Row Depth (Window of Interest)
Serial Cmd: <K516,row pointer,column
Default: 960
Options: 3 to (960 – row pointer)
Column Width (Window of Interest)
Serial Cmd: <K516,row pointer,column pointer,row
Default: 1280
Options: 8 to (1280 – column pointer)
Focus Distance
Focal Distance (Focus Distance)
Serial Cmd: <K525,focal
Default: 80
Options: 25 to 4,000 (mm)
100 to 4,000 (1/100 inch)
Distance Units (Focus Distance)
Serial Cmd: <K525,focal
Default: 0 = millimeters
Options: 0 = millimeters
Lens Type (Focus Distance)
Serial Cmd: <K525,focal distance,distance
Default: 3 = 45°
Options: 1 = 15°
2 = 30°
3 = 45°
4 = 12°
Illumination (Standard QX Hawk)
Mode (Illumination, Standard QX Hawk)
Serial Cmd: <K539,mode,intensity>
Default: 1 = Bright Field
Options: 0 = Always Off
1 = Bright Field
2 = Mode 2
3 = Mode 3
4 = Mode 4 (Internal Off)
QX Hawk Industrial Imager User Manual
pointer,row
distance,distance units,lens type>
distance,distance units,lens type>
1 = 1/100 inch
units,lens
depth,column width>
depth,column width>
type>
