Data Types
Microscan Data Type AB PLC
U8
U32
STRING32
QX Hawk Small IN Assembly 0x64, 100 decimal (IN = QX Hawk -> PLC)
Field # Data Type
0 U32
U32
1
(32 bit flags)
U32
2
(32 bit flags)
3 U32
4 STRING 32
This is a small, lightweight input assembly. It is a subset of the "Big IN Assembly 0x65". It provides
feedback of the output assembly, and the text of any bar codes decoded by the imager.
See Big IN Assembly 0x65 for a description of the data fields.
QX Hawk Industrial Imager User Manual
ODVA CIP EDS
SINT USINT
DINT UDINT
STRING UDINT and BYTE[]
Size (# of Data
Type Elements
User-Defined Tag Echo
1
Echo from asm OUT 0xC6
Command Echo
1
Echo from asm OUT 0xC6
Output Control Echo
1
Echo from asm OUT 0xC6
Read Cycle Sequence Counter:
When this value changes, it indicates the following
read cycle report fields have changed.
1
0 = Read cycle report has been "reset" to
"empty".
Read cycle report data is only valid when
Sequence is not 0.
Read Cycle Report: Decoded Data
Up to 64, 8-bit chars
U32 + U8[64]
The first U32 is the length of the bar code data
in the U8[64] field.
Total=
84 U8,
or 21 U32
Appendices
Description
Unsigned, 8 bit
Unsigned, 32 bit
A 32 bit length field, followed by
8 bit ASCII characters
Field Name
A-99
