Morphology Operation (Configuration Database, Standard QX Hawk, CCD)
Serial Cmd:
<K255,index,shutter speed,gain,focal distance,unused,row pointer,column
pointer,row depth,column width,symbol
Default:
0 = Disable
Options:
0 = Disable
3 = Open
Morphology Size (Configuration Database, Standard QX Hawk, CCD)
Serial Cmd:
<K255,index,shutter speed,gain,focal distance,unused,row pointer,column
pointer,row depth,column width,symbol type,morphology
Default:
3 = Small
Options:
3 = Small
Save Current Settings to Configuration Database
Serial Cmd:
<K255+,index>
Example:
<K255+,5>
Load Current Settings from Configuration Database
Serial Cmd:
<K255–,index>
Example:
<K255–,5>
Request Database Index Setting
Serial Cmd:
<K255?,index>
Returns:
Returns settings for the selected Configuration Database index.
Request All Database Settings
Serial Cmd:
<K255?>
Returns:
Returns settings for the entire Configuration Database.
Database Mode
Switch Mode (Database Mode)
Serial Cmd:
<K256,switch
dimensions>
Default:
1 = Number of Image Frames
Options:
0 = Time
1 = Number of Image Frames
Frame Count/Time (Database Mode)
Serial Cmd:
<K256,switch
dimensions>
Default:
1 (1 frame/1 ms)
Options:
1 to 65535 (in 1 ms increments)
QX Hawk Industrial Imager User Manual
type,morphology
1 = Erode
4 = Close
5 = Medium
Saves current imager settings to database index number 5.
Loads current settings from database index number 5 to the imager.
mode,frame count/time,image process looping,image
mode,frame
count/time,image process looping,image
Appendices
operation,morphology size>
2 = Dilate
operation,morphology
size>
7 = Large
A-77
