name
0 Out1
1 Out2
2 Out3
3-31 Reserved
0 = output contact is open
1 = output contact is closed
Device Status
Field # Bit Name
0 Reserved
New Master
1
Requested
2-7 Reserved
8 Scanning Disabled
9-15 Reserved
16 In Read Cycle
17 Actively Scanning
QX Hawk Industrial Imager User Manual
State
1 = New Master Requested
1 = Scanning Disabled
1 = In Read Cycle
1 = Active Scanning
