Microscan QX Hawk User Manual page 374

Serial Commands
I/O Parameters
Calibration Options
Serial Verification
Beeper
Quality Output
Symbol Data Output
Read Duration Output
No Read Message
Input 1
Frame Information
ISO/IEC 16022 Parameter LED Configuration <K737,unused,ISO/IEC 16022 parameter>
Green Flash LED
Status Indicators
EZ Trax Output
Database Identifier Output
EZ Button
EZ Button Modes
Trend Analysis Output 1
Trend Analysis Output 2
Trend Analysis Output 3
Diagnostics Output 1
Diagnostics Output 2
Diagnostics Output 3
Symbol Quality Output 1
Symbol Quality Output 2
Symbol Quality Output 3
Output 1 Parameters
Output 2 Parameters
Output 3 Parameters
A-56
<K529,gain,shutter speed,focus position,symbol type,window of
interest framing,window of interest margin,unused>
<K701,serial command echo status,serial command beep status,
control/hex output>
<K702,status>
<K704,quality output separator,decodes per trigger status>
<K705,symbol data output status,when to output symbol data>
<K706,status,separator>
<K714,status,message>
<K730,mode,active state>
<K734,output frame number,output coordinates>
<K750,green flash LED status,targeting status,green flash duration>
<K751,comm,bar graph,I/O 1,I/O 2>
<K757,status,comm port,image mode,image format,JPEG quality,
object info output,grade output>
<K759,status,separator character>
<K770,global status,default on power-on,load configuration database,
save for power-on>
<K771,single beep,two beeps,three beeps,four beeps>
<K780,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
<K781,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
<K782,trend analysis mode,number of triggers,number to output
on,decodes per trigger>
<K790,unused,service unit>
<K791,unused,service unit>
<K792,unused,service unit>
<K800,output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on unused ECC,unused
ECC threshold>
<K801,output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on unused ECC,unused
ECC threshold>
<K802,output on symbol contrast,symbol contrast threshold,output
on print growth,print growth threshold,output on axial non-uniformity,
axial non-uniformity threshold,output on unused ECC,unused
ECC threshold>
<K810,output on,output state,pulse width,output mode>
<K811,output on,output state,pulse width,output mode>
<K812,output on,output state,pulse width,output mode>
QX Hawk Industrial Imager User Manual
